Xerox PHASER 340 Guide de configuration

Cleaning for light stripes: printhead

Approximate time to complete: 3-10 minutes

If your prints have 1/10 in. (2.5 mm) lengthwise stripes that are the wrong

color or have missing colors, you can correct the problem by cleaning the

printhead. The printer automatically executes a printhead cleaning

sequence when you run the

Clean:Light Stripes

routine from the front

panel.

1.

When the printer is on and the

Ready

message appears, press the

Clean

button. The printer displays the first selection in the menu:

Clean:Light Stripes

<---- Clean Test

2.

Press the

Clean

button once again.

3.

A series of front panel messages indicate the condition of the

printer as it progresses through a sequence of automatic cleaning

routines. The printer outputs a cleaning page at the end of the

cleaning sequence that you may discard as normal ofﬁce waste.

4.

When the cleaning sequence is completed, the printer displays the

following message:

Clean:Light Stripes

<---- Clean Test

9101-48A

5.

To conﬁrm that the problem has been corrected, press the

Test

button to print a test page. Check for any missing color bars on

the test page.

1.

Black

2.

Cyan

3.

Magenta

4.

Yellow

9101-49

1234 678910111213141516171819202122232425262728293031323334353637383940414243444546474849505152535455565758596061626364656667686970717273747576777879808182838485868788

5

1

2

3

4

678910111213

12345678910111213141516171819202122232425262728293031323334353637383940414243444546474849505152535455565758596061626364656667686970717273747576777879808182838485868788

12345678910111213141516171819202122232425262728293031323334353637383940414243444546474849505152535455565758596061626364656667686970717273747576777879808182838485868788

12345678910111213141516171819202122232425262728293031323334353637383940414243444546474849505152535455565758596061626364656667686970717273747576777879808182838485868788

6.

If one or more of the color bars are still missing, repeat the

cleaning sequence by pressing the

Clean

button once again.

When cleaning ends, the printer outputs a cleaning page that you

may discard as normal ofﬁce waste.

If the second cleaning sequence does not cure the light stripes or

missing colors problem, you can press the

Clean

button for a

third time to repeat the cleaning sequence.

7.

If your prints still have color stripe problems after the third

cleaning sequence, service may be required.

8.

Return the printer to normal operation by pressing the button.

Source: 070-9101-03 C4
