Q1 DASH CAMERA
User manual
Product Structure Diagram
Main View
Left View
Right View
Right View
Button Description
Power Button:
1) Turn on/off
Shortly press to turn on the camera. In the boot state, long press for 3
seconds to save files automatically and turn off the camera.
2) Backlight Switch
In the standby mode, shortly press 【Power Button】 to turn off screen
backlight, shortly press again to turn on the backlight.
M Button（Menu/Mode Button）：
1) Menu Button
In the standby mode, shortly press 【Menu Button】 to enter main menu
setting, shortly press【Up Button】or【Down Button】to select the item you
want to set, then shortly press【OK Button】to confirm. After setting, shortly
press【Menu Button】to exit menu setting.
(the menu setting method is the same in video mode, photo mode, playback
mode).
2) One Press to lock
In Recording mode, shortly press【Menu Button】to lock the current file,
and the file won’t be covered.
3) Mode shifting
Long press【Menu Button】to switch function mode ,(video mode, camera
mode, playback mode) three modes of cyclic switching.
Up Button:
1) It’s turning pages up in menu setting mode and playback mode.
2) Silent Mode
Long press 【Up Button】to open or shut down the mute incon at the
lower right corner accordingly.
Down Button:
1) Page Down Turing
It’s turning down pages in menu setting mode and playback mode.
OK Button:
Shortly press【Ok Button】to confirm in menu interface, shortly press to
start or stop recording in recording model; shortly press it to stop playing in
playback mode, shortly press it to shoot a picture in photo mode.
Reset Button:
When the camera crashes, insert a needle into the small hole and press it to
reset the camera.
【Tips】：Generally, reset button is used in crash mode. It’s unnecessary
under normal circumstance.
Installation Guideline
1) Shut down the car engine.
2) Find a proper position to install the bracket, and hang the dash camera.
The installation position should not affect driving. Don’t forget to clean the
glass for clear viewing.
3) Adjust the viewing angle of the camera to ensure the lens is on level
ground.
4) One end of the USB cable is inserted into USB port of the recorder, the
other
end is connected to the USB interface of the car.
5) Start the engine to check if the recorder has been installed correctly.
Basic Instruction of Recording/ Photo
Video Mode :
Machine boot will enter the video mode standby state, the upper left corner
of the display video Icon ;
shortly press 【Ok Button】 to start recording the video under the screen,
there will be a red dot in the flashing at the same time, in the video mode, can
not operate the menu and switch mode, then shortly press 【Ok Button】to
stop recording
Photo Mode :
In standby mode, press the 【M Button】 to switch to the camera mode. The
icon in the upper left corner of the screen displays the camera Icon；
Shortly press the 【Ok Button】to take pictures, the screen flashes once
means the shooting is finished; shortly press the 【Menu Button】to enter
photo menu setting ; press the 【M Button】 to switch to playback mode.
Video / Photo Playback :
In the photo mode, press the M key, switch to playback mode, display the
playback icon in the upper left corner of the screen ；
shortly press the 【Up Button】 to select files upward;
shortly press 【Down Button】 to select files downward;
Press the 【Ok Button】 to select video file;
Click the 【Menu Button】 to enter the menu settings, where you can delete
or unlock files.
Menu Settings :
In the standby mode of three modes (camera, camera, playback), shortly press
【Menu Button】to enter menu , and then shortly press again to setup
menu；
By pressing the 【Up Button】or 【Down Button】, you can choose each set
item from up and down for looping; shortly press the 【Ok Button】to select
the settings you need to change, and then shortly press the 【Menu Button】
to exit the menu interface.
