Yamaha CRYPTON T105E Manuel utilisateur

OWNER'S

MANUAL

5AV-F8199-E0

EAA00100 EAA20301

INTRODUCTION

Congratulations on your purchase of the

Yamaha T105E. This model is the result of

Yamaha’s vast experience in the produc-

tion of fine sporting, touring, and paceset-

ting racing machines. It represents the high

degree of craftsmanship and reliability that

have made Yamaha a leader in these fields.

This manual will give you an understand-

ing of the operation, inspection, and basic

maintenance of this motorcycle. If you

have any questions about the operation or

maintenance of your motorcycle, please

consult a Yamaha dealer.

T105E

OWNER’S MANUAL

Manufacturing

1st edition, September 2001

unauthorized use without the written

permission of Yamaha Motor Co, Ltd.

Manufacturing is expressly prohibited.

Printed in China

T105(E) O/M-1 9/11/01 11:16 AM Page 1 (1,1)

EAA10500

Particularly important information is distin-

guished in this manual by the following

notations:

The Safety Alert Symbol means ATTEN-

TION! BECOME ALERT! YOUR SAFETY IS

INVOLVED!

Failure to follow WARNING instructions

could result in severe injury or death to the

motorcycle operator, a bystander or a per-

son inspecting or repairing the motorcycle.

A CAUTION indicates special precautions

that must be taken to avoid damage to the

motorcycle.

NOTE:

A NOTE provides key information to make

procedures easier or clearer.

EUU13800*

NOTE:

9Yamaha continually seeks advancements

in product design and quality. Therefore,

while this manual contains the most cur-

rent product information available at the

time of printing, there may be minor dis-

crepancies between your machine and

this manual. If there is any question con-

cerning this manual, please consult your

Yamaha dealer.

9This manual should be considered a per-

manent part of this motorcycle and

should remain with it even if the motor-

cycle is subsequently sold.

EUU60100

PLEASE READ THIS MANUAL CAREFULLY

AND COMPLETELY BEFORE OPERATING

THIS MOTORCYCLE.

T105(E) O/M-1 9/11/01 11:16 AM Page 2 (1,1)

GIVE SAFETY THE RIGHT OF WAY...............5

GENERAL NOTE..............................................6

DESCRIPTION..................................................8

MOTORCYCLE IDENTIFICATION...................9

Identification numbers record ...................9

Key identification number .......................10

Frame serial number ................................10

Engine serial number ...............................10

CONTROL FUNCTIONS................................11

Main switch ...............................................11

Indicator lights ..........................................12

Instrument panel.......................................13

Handlebar switches ..................................14

Shift pedal .................................................16

Front brake lever.......................................16

Rear brake pedal .......................................17

Fuel tank cap .............................................17

Starter lever 1..........................................18

Kick starter.................................................18

Steering lock..............................................19

Seat ............................................................20

Helmet holder ...........................................21

Side cover removal...................................21

PRE-OPERATION CHECKS ...........................22

Fuel.............................................................24

Engine oil...................................................25

Tires............................................................26

OPERATION AND IMPORTANT

RIDING POINTS.............................................27

Starting and warming up a

cold engine ................................................28

Starting a warm engine ...........................30

Shifting.......................................................31

To start out and accelerate.......................31

To decelerate .............................................33

Engine break-in .........................................34

Parking .......................................................36

EAA30001

CONTENTS

T105(E) O/M-1 9/11/01 11:16 AM Page 3 (1,1)

PERIODIC MAINTENANCE AND

MINOR REPAIR..............................................37

Tool kit........................................................38

Periodic maintenance/lubrication ...........39

Engine oil...................................................41

Air filter ......................................................44

Throttle cable adjustment........................46

Carburetor adjustment.............................47

Idle speed adjustment..............................47

Spark plug inspection ..............................48

Front brake adjustment............................50

Rear brake adjustment .............................51

Brake light switch adjustment.................52

Checking the brake shoes ........................52

Drive chain slack check ............................53

Drive chain slack adjustment ..................54

Drive chain lubrication .............................56

Brake lever and pedal...............................57

Center and sidestand ...............................57

Front fork inspection ................................58

Battery........................................................59

Replenishing the battery fluid .................61

Fuse replacement .....................................62

Troubleshooting........................................63

CLEANING AND STORAGE .........................64

Cleaning.....................................................64

Storage ......................................................64

SPECIFICAITIONS .........................................66

T105(E) O/M-1 9/11/01 11:16 AM Page 4 (1,1)

Motorcycles are fascinating vehicles, which

can give you an unsurpassed feeling of

power and freedom. However, they also

impose certain limits, which you must ac-

cept; even the best motorcycle does not ig-

nore the laws of physics.

Regular care and maintenance are essen-

tial for preserving your motorcycle’s value

and operating condition. Moreover, what is

true for the motorcycle is also true for the

rider: good performance depends on being

in good shape. Riding under the influence

of medication, drugs and alcohol is, of

course, out of the question. Motorcycle rid-

ers - more than car drivers - must always

be at their mental and physical best. Under

the influence of even small amounts of al-

cohol, there is a tendency to take danger-

ous risks.

Protective clothing is as essential for the

motorcycle rider as seat belts are for car

drivers and passengers. Always wear a

complete motorcycle suit (whether made

of leather or tear-resistant synthetic materi-

als with protectors), sturdy boots, motorcy-

cle gloves and a properly fitting helmet.

Optimum protective wear, however, should

not encourage carelessness. Though full-

coverage helmets and suits, in particular,

create an illusion of total safety and protec-

tion, motorcyclists will always be vulnera-

ble. Riders who lack critical self-control run

the risk of going too fast and are apt to

take chances. This is even more dangerous

in wet weather. The good motorcyclist

rides safely, predictably and defensively -

avoiding all dangers, including those

caused by others. Enjoy your ride!

EUU75901

GIVE SAFETY THE RIGHT OF WAY

T105(E) O/M-1 9/11/01 11:16 AM Page 5 (1,1)

Much can be gained from the correct use and maintenance of a

motorcycle.

1THE CUSTOMERS CAN USE THE FULLEST

POTENTIAL OF YAMAHA MOTORCYCLES

2A MOTORCYCLE CAN KEEP ITS PERFORMANCE

CAPABILITY FOR A LONGER TIME

Comparison of wear on engine parts

With maintenance

Without

maintenance

100%

Perfect operative

Distance

Engine overhaul, cylinder

(piston, piston ring, cylinder, etc.)

condition

covered (km)

boring, piston ring change, etc.

GENERAL NOTE

T105(E) O/M-1 9/11/01 11:16 AM Page 6 (1,1)

3FUEL COST AND REPAIR EXPENSES CAN BE

KEPT TO A MINIMUM 4A MOTORCYCLE CAN DEMAND A HIGH PRICE

WHEN IT IS TRADED IN AS A USED PRODUCT

100%

With maintenance

Without

Distance covered (km)

Fuel consumption

maintenance

Distance covered (km)

Customer’s running cost

Without maintenance

With maintenance

Big repairs at higher expenses

(fuel cost plus maintenance and repair expenses)

T105(E) O/M-1 9/11/01 11:16 AM Page 7 (1,1)

EAA50000

DESCRIPTION

1. Tail/Brake light

2. Rear flasher light

3. Side cover

4. Fuel tank cap

5. Front flasher light

6. Kick starter

7. Rear brake pedal

8. Head light

9. Fuel tank

10. Seat lock

11. Shift pedal

12. Handlebar switch

13. Speedometer

14. Fuel gauge

15. Main switch/steering lock

16. Throttle grip

17. Front brake lever

18. Indicator light

19. Helmet holder

20. Starter lever

T105(E) O/M-1 9/11/01 11:16 AM Page 8 (1,1)

1. KEY IDENTIFICATION NUMBER:

2. FRAME SERIAL NUMBER:

3. ENGINE SERIAL NUMBER:

EAA61101

Identification numbers record

Record the key identification number,

frame serial number and engine serial

number in the spaces provided for assis-

tance when ordering spare parts from a

Yamaha dealer for reference in case the ve-

hicle is stolen.

EAA60000

MOTORCYCLE IDENTIFICATION

T105(E) O/M-1 9/11/01 11:16 AM Page 9 (1,1)
