XtendLan XL-RAID-SATA Manuel utilisateur



XL-RAID-SATA

Data Backup System

User’s Guide

Chapter 1 Introduction ...........................................................1

1-1 Functions and Features.......................................................... 1

1-2 Product Specification ............................................................ 2

Chapter 2 Hardware Installation...........................................3

2-1 Contents in the product package ........................................... 3

2-2 System Requirement ............................................................. 4

2-3 Operation Requirement and Caution..................................... 4

2-4 Detail Description ................................................................. 5

2-5 Installing Hard Drive.............................................................6

2-5 Installing Hard Drive.............................................................7

2-6 Connecting XL-RAID-SATA to your computer ................. 10

Chapter 3 How to Operate XL-RAID-ATA........................13

3-1 Setting the Hard Drive Array Mode .................................... 13

3-2 Computer Set Up................................................................. 15

3-3 LCD Display Message After Turning the Machine On....... 15

Chapter 4 System Maintenance............................................17

4-1 Hot Swap & Auto Rebuilding ............................................. 17

4-2 Firmware Update................................................................. 19

Chapter 5 Installing RAIDGuide.........................................22

5.1 Software Introduction .......................................................... 22

5.2 Installing RAIDGuide.......................................................... 23

Appendix ATrouble Shooting Q&A

Appendix B Pin Definitions for each connection port

Appendix C LCD Display Symbol Definition Chart

Chapter 1 Introduction

-1

Functions

and

Features

The XtendLan disk array XL-RAID-SATA provides both RAID 1 and

RAID 0 functions with its independent disk array microprocessor chips.

It is considered as the best choice for storage expansion and instant

online backup.

 No hardware driver needed and applicable to all operating

systems

XL-RAID-SATA is equipped with the standard SATA

Type 1 and ATA133 connection interfaces. The XL-RAID-

SATA system not only possesses high transfer rate but also

does not require specific system drivers. Therefore, it can

be simply applied to any computer system without any

concerns about incompatibility.

 Supports both SATA and E_IDE hard drive

XL-RAID-SATA comes with removable hard drive

carrier that is compatible with these two types of enclosure

module. It can be applied to hard drives with E_IDE interface

or to the SATA hard drives.

 Hot Swappable Drive

Under the mirroring mode (RAID 1), when one hard drive is

damaged, XtendLan allows the system to switch hard drive

without pausing the system operations.

 Auto Data Rebuilding

Under the mirroring mode (RAID 1), XL-RAID-SATA will treat

one hard drive as the source hard drive and the other as the

target hard drive. Therefore, it does not require any specific

command or system interruption to rebuild the hard drive while

the computer system is still running.

 Hard Drive Backup

Under the mirroring mode (RAID 1), XtendLan can serve as

hard drive backup. It can also be used as system backup or

off-line data backup to avoid any virus attack.

 LCD Display Screen

The LCD display screen will allow users to monitor and to

maintain the system operations.

 System Failure Buzzer

When system failure occurs, XtendLan will not only display the

damage status on the LCD display screen but will also generate

system alarm as well. The XtendLan system also utilizes

Windows version graphic user interface monitoring software

which will allow remote maintenance via internet. XtendLan

will notify system maintenance technicians once malfunction is

detected for immediate repair services.

 Aluminum Alloy Frame

The aluminum alloy frame gives strong and durable structure

and serves as the best heat sink.

1-2

Product

Specification

Disk Array Hardware Include disk array chips with individual

microprocessor

Disk Array Type: RAID 0,1

Connection Interface: SATA Type1 and ATA133

Connection Transfer Rate: Up to 150 MB/ Up to 133 MB Hard drive

Interface: SATA Type 1 or ATA 133

Hot Swappable Drive: 2 x (1 inch IDE Hard Drive)

Cooling Fans: 5.2 cm ball bearing fan

Operating Temperature: 0 ～55°C

Power Input: 12V 4 A, 5V 4 A

Dimension (MM): 146(width) x 238(length) x 85(height)

Weight: 4kg(Hard Drive excluded)

Aluminum Alloy Frame: Yes

LCD Display: Yes

Online Hot Swappable Drive: Yes

Auto Rebuild: Yes

System Driver Needed: No

Certificates: CE, FCC Certificate

Chapter

Hardware

Installation

2-1

Contents

the

product

package

The XL-RAID-SATA package contains:

Object Quantity

XL-RAID-SATA 1

RS232 Cable 1

Removable Carriers 2

User’s Guide 1

RAIDGuide CD 1

Attachment Pack 1

(includes 6#-32 screws x 8 pcs , Key for keylock x 2 )

2-2

System

Requirement

 Hardware Requirement

1. Computers or servers with SATA Type 1 or E_IDE interface.

2. Hard drive with SATA Type 1 or E_IDE interface.

3. The computer or server must run on the Windows system and

has RS232 port to install the RAIDGuide GUI software.

2-3

Operation

Requirement

and

Caution

1. XL-RAID-SATA’s brilliant design allows the user to

simultaneously utilize two hard drives manufactured by

different companies. However, if the user expects better

efficiency, we strongly recommend the users to use hard

drives manufactured by the same manufacturers.

2. Please carefully select the mode of disk array (RAID 0 or RAID

1) prior to usage. Unless high transfer rate and large storage

capacity is needed, otherwise, please use the manufacturer’s

default mirror setting (RAID 1). Changing the disk array mode

after the system setting is completed will result in complete loss

and damage to the stored data.

3. Since the system uses more stringent factors to determine the

disk corruption in the hard drive, please use noncorrupted hard

drive with minimum storage capacity of 20 GB.

4. Please set the first and second hard drive (IDE drives) in XL-

RAID-SATA

to MASTER or Single Drive mode. Otherwise, the system will

not be able to detect the hard drives.

5. The SATA and E_IDE interfaces can not be used simultaneously.

If the system detects the E_IDE interface, the system will prefer

to use the E_IDE interface.

6. The XL-RAID-SATA had undergone strict hard drive

compatibility test. The result shows that it is compatible with

most hard drives on the market such as Maxtor, Western

Digital, Seagate, Fujitsu, Hitachi, and etc. However, due to the

new types of hard drives appearing on the market, if your

hard drive is not compatible with the system, please contact

us at www.xtendlan.com or download the latest firmware

updates.

The XL-RAID-SATA is equipped with a 5.2 cm ball bearing

cooling fan that will provide effective cooling for the 7200 rpm hard

drive. We highly recommend using computer chassis with effective

cooling design to avoid disk array crashing due to ineffective

cooling.

2-4

Detail

Description

Front View

Rear View

2-5

Installing

Hard

Drive

1. Insert key to the lock located at the right side of the tray handle.

Turn the key clockwise to open the tray handle.

2. Pull the handle of the removable hard drive carrier.

3. Remove the removable hard drive carrier.

4. Connect the IDE cables on the removable hard drive carrier to

the pins on the hard drive.

5. Secure the hard drive on the removable hard drive carrier by

the screws provided in the accessory pack.
