XtendLan OUTIRDVS620FR-42 Manuel utilisateur

OUTIRDVS620FR-42

Face Recognition Multifunction Megapixel HD Smart Camera

Operation Manual

1. Main features:

（1）1/3 inch SONY Super HAD CCDⅡ

（2）Sony New HD CCD

（3）Face Recognition: Face Detection / multi-target tracking motion

detection / tracking Zoom / Intelligent Face tracking / warning zone of

detection / capture Archive

（4）Automatic intelligent analysis multi-target moves and face tracking.

Electronic fence one/dual-way throughout to alarm

（5）Supports digital through the fog / HLC / BLC / Smart IR function

（6）Supports 2 languages

（7）Use TF card capture, storage function, maximum support 32G

（8）Photo Playback, Auto search ,face zoom

（9）Support communication settings (RS485), Pelco_D protocol

（10）Support alarm equipment .

2. Function description

(1) Button

①UP

②Down

③Left

④Right

⑤Menu

(2) Menu mode

2.1 When turned on, press "MENU" button to enter the menu mode. upwards

to pull the "UP" key to up-move / analog plus / mode switching; downwards

to pull"DOWN" key to down- move / analog minus / mode switching;

Leftwards to pull "L" key to return to the previous directory; Rightwards to

pull "R" key for entry into the next directory;

2.2 Exit: Press "MENU" button to pop-up exit menu mode. upwards to pull

"UP" key to leave; downwards to pull "DOWN" key to return key; Leftwards to

pull "L" key to restore the factory settings; Rightwards to pull "R" key to save

and exit.

2.3 The operation and settings of RS485 and PTZ keyboard: operation

command used to record RS485 keyboard can record various different brands

of commands. Usage: select the keys [KEY FUNC] you want to record by the

buttons on the machine, such as MENU, UP ..., then press [KEY SET ] to start

recording, the menu will be displayed on waiting, then press the RS485

keyboard keys, and then press the enter button on the machine, then displays

OK, indicating the end of the record of this button.

2.4 Intelligent Monitoring: multi-target tracking, face book, electronic fences,

motion detection, digital zoom, privacy masking, close the Smart Monitoring,

these seven item represent a separate product function, that when you select

"O" ring stays in that item, indicating the product function at this time. Such

as "O" ring stays in face book entry, save and exit, it means that the product

at this time is the human face capture function. So that the user can

according to actual situation to select.

2.5 alarm devices: burglar alarm trigger line is divided into: ALARM +,

ALARM-, this two trigger lines correspondingly connected to the input of the

alarm system.

Set whether needs to output an alarm or not when motion is detected,

"Alert level" to choose high, low, off; high is high output (3V), low output is

low (0V), off means the alarm signal output is closed. Set high or low

depending on an external alarm system of itself trigger voltage is high or low.

3. Menu function settings

1. Intelligent monitoring

1.1 Multi-target tracking: the use of advanced image detection, identification

and tracking technology, with precision motion control system to realize the

quick succession tracking capture of multi-motion target in big scene. Mainly

used in public places, residential, factories, campuses, shopping malls and so

on.

Magnification

0～5[0]

Set automatic magnification

Sensitivity

-4～4[0]

Set detection sensitivity, the larger

the number is, the more sensitivity is

Intelligent tracking

ON,OFF(OFF)

Set if enables intelligent tracking

Frame follow

ON,OFF(OFF)

Set if enables frame follow

Alert level

High,low,off(off)

Set if output alarm when detect the

object motion, high is high output,

low output is low .Set high or low

depending on an external alarm

system of itself trigger voltage is high

or low.

Alarm seconds

0-3600 [10]

Set the alarm time in unit of seconds

while detecting object motion

Manually warning area

ON,OFF(OFF)

Set if needs to use manually warning

area range

Warning area selected

1、2[1]

Select warning areas needed to set,

max.2

Set warning area

Press the Right key

then click setting

Press Enter key to switch to the

endpoint, total of 6 set point, Press

the Enter key to switch to the set

point, press Up / Down / Left / Right,

warning zone can be set for several

consecutive press the Enter key to

exit the setting screen.

Switch

ON,OFF(OFF)

Set if opens the warning area

Number of edges

4～6[6]

Set the number of edges

Color

0-15[1]

Set the color

Display warning area

ON,OFF(ON)

Set if displays the image of warning

area

1.2 Face book: for face capture, storage, mainly ideal for the cell door,

factory gate, campuses, shopping malls, banks and other important places.

Sensitivity

0～11 [ 11]

Set the sensitivity,

Back light compensation

ON,OFF(OFF)

Set if enables back light compensation

Face tracking zoom

ON,OFF(OFF)

Set if enables face auto-zoom

Face book dwell time

5 ~ 90 [5]

Set the face book dwell time in the unit

of seconds

Display face book delay

ON,OFF(OFF)

Set if face book delay the displays

Frame

ON,OFF(OFF)

Set if opens frame

Set cordon

Press the Right key

then click setting

Set warning areas, total of 2 set point,

Press the Enter key to switch to the set

point, then press Up / Down / Left /

Right to pan to warning area, for

several consecutive press the Enter key

to exit the setting screen.

Face magnification

1 ~ 4 [1]

Set the face magnification

Face book location

0 ~ 120 [20]

Set the face book location

Capture archive

ON,OFF(ON)

Set if needs to storage the captured

image into TF card

Warning area displays

ON,OFF(OFF)

Set if display the image of warning area

Alarm level

High,low,off(off)

Set if output alarm when detect the

object motion, high is high output, low

output is low .Set high or low

depending on an external alarm system

of itself trigger voltage is high or low.

Alarm seconds

0-3600 [10]

Set the alarm time in unit of seconds

while detecting faces

1.3 Electronic fence: Electronic fences, one/dual-way crossing alarms.

Generally ideal for walls, windows, floor glass doors and windows, "provided

there is external alarm equipment."

Alarm level

High,low,off(off)

Set if output alarm when detect the object

motion, high is high output, low output is

low .Set high or low depending on an

external alarm system of itself trigger

voltage is high or low.

Alarm seconds

0-3600 [10]

Set the alarm time in unit of seconds while

detecting touch

Trace line

ON,OFF(ON)

Set if displays trace line

Sensitivity

-4 ~ 4 [0]

Set the sensitivity

Cordon selected

1 ~ 4 [3]

Set the number of cordon, total of 4 can

be set

Set cordon

Press the Right key

then click setting

Set cordons, total of 2 set point, Press the

Enter key to switch to the set point, then

press Up / Down / Left / Right to randomly

move the cordon location, for several

consecutive press the Enter key to exit the

setting screen.

Alarm direction

Two-way, right to left,

left to right, touch

[OFF]

Color

0-15 [3]

Set the color of cordon

1.4 Motion detection: Generally known as Movement detection, commonly

used in unmanned surveillance video, that is, when an object movement is

detected in the monitoring range, it will send alarm signals "provided there is

external alarm equipment."

Set warning area

Press the Right key

then click setting

Set warning areas, total of 16 areas, press Up /

Down / Left / Right to move the warning area

location, then press Enter key to remove or set

area(red bottom), press any key in Up / Down /

Left / Right these four item to set screen or

press Enter key to exit .

Sensitivity

-2 ~ 2 [0]

Set the sensitivity of motion detection, the

larger the number, the more the sensitivity

Alarm level

High,low,off(off)

Set if output alarm when detect the object

motion, high is high output, low output is

low .Set high or low depending on an external

alarm system of itself trigger voltage is high or

low.

Alarm seconds

0-3600 [10]

Set the alarm time in unit of seconds while

detecting object motion

1.5 Digital Zoom: mainly used for a certain area to zoom, move.

Magnification

1.0～4.0 [1]

Magnification

Vertically

-10 ~ 10 [0]

After amplification, set the

vertical postion of screen

Horizotal movement

-10 ~ 10 [0]

After amplification, set the

horizotal postion of screen

1.6 Privacy Shield: mainly for a region or personal area not want to be

photographed, and select to use regional blocks to mask. Mainly ideal for

office spaces, or more specific places.

Transparency

0-3 [3]

Set the transparency of privacy

shield

Shielded area

selection

1,2,3,4,5,6,7,8[1]

Select the shield ID, a total of 8

areas can be set

Set shield area

Press the Right key then click

setting

Set the shield area, total of 4 set

point, Press the Enter key to switch

to the set point, then press Up /

Down / Left / Right to move shield

area blocks size and location, for

several consecutive press the Enter

key to exit the setting screen.

Switch

ON,OFF(OFF)

Set if needs to enable this shield

Color

1-15

Set the color of shield

1.7 Disable intelligent monitoring: turn off intelligent monitoring function of

products (multi-target tracking, face book, electronic fences, motion detection,

digital zoom, privacy shield), work as ordinary Megapixel HD surveillance

products.

2. Exposure mode

2.1 Standard Exposure: general standard exposure modes

Intelligent dark zone

compensation

ON,OFF(OFF)

[enable] effectively compensate for

camera when shooting in backlit situation

of dark picture of the main deficiencies,

then dark areas of the background screen

will be more bright

2.2 Back light compensation

Dark compensation

intensity

Auto, low, medium,

high(auto)

The compensation intensity of dark

2.3 HLC

Set light district

Press the Right key then

click setting

Set overexposed areas range area to be

shielded, total of 2 set point, Press the

Enter key to switch to the set point, then

press Up / Down / Left / Right to pan to

move the light area size, for several

consecutive press the Enter key to exit

the setting screen.

Dark compensation

intensity

low, medium, high(high)

The compensation intensity of dark

Shielded gray

1~6 [1] (1 is black(0,0,0)

other is 40, 80, 120, 160,

200 )

Set shield color of overexposed area, the

larger the number is, the whiter the color

2.4 Through the fog

Through the fog

Auto, low, medium,

high(auto)

Set the intensity through the fog, if

set to automatic, the program will

follow the scene to determine

whether or not to open the Fog and

decided strength

Sensitivity

1~13 [8]

Set the sensitivity of Fog, the larger

the number, the more the sensitivity

Strength

1~13 [8]

Set the strength of Fog

Color Adjustment

White Balance

ATW 2-8.5K, ATW 2-8.5K

Set tracing white balance

mode

Brightness

0-99 [50]

Set the brightness

Color-red

0-99 [50]

Set the color—red intensity

Color-green

0-99 [50]

Set the color—green intensity

Color-blue

0-99 [50]

Set the color—blue intensity

Contrast

0-99 [40]

Set the contrast

Saturation

0-99 [45]

Set the saturation

Color rolling suppression

OFF,ON(OFF)

Set the rolling suppression

Image Adjustment

4.1

Day&Night mode

Mode

Color, black&white, auto-

progressive,auto-

standard, exteral

input,( exteral input)

Color-color mode compulsory, non-switching

Black & white- black&white compulsory, non-switching

Auto-progressive: the progressive black&white closed to

human’s eyes

Aut-standard: switching to black& white once up to

specified brightness

External input: external control, needs the IR Input

Level in day&night mode to set the input level so as to

work properly

Color burst

ON,OFF(OFF)

Turn on / off the color burst, only valid for [black and

white], [Auto - Standard], [External Input] mode

Delay control

0-255 [0]

Control the switching delay time of day&night

mode,only valid for [Auto - Standard]mode

Delay time

0-60 [2]

Control the switching delay time of day&night mode,

only valid for [External Input] mode

Day->night

0-255 [128]

Set the enable point switching from color mode in day

to black& white mode in night, Day->night enable point

must be later than the reply point of Night->day, only

valid for [Auto - Standard]mode

Night->day

0-255 [112]

Set the enable point switching from black& white mode

in night to color mode in day , Night->day reply point

must be later than the enable point of Day->night, only

valid for [Auto - Standard]mode

IR-CUT input

level

High , low (low)

Input the high/low level for IR-CUT switching, only valid

for [External Input] mode, set it low.

IR-CUT output

High , low , off (off)

Input the high/low level for IR-CUT switching, only valid

for [External Input] mode, set it low.

Smart IR

0 ~ 6 [2]

Set the smart IR intensity,only valid for [External Input]

mode

4.2

Digital slow shutter

1/100000,1/10000,1/5000,1/2000,

1/500, 1/250, 1/100,1/50, automatic,

2x,3x,4x,5x,,8x,

16x,32x,64x,128x,256x,512X[16X]

Set the shutter speed.

4.3

HDNR

0 ~ 32 [32]

Set the HDNR（2D/3D）

4.4

Sharpness

0 ~ 7 [1]

Set the screen sharpness, the

larger number is, the

stronger it is

4.5

Dynamin compensation of dead pixels

Dynamin compensation of

dead pixels

0 ~ 2 [1]

Set the compensation

intensity

System setting

5.1

TF card playback, rightwards to pull R key to access the image bar.

TF card playback

Press Right then click on Set

Playblack the picture in TF

card

TF card format

Press Right then click on Set

Fomat the TF card

Year

Add via upwards UP key, and

minus via downwards DOWN

key

Set the year of image which

is looking for

Month

Add via upwards UP key, and

minus via downwards DOWN

key

Set the month of image

which is looking for

Day

Add via upwards UP key, and

minus via downwards DOWN

key

Set the day of image which is

looking for

Hour

Add via upwards UP key, and

minus via downwards DOWN

key

Set the hour of image which

is looking for

Table des matières

Autres manuels XtendLan Caméra de sécurité

XtendLan

XtendLan SDOMEOATM Manuel utilisateur

XtendLan

XtendLan SDOMEO4802701 Manuel utilisateur

XtendLan

XtendLan HDC-SDOMEO51MIR-B Manuel utilisateur

XtendLan

XtendLan XL-ICA-641M2 Manuel utilisateur

XtendLan

XtendLan XL-ICA-361M3CP Manuel utilisateur

XtendLan

XtendLan XL-ICA-206M2IR-36 Manuel utilisateur

XtendLan

XtendLan XL-ICA-206M2T-M39 Manuel utilisateur

XtendLan

XtendLan XL-ICA-206M1IR Manuel utilisateur

XtendLan

XtendLan XL-ICA-371M2 Manuel utilisateur

XtendLan

XtendLan PEDOMEOIR48023SD Manuel utilisateur

XtendLan

XtendLan SDOMEOAT2-SD332 Manuel utilisateur

XtendLan

XtendLan XL-ICA-306M1 Manuel utilisateur

XtendLan

XtendLan XL-ICA301A Manuel utilisateur

XtendLan

XtendLan XL-ICA-H660-SC110 Manuel utilisateur

XtendLan

XtendLan XL-ICA-107M1C Manuel utilisateur

XtendLan

XtendLan Speed Dome Manuel utilisateur

XtendLan

XtendLan SDOMEOAT2-SD310 Manuel utilisateur

XtendLan

XtendLan XL-ICA-106M3 Manuel utilisateur

XtendLan

XtendLan SDOMEOIR6-CM10 Manuel utilisateur

XtendLan

XtendLan XL-ICA-H660-SC110 Manuel utilisateur

XtendLan

XtendLan XL-ICA-661M1CP Manuel utilisateur

XtendLan

XtendLan XL-ICA-306M3 Manuel utilisateur

XtendLan

XtendLan SDOMEOAT-57030SD Mode d’emploi

XtendLan

XtendLan ABOX56022 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
