Xtreme X-300 Manuel utilisateur

Page

X-300

Electric Scooter

PLEASE BE SAFE WHEN RIDING

ALWAYS WEAR AHELMET AND OBEY ALL LAWS!

X-Treme TM Electric Scooters

Page

BATTERY MAINTENANCE and

CHARGING INSTRUCTIONS

1. You MUST charge completely prior to initial use. (Follow

charging instructions in your Product Handbook)

2. Charge immediately after each use.

3. Charge before storage. You must charge every 30 days if not

in use.

4. Charge the unit for 6-8 hours or until the light on the charger

turns red & green.

5. DO NOT allow this unit to deep discharge the battery.

6. For safety purposes, DO NOT charge for over 8 hours.

7. Turn the unit OFF when not in use.

This PRODUCT IS NOT INTENDED FOR EXTREME or

OFF-ROAD Use! Please take care of your scooter!

DO NOT JUMP or ABUSE THIS PRODUCT!

DO NOT RIDE IN WET/ICY CONDITIONS!

Failure to follow these instructions will

VOID YOUR WARRANTY!

IMPORTANT

Failure to follow these INSTR

UCTIONS will

VOID YOUR WARRANTY!

Page

WARNING

This product does not conform to Federal Motor Vehicle Standards and is not

intended for operation on public streets, roads or highways. Serious injury can

result from the unsafe operations of this product. Operator can minimize these

risks by using certain safety equipment such as: safety helmet, goggles, gloves,

elbow and kneepads and appropriate footwear.

DO NOT operate this product in traffic, on wet, frozen, oily or unpaved surfaces or

under the influence of drugs and/or alcohol. Avoid uneven surfaces, potholes,

surface cracks and obstacles.

DO NOT use a water hose to clean this product. See Product Handbook for more

information.

This product is recommended for riders 14 YEARS OF AGE and older.

SAFETY

Persons without excellent vision, balance, coordination, reflex, muscle and

bone strength and good decision-making capabilities should not use this

product.

Minors without adult supervision should not use this product.

Persons unwilling or unable to take responsibility for their own actions should

not use this product.

The user of this product assumes ALL risks associated with its use. To

minimize these RISKS, the user must wear safety helmet, goggles, gloves,

elbow and kneepads and appropriate footwear.

This product is ELECTRIC! DO NOT ride this product in wet conditions,

puddles or rainy weather.

IMPORTANT

PLEASE READ THIS BEFORE USING THIS PRODUCT

READ THIS FIRST!

Page

SAFETY GUIDE

The recommended minimum age for riding this scooter is 14 years old.

To avoid damage to the motor and footplate, do not overload the scooter.

Never ride with more than one person.

Inspect your scooter thoroughly before each use for loose or missing parts.

Avoid unintentional starts by turning the scooter off while not in use.

To avoid the risk of a short circuit inthe electrical parts, do not use your Electric

scooter in the rain and never spray or wash off your scooter with water.

Do not place the battery near fire or heat.

To avoid damage to the battery, do not use the charger if it has been damaged

in any way.

Keep hands, face, feet and hair away from all moving parts.

Do not touch the motor or wheels while they are rotating.

Brakes are designed to control speed as well as stop the scooter. Practice

braking for proper slowing down and smooth stops.

Maintain your scooter as recommended in this Product Handbook.

Use only quality replacement parts as recommended by the manufacturer.

Inspect the entire scooter prior to each use. Replace any part that is cracked,

chipped or damaged before use.

*NEVER ALLOW CHILDREN TO OPERATE THE SCOOTER WITHOUT ADULT

SUPERVISION.

*NEVER ATTEMPT TO OPERATE THE SCOOTER WHILE UNDER THE

INFLUENCE OF ALCOHOL.

If a situation arises that is not covered in the manual,

proceed with caution and use good judgment.

QUICK

REFERENCE

SAFETY GUIDE

Page

TABLE OF CONTENTS

IMPORTANT INFORMATION/QUICKREF GUIDE….………………..……..2-4

TABLE OF CONTENTS………………….…………….…………………………5

PACKAGE CONTENTS,ASSEMBLY & GETTING STARTED……………….6

RIDING/BRAKING…………………………………………..……………….……8

FOLDING AND STORAGE……….………………..……………………...……..8

BRAKING SYSTEM & ADJUSTMENTS.………………………….……………9

TIRE PRESSURE………………………………………………………….…….10

MAINTENANCE………………………………………………..………..……10-12

TROUBLESHOOTING GUIDE……………………………………………….…12

SUPPORT INFORMATION………………………………………..……….……13

DO NOT RETURN TO STORE!

Do not use this vehicle for the first time until you have inflated the tires to the correct PSI

and completely charged the battery. Failure to follow these instructions may damage your

vehicle and void your warranty.

CALL TOLL FREE OR GO ONLINE

1-800-772-3852 www.x-tremescooters.com/support/

For General Information or Parts Visit www.x-tremescooters.com

Page

PACKAGE CONTENTS

Your scooter comes with the following items in the box. Please locate all of the

following:

1. X-300 Scooter

2. 24V Battery Charger

3. Tool Kit & User Manual

4. Seat

5. Seat Post & Clamp

GETTING STARTED

Please read and understand these instructions and the OPERATING

PROCEDURES section, prior to starting or riding your scooter!

Assembly

1. Carefully remove the scooter from the box.

2. To unfold the scooter, begin by pressing

down on the FOLDING HANDLE with one

hand while gently pulling up on the

handlebars with the other.

3. Fully extend the handlebars to their upright

position until you feel the mechanism lock

into place.

4. Attach the handlebars by first loosening the

4 Allen head bolts and removing the top of

the handlebar cap. Lay the handlebar on

top of the handlebar bracket being sure to

orient the bars in the correct riding position

with the throttle on the rider’s right side.

Secure the handlebars to the post by

tightening the bolts on the clamp with the

enclosed Allen wrench as shown.

5. Secure the hand brakes in place by using

the provided Allen Wrench to first loosen

the tension bolts. Adjust the levers to a

comfortable position and tig

hten the bolts.

*BE CAREFUL NOT TO PULL ON THE

CABLES!

Page

Assembly – Cont:

6. Check below the foot plate to ensure the

motor connector is plugged into the

controller. If not, connect the two ends

together as shown.

7. Attach the seat post to the seat post

receiver, then attach the clamp to the top of

the seat post. Pull the upper seat post to

the desired position and tighten the clamp

securely.

8. Attach the seat to the upper seat post and

tighten the seat bolts as shown.

9. FAILURE TO PROPERLY TIGHTEN AND

ALIGN THE SEAT COULD RESULT IN

RIDER INJURY. DO NOT ATTEMPT TO

RIDE WIHTOUT PROPER SEAT

ADJUSTMENT AND ENSURING SEAT

BOLTS ARE SECURE & TIGHT!

Page

CHARGING

Your scooter comes partially charged out of the carton. You must charg the unit for 6-8

hours prior to it’s first use. We also recommend charging your scooter after each use

and prior to storage.

WARNING: Do not allow your scooter to go into deep discharge, as this will damage the

batteries.

RIDING

1. Make sure that all of the exposed bolts and screws are tightened.

2. Raise the kickstand to its upright position.

3. Push the on/off switch (located on the left handlebar) to the ON position.

4. Put one foot on the deck of the scooter while pushing off with the other foot, gently

rotate the THROTTLE GRIP, on the right side of the handlebars. The scooter will

begin to move on its own power.

**Your scooter has a variable speed hand throttle. You can control the speed of your

scooter by the amount of pressure you use when rotating the hand throttle. The more

you rotate, the faster you will go.

STOPPING & BRAKING

1. To brake, release the THROTTLE GRIP and depress the BRAKE LEVERS (on the

left/right side of the handlebars. Depressing the brake will disengage power to the

motor. When the unit feels like it is loosing power or not accelerating to full speed,

the scooter is ready to be re-charged.

1. Make sure unit is turned off.

2. Open the charging socket cover

located on the right side of the

scooter frame, under the footplate.

Locate your Battery Charger.

Find the charger socket end that

has a three-prong socket and plug

it into the scooter.

4. Next, plug the AC plug into a wall

outlet.

Charging Indicators:

RED: Charging

RED & GREEN: Fully charged and

ready for use

Page

NOTE: If the on/off switch is left in the ON position for more than 10-15 minutes without

moving, Smart Power will shut itself OFF. To reset, turn the unit OFF, wait a few seconds

and then switch it back ON again.

FOLDING & STORAGE

When you are done riding the scooter you can fold it down for compact storage and

transportation. First remove the seat post and seat, then using one hand, push down on

the folding handle while gently pushing down on the handlebars. BE CAREFUL NOT TO

HIT YOUR HEAD WITH THE HANDLEBAR. Push down until you feel the mechanism

lock into the down position.

BRAKING SYSTEM

The scooter uses a pinch braking system for the front, They are both activated by a hand

brake lever on the left and right side of the handlebar. Squeezing the hand brake lever

with your left hand activates the rear brake. Squeezing the hand brake lever with your

right hand activates the front brake. Make sure to release the HAND THROTTLE GRIP

when engaging the brakes. Your scooter is equipped with switches on each brake lever

that will disengage power to the motor when the brake levers are depressed.

Practice braking on a smooth, dry surface to get used to the feel of the braking system.

Braking distance is affected by wet conditions and loose and uneven riding surfaces.

Adjusting the Brakes

The Brakes on the scooter should come fully adjusted from the factory.

However, it may be necessary to adjust the brakes from time to time.

To adjust the front brakes:

For brakes that are adjusted too loose:

1. Adjust the tension screw on the left

hand brake lever by rotating it

counter-clockwise until the wheel spins

freely.

For brakes that are adjusted too tight:

2. Tighten the tension screw on the

left hand brake lever by rotating it

clockwise until the wheel has a

slight drag.

For Further Front Brake Adjustment

3. Locate the adjustment screw on the front

brake assembly (located above the front

wheel).

Tighten or loosen as necessary.

Page

SQUEAKY BRAKES

The brakes may squeak before they are broken in. This is normal and will not affect the

function or performance of the brakes. With continued use the squeak should go away.

TIRE PRESSURE

The tire must be inflated to a maximum of 50 P.S.I. It is also recommended to use a tube

additive like Slime, available from any motorcycle shop, to avoid inconvenient punctures.

Empty all air from the tire, prior to loosening the bolt to split the rim.

MAINTENANCE

RECOMMENDED TOOLS

To adjust and service the scooter you will need the following tools:

Allen Wrenches: 3/4/5/6 mm

Wrenches: 10/13/13 mm Open end wrench

Large Adjustable Crescent Wrench

Philips Head Screwdrivers

Oil, Grease or Lubricant

ADJUSTING THE HEAD UNIT

The head unit will come adjusted from the factory. However, riding on rough terrain and

general use may cause the head unit to become loose over time. It may be necessary to

adjust the head unit from time to time.

To adjust the head unit:

1. Rotate the handle bar as far right as it will

go to expose the HEAD UNIT. (see fig

left)

2. Using a large adjustable wrench, gently

turn the BEARING LOCK clockwise to

tighten. *DO NOT OVER TIGHTEN OR

IT WILL DAMAGE THE BEARINGS.

Table des matières

Autres manuels Xtreme Scooter

Xtreme

Xtreme X-360 Manuel utilisateur

Xtreme

Xtreme XG-499 Manuel utilisateur

Xtreme

Xtreme X-600 Manuel utilisateur

Xtreme

Xtreme X-250 Manuel utilisateur

Xtreme

Xtreme X-010 Manuel utilisateur

Xtreme

Xtreme X-400 Manuel utilisateur

Xtreme

Xtreme XM-3000 Guide de dépannage

Xtreme

Xtreme XB-420M Manuel utilisateur

Xtreme

Xtreme XMB-320 Manuel utilisateur

Xtreme

Xtreme XP-707 Manuel utilisateur

Xtreme

Xtreme XM-5000Li Guide de dépannage

Xtreme

Xtreme XG-550 Manuel utilisateur

Xtreme

Xtreme X-370 Manuel utilisateur

Xtreme

Xtreme XR-302 Manuel utilisateur

Xtreme

Xtreme METRO EXPRESS Manuel utilisateur

Xtreme

Xtreme X-500 Manuel utilisateur

Xtreme

Xtreme XB-420M Manuel utilisateur

Xtreme

Xtreme XG-470 Manuel utilisateur

Xtreme

Xtreme X-140 Manuel utilisateur

Xtreme

Xtreme Rubicon 48V Manuel utilisateur

Xtreme

Xtreme XG-565 A-Blaze Signature Series Manuel utilisateur

Xtreme

Xtreme XT300 Manuel utilisateur

Xtreme

Xtreme XB-300SLA Manuel utilisateur

Xtreme

Xtreme XMB-420 Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
