Xtool D1 Pro Manuel utilisateur
04
xTool D1 Pro 40 W
Laser Module Kit
KD010553000
04
xTool D1 Pro 40 W
Laser Module Kit
KD010553000
xTool D1 Pro 40 W laser module kit provides two color options. This user manual
uses the golden red version to describe how to modify and set up your machine.
List of items
Modify your xTool D1 Pro
Set up the machine
Use the focal length setting piece for
the infrared laser module
Clean the laser module
Instructions
03
06
38
43
46
51
01 02
03
List of items
04
Middle platePosition limit piece A Position limit piece B
Main control board Laser module Position limit control board
Power adapter Parts storage boxCable tie pack
Screwdriver Focal length
setting piece
Hex key
Screw M4*16 Screw M4*25
Cylindrical head
screw M3*6
05 06
Modify your xTool D1 Pro
Sharp-nose pliers
1. Remove the original middle plate
With this xTool D1 Pro 40 W laser module kit, you can modify
your xTool D1 Pro into a 40 W one.
Cylindrical head
screw M3*8
Round head
screw M3*10
Flat head
screw M3*8
07 08
09 10
12
11
14
13
2. Replace the position limit control board
If the position limit control board cannot be removed due to screw slipping, use the
sharp-nose pliers to remove it. Exercise caution when doing this, protecting yourself
from hurt.
16
15
3. Replace the position limit pieces
18
17
4. Replace the main control board
(1) Remove the original main control board
The largest processing area varies according to laser module. You need to set the
position of position limit piece A, accordingly.
(1) (3)(2)
For laser module 40 W For laser module 20 W For laser module 10 W & 5 W
