Xtool Anycut KNC81 Manuel utilisateur
Shenzhen Xtooltech Intelligent Co., LTD
Anycut KNC81
Key Cutting Machine
User Manual
I
Please read this user manual carefully before using Anycut
KNC81 Key Cutting Machine. When reading the manual, please
pay attention to the words “Note” or “Caution” and read them
carefully for appropriate operation.
TRADEMARKS
is a registered trademark of Shenzhen Xtooltech
Intelligent CO., LTD.
In countries that the trademarks, service marks, domain names,
logos and the name of the company are not registered, Xtool
claims that it still reserves the ownership of the unregistered
trademarks, service marks, domain names, logos and the
company name. All other marks for the other products and the
company’s name mentioned in the manual still belong to the
original registered company.
You may not use the trademarks, service marks, domain names,
logo and company name of Xtool or other companies mentioned
without written permission from the trademark holder.
Xtool reserves the right for the final interpretation of this manual
content.
II
COPYRIGHT
Without the written consent of Shenzhen Xtooltech Intelligent Co.,
Ltd., any company or individual shall not copy or backup this
operation manual in any form (electronic, mechanical,
photocopying, recording or other forms).
DECLARATION
This manual is designed for the usage of Anycut KNC81 Key
Cutting Machine, and provides operating instructions and product
descriptions for users of the Anycut KNC81 Key Cutting Machine.
No part of this manual can be reproduced, stored in a retrieval
system or transmitted, in any form or by any means (electronic,
mechanical, photocopying, recording, or otherwise), without the
prior written permission of Xtool.
Use the device only as described in this manual. Xtool is not
responsible for any consequences of violating the laws and
regulations caused by using the product or its data information
Xtool shall not be liable for any incidental or consequential
damages or for any economic consequential damages arising from
the accidents of individual users and the third parties, misuse or
abuse of the device, unauthorized change or repair of the device,
III
or the failure made by the user not to use the product according to
the manual.
All information, specifications and illustrations in this manual are
based on the latest configurations and functions available at the
time of printing. Xtool reserves the right to make changes at any
time without notice.
OPERATION INSTRUCTIONS
To avoid personal injury and/or machine damage, please
make sure that you have read this manual carefully and follow
the following safety precautions:
Make sure that you are using this machine under a safe
environment.
Please close the protection cover when the machine is
processing.
Do not put hair, hand, clothes, other tools etc. near machining
area when processing.
When processing, lease pay attention to the operations of the
machine and do not leave it alone.
Please make sure the flat side of the plug is on the top when
charging. The machine will ring an alarm if plugged in a wrong
way.
Do not use a power socket that’s damaged or loosened.
IV
If you are not using the machine for a long time, please pull out
the power supply.
Do not put this machine into humid, greasy, or dusty areas.
Do not put any tools or containers on the machine.
Please put this machine on a level and steady surface.
Please make sure the machine is dry and clean.
When abnormalities happened, shut down the power
immediately.
CAUTIONS!
Avoid shaking or dismantling the unit as it may damage the
internal components.
Do not use hard or sharp objects to touch the LCD screen;
Do not use excessive force;
If necessary, calibrate the screen before testing to ensure the
accuracy of LCD performance.
Keep the main unit away from strong magnetic fields.
AFTERSALES-SERVICES
E-Mail: supporting@xtooltech.com
Tel: +86 755 21670995 or +86 755 86267858 (China)
Official Website: www.xtooltech.com
i
CONTENT
TRADEMARKS....................................................................................................................................... I
COPYRIGHT...........................................................................................................................................II
DECLARATION..................................................................................................................................... II
OPERATION INSTRUCTIONS...........................................................................................................III
CAUTIONS!...........................................................................................................................................IV
AFTERSALES-SERVICES.................................................................................................................IV
1 GENERAL INTRODUCTION........................................................................................................ 3
KNC81 Main Unit................................................................................4
Front View of Machine
.....................................................................................................................
4
Back View of Machine
......................................................................................................................
5
Clamp................................................................................................... 6
Technical Specifications................................................................... 7
2 GETTING STARTED......................................................................................................................8
How To Install..................................................................................... 8
Installing Cutter & Probe
.................................................................................................................
8
Installing Clamp
................................................................................................................................
9
Changing Sides of the Clamp
.......................................................................................................
10
Introduction To the Clamp
............................................................................................................
10
Guide to Activation...........................................................................13
Main Interface...................................................................................17
Android system
...............................................................................................................................
17
APP Menu
.......................................................................................................................................
21
Navigation Buttons
.........................................................................................................................
22
3 PROCESS......................................................................................................................................23
ii
Machine Information........................................................................23
Process Settings.............................................................................. 24
Height Level Adjustment.................................................................24
Motor Test......................................................................................... 26
Probe & Cutter Sensor Test...........................................................27
4 UPDATE.........................................................................................................................................28
5 KEY CUTTING.............................................................................................................................. 29
Vehicle Database.............................................................................29
Key Code Processing......................................................................31
All Key Lost Search......................................................................... 32
Quick Copy........................................................................................34
6 SETTINGS..................................................................................................................................... 36
7 REMOTE SUPPORT....................................................................................................................37
8 MAINTENANCE INSTRUCTIONS............................................................................................ 38
SHENZHEN XTOOLTECH INTELLIGENT CO., LTD................................................................... 39
3
1 GENERAL INTRODUCTION
Anycut KNC81 key cutting machine is a professional device that is
customized for global locksmith communities. It’s portable,
lightweight, fast and accurate, designed to cut various car
mechanical keys precisely.
As an innovative portable key cutting machine, Anycut has these
following features:
Control via tablet & Integrated database.
Portable, fast & accurate.
Long battery life with high-energy lithium battery.
Support inner milling/side milling/face milling/Tubular key and
more.
Equipped with probe & cutter.
Supports OTA update.
4
KNC81 MAIN UNIT
The main unit of the Anycut is the key cutting machine itself. It is
used to finish the cutting process.
FRONT VIEW OF MACHINE
1Protection Cover: Close it to avoid debris spattering around
when the machine is working.
The motor will not activate when you leave the protection cover up.
2Tablet: You can touch the screen and finish all operations.
3Tablet Holder: Used to support the tablet, flexible adjustment
of the tablet height as needed.
4Probe & Cutter Holder: Install the probe and the cutter into
these holders.
1
3
2
5
4
6
7
8
5
5Emergency Start/Stop Button: Rotate the button clockwise to
start the machine, push the button to emergency shut down the
machine.
6Clamp Holder: Used to hold and lock the clamp. It’s controlled
by X/Y-axis motors for cutting keys.
7Debris Tray: Used to collect debris when cutting keys.
Please clean the tray regularly.
8Tool Tray: Used to storage tools or key blanks.
BACK VIEW OF MACHINE
9Charging Port: Works as a power supply for the machine, and
also charge the battery inside.
Make sure the flat side of the socket is on the top when inserting.
10 Nameplate: Shows information, serial number and notifications
of the machine.
⑩
9
