EF6300iSDE
OWNER’S MANUAL
Read this manual carefully before operating this machine.
7CK-9-12 hyoshi 11.4.13 14:40 Page 1
Read this manual carefully before operating this machine. This manual
should stay with this machine if it is sold.
7CK-9-12 hyoshi 11.4.13 14:40 Page 2
INTRODUCTION
Congratulations on your purchase of your new Yamaha.
This manual will provide you with a good basic understanding of the operation and
maintenance of this machine.
If you have any questions regarding the operation or maintenance of your machine,
please consult a Yamaha dealer.
EF6300iSDE
OWNER’S MANUAL
© 2011 by Yamaha Motor Corporation, U.S.A.
1st Edition, February 2011
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, U.S.A.
is expressly prohibited.
Printed in Japan
P/N LIT-19626-01-73
7CK-28199-12_a 11.3.21 13:17 Page A-1
Particularly important information is distin-
guished in this manual by the following
notations.
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety mes-
sages that follow this symbol to avoid
possible injury or death.
A WARNING indicates a hazardous sit-
uation which, if not avoided, could
result in death or serious injury.
A NOTICE indicates special precau-
tions that must be taken to avoid dam-
age to the machine or other property.
TIP
A TIP provides key information to make
procedures easier or clearer.
NOTICE
WARNING
PLEASE READ AND UNDERSTAND
THIS MANUAL COMPLETELY BEFORE
OPERATING THE MACHINE.
TIP
9Yamaha continually seeks advance-
ments in product design and quality.
Therefore, while this manual contains
the most current product information
available at the time of printing, there
may be minor discrepancies between
your engine and this manual. If there
is any question concerning this manu-
al, please consult a Yamaha dealer.
9This manual should be considered a
permanent part of this engine and
should remain with this engine when
resold.
* Product and specifications are subject to
change without notice.
WARNING
IMPORTANT MANUAL INFORMATION
7CK-28199-12_a 11.3.21 13:17 Page A-2
CONTENTS
SAFETY INFORMATION ........................1
Exhaust fumes are poisonous ..............2
Fuel is highly flammable and
poisonous .............................................2
Engine and muffler may be hot.............2
Electric shock prevention......................3
Connection notes..................................4
Connection ...........................................4
Extension cord notes ............................4
LOCATION OF IMPORTANT
LABELS...................................................5
DESCRIPTION ........................................7
Control panel ........................................7
CONTROL FUNCTION............................8
Engine switch .......................................8
Oil warning light (red) ...........................8
AC protector .........................................9
Economy control switch........................9
G.F.C.I. receptacle .............................10
Voltage select switch ..........................11
Hour meter..........................................12
Power meter .......................................12
AC pilot light (green)...........................12
Overload indicator light (red) ..............13
Fuel tank cap ......................................13
Fuel cock knob ...................................14
Ground (earth) terminal ......................14
Caster lock lever.................................14
PREPARATION.....................................15
Fuel.....................................................15
Engine oil............................................16
Battery preparation .............................17
PRE-OPERATION CHECK ...................19
Pre-operation check ...........................19
OPERATION..........................................20
Starting the engine .............................20
Stopping the engine............................22
Connection .........................................23
Application range................................25
PERIODIC MAINTENANCE ..................27
Maintenance chart ..............................27
Spark plug inspection .........................29
Carburetor adjustment........................31
Engine oil replacement .......................31
Air filter ...............................................32
Muffler screen and spark arrester.......34
Fuel tank filter .....................................36
Battery ................................................37
Recommended battery .......................37
Fuse replacement...............................38
G.F.C.I. receptacle test.......................39
STORAGE .............................................40
Drain the fuel ......................................40
Engine ................................................42
Battery ................................................43
TROUBLESHOOTING ..........................44
SPECIFICATIONS.................................47
Dimensions.........................................47
Engine ................................................47
Generator ...........................................47
Battery ................................................47
CONSUMER INFORMATION................48
Identification number records .............48
Machine identification .........................48
EXHAUST EMISSION CONTROL
SYSTEM AND COMPONENTS.............49
WIRING DIAGRAM ...............................51
YAMAHA MOTOR CORPORATION,
U.S.A.
EF SERIES GENERATORS
3-YEAR LIMITED WARRANTY............53
YAMAHA OUTDOOR POWER
EQUIPMENT
CALIFORNIA EVAPORATIVE
EMISSION CONTROL
WARRANTY STATEMENT ..................56
YAMAHA MOTOR CORPORATION,
U.S.A.
SMALL OFF ROAD ENGINES
CALIFORNIA EMISSION
CONTROL WARRANTY.......................57
YAMAHA EXTENDED SERVICE
(Y.E.S.)..................................................61
7CK-28199-12_a 11.3.21 13:17 Page A-3
– 1 –
SAFETY INFORMATION
9This generator is not designed for on-board use.
Do not use it while installed on the vehicle.
9Do not modify the generator or use it with its parts
removed.
9Do not allow children to operate the generator.
1
11
794-7CK
9Be sure to carry the generator only by its carrying
handles.
1Carrying handles (shaded)
7CH-002
9Do not place any obstacles on the generator.
7CK-28199-12_a 11.3.21 13:17 Page 1
–2 –
741-7XFa
741-7XFb
741-7XFc
741-7XFd
741-7XFe
741-7XFf
Exhaust fumes are poisonous
9Never operate the engine in a closed area or it
may cause unconsciousness and death within a
short time. Operate the engine in a well ventilated
area.
Engine and muffler may be hot
9Place the generator in a place where pedestrians
or children are not likely to touch the generator.
9Avoid placing any flammable materials near the
exhaust outlet during operation.
Fuel is highly flammable and poisonous
9Always turn off the engine when refuelling.
9Never refuel while smoking or in the vicinity of an
open flame.
9Take care not to spill any fuel on the engine or
muffler when refueling.
9Do not leave the generator inside the vehicle or in
the trunk.
9If you swallow any fuel, inhale fuel vapor, or allow
any to get in your eye(s), see your doctor immedi-
ately. If any fuel spills on your skin or clothing,
immediately wash with soap and water and
change your clothes.
9When operating or transporting the generator, be
sure it is kept upright. If it tilts, fuel may leak from
the carburetor or fuel tank.
7CK-28199-12_a 11.3.21 13:17 Page 2
–3 –
741-7XFg
a
741-7XFi
9Keep the generator at least 1 m (3 ft) from build-
ings or other equipment, or the engine may over-
heat.
a1 m (3 ft)
9Do not operate the generator with a dust cover or
other objects covering it.
9When covering the generator, be sure to do so
only after the engine and muffler have completely
cooled down.
Electric shock prevention
9Never operate the engine in rain or snow.
7
741-7XFh
741-7XFj
9Never touch the generator with wet hands or elec-
trical shock will occur.
9Connect the ground lead of the generator to the
ground (earth) terminal and connect the end to the
ground electrode buried in the ground.
1Ground (earth) terminal
1
763-7CKa
7CK-28199-12_a 11.3.21 13:17 Page 3
–4 –
1
2
1
2
741-7XFk
Connection notes
9Avoid connecting the generator to commercial
power outlet.
9Avoid connecting the generator in parallel with any
other generator.
1Correct
2Incorrect
Connection
Before the generator can be connected to a build-
ing’s electrical system, a licensed electrician must
install an isolation (transfer) switch in the build-
ing’s main fuse box. The switch is the connection
point for generator power and allows selection of
generator or main line power to the building. This
will prevent the generator from charging the main
power line (backfeeding) when the main power
supply has failed or has been turned off for line
repair. Backfeeding can electrocute or injure line
maintenance personnel. Also, generator and build-
ing electrical system damage can occur when nor-
mal operating power returns if unit is used without
an isolation switch.
WARNING
Extension cord notes
Extension cords should be protected by a tough flexi-
ble rubber sheath (IEC 245) or the equivalent to with-
stand mechanical stresses.
7CK-28199-12_a 11.3.21 13:17 Page 4
–5 –
LOCATION OF IMPORTANT LABELS
Please read the following labels carefully before oper-
ating this generator.
TIP
Maintain or replace safety and instruction labels, as
necessary.
1
2
4673 5
12
HOT EXHAUST
7WL-28176-10
OIL
EF6300iSDE
AC output 60Hz
Rated 5500VA
Phase Single
Fuel
Gasoline
YAMAHA MOTOR POWERED PRODUCTS CO.,LTD.
MADE IN JAPAN
240V/120V
7CK-24164-10
7CK-28199-12_a 11.3.21 13:17 Page 5
