INSTRUCTIONS FOR REFILLING XEROX PHASER 7500 SERIES

The toner cartridge is basically a plastic tube - containing toner and a chip. The cartridge can be refilled as

many times as you want.

Before you begin

Please read instructions from start to finish,

before you start your refill.

Protect your work surface with old newspaper to

catch any waste toner spills.

hen should I refill?

Toner Low – IGNORE AND KEEP PRINTING.

When you cannot print then it is time to empty and

refill the cartridge indicated.

Turn off your printer.

Remove only the EMPTY toner cartridge from

printer.

Place the printer cartridge on several sheets of

newspaper to catch any toner spills.

www.zinetic.co.uk

www.zinetic.co.uk email: sales@zinetic.co.uk

ocate the small plastic cover that covers the

toner port. Note the orientation of the plastic

cover.

The refill hole is hidden behind the plastic cover.

Slide off the plastic cover that covers the toner

refill hole.

The plastic cover is on rails and is a tight fit so

take your time don’t break it – as we have to refit

it later.

For best results shake / tap out the remaining

toner from the cartridge via the refill hole.

Toner can be very messy – so empty the old

toner directly into a sealable plastic bag.

This the part you are most likely to spill

toner so please take care.

Wipe clean the cartridge after finishing.

www.zinetic.co.uk

www.zinetic.co.uk email: sales@zinetic.co.uk

Shake your bottle

of new toner

vigorously for 20

seconds BEFORE

removing the cap.

Remove cap and

seal.

Fit the toner pouring

spout securely to

the bottle.

Screw it down as

tight as it will go.

Wrap any type of tape around the base of the

spout & neck of the bottle to prevent any fine

toner powder escaping.

Carefully insert the spout into the hole.

(The toner will flow out like water, so take care

not to spill it)

There is a lot of toner to get into the

cartridge this will take approx. 5 minutes.

Don’t rush this part.

With the spout inserted – carefully “Upend” the

cartridge and allow the toner to slowly pour down

and into the cartridge.

The toner port will be at the top nearest the

ceiling so that gravity will help move the toner

down inside the cartridge.

www.zinetic.co.uk

www.zinetic.co.uk email: sales@zinetic.co.uk

It can help to very gently squeeze the bottle with minimum pressure – i.e. the same pressure you

would check the ripeness of a piece of soft fruit like a banana. This helps keep the toner moving.

If you squeeze the bottle too hard you will get toner powder escaping from the cartridge and landing on the

floor. Avoid this !

When you have finished refilling the cartridge -

lower the cartridge and remove the toner bottle

from the port.

Replace the plastic cover. The cover must be

replaced the correct way.

Stage 2 - Changing the Chip

1. The reset chip is located on end of the

cartridge and is held in place by 2 locking tabs.

www.zinetic.co.uk

www.zinetic.co.uk email: sales@zinetic.co.uk

2. We need to release and remove the chip

without breaking the plastic clips. Shown

opposite.

The clips can be depressed from the front - or

you can go in from behind and release them. Or

a combination of both.

3. Once the clips are released its really easy

to slide the chip.

www.zinetic.co.uk

www.zinetic.co.uk email: sales@zinetic.co.uk

Refit the new chip.

Slide the chip into place. The clips will probably

reengage to lock it into place but if they don’t

manuvere them into place from behind so that

they lock it into place.

The chip should be securely locked in place.

You can refill this cartridge as many times as you want. It will

never need to be replaced by a new cartridge unless it becomes

damaged.

Safety information:

•Toner powder should be treated as a nuisance dust. Not to be used by children.

•Avoid inhalation. Avoid eye & skin contact. Do not ingest. Inhalation: slight irritation of respiratory tract.

Consult a doctor. Eye contact: Dust may cause irritation by mechanical abrasion. Consult a doctor.

•Skin contact: wash with soap and cold running water. Ingestion: No known hazard. Carcinogenicity: N/A,

Mutagenicity: AMES test negative.

All safety information is given to help facilitate the safe use of this product and is based on information

obtained from the manufacturer. This information is believed to be correct, but does not purport to be all

inclusive and should be used only as a guide. Zinetic makes no warranty, express or Implied as to the

accuracy or completeness of this information. It is the users responsibility to determine the suitability of this

information for the adoption of necessary safety precautions and or compliance with local laws/regulations.

Zinetic is not associated with or endorsed by any of the cartridge / printer manufacturers referred to in any of

our published works. Names of manufacturers, machines and part numbers are given as an aid to

identification only. Names of manufacturers, machines and part numbers may be trade marks of the

respective manufacturer. All Trade Marks hereby expressly acknowledged.
