Xerox WorkCentre 6605DN Manuel d'utilisation

Xerox® WorkCentre® 6605

Quick Use Guide

Xerox WorkCentre 6605

Color Multifunction Printer

Contents

Printer Basics ...............................................................3

EN Copying.......................................................................10

EN Printing......................................................................... 6

Printer Tour...................................................................3

Control Panel................................................................4

CentreWare Internet Services...................................5

Supported Papers........................................................6

Basic Printing ..............................................................7

Printing from USB Flash Drive ................................. 8

Printing Saved and Secure Jobs............................... 9

Basic Copying............................................................10

ID Card Copying........................................................11

EN Scanning.....................................................................12

EN EN Faxing..........................................................................18

EN Troubleshooting ........................................................20

Paper Jams.................................................................20

Scanning to Email....................................................13

EN Scanning to a USB Flash Drive............................... 14

EN Scanning to a USB Connected Computer.............15

EN Scanning to a Shared Folder on a Network

Computer....................................................................16

Scanning to Windows WSD ....................................17

Basic Faxing............................................................... 19

Printer Basics

Printer Tour

Fuser

Trays 1–2

EN Bypass Tray

Duplex Automatic Document Feeder

Toner Cartridges

EN Imaging Units

EN Waste Cartridge

Jam Access

Printer Basics

1 2

ABC@:./

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

-_~

Control Panel

Menus

Services Home displays main services, such as copy, scan, and fax.

Job Status displays active, held, completed, and secure jobs.

Machine Status displays settings and information.

Clear All clears previous and changed settings for the current service.

Cancel stops the current job.

Start starts the selected job.

Job Controls

Alphanumeric Keypad

Touch screen

Power Saver On/Off

Printer Basics

xxx.xxx.xxx.xxx

1 2

ABC@:./

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

-_~

http://xxx.xxx.xxx.xxx

CentreWare Internet Services

EN CentreWare Internet Services enables you to access printer conﬁguration details, paper and supplies status,

job status, and diagnostic functions over a TCP/IP network. You can also manage fax, email, and network

scanning address books.

For details on printer administration, see the Features chapter in the User Guide located on your Software and

Documentation disc or online.

EN To connect, type the printer IP address in your computer Web browser. The IP address is available on the

control panel touch screen.

Printing

60–216 g/m2

(16 lb. Bond–80 lb. Cover)

Executive..................7.25 x 10.5 in.

Letter.........................8.5 x 11.0 in.

Folio...........................8.5 x 13.0 in.

Legal..........................8.5 x 14.0 in.

A5...............................148 x 210 mm

B5 ...............................176 x 250 mm

A4...............................210 x 297 mm

Monarch...................3.9 x 7.5 in.

#10.............................4.12 x 9.5 in.

DL ...............................110 x 220 mm

C5 ...............................162 x 229 mm

60–216 g/m2

(16 lb. Bond–80 lb. Cover)

Executive..................7.25 x 10.5 in.

Letter.........................8.5 x 11.0 in.

Folio...........................8.5 x 13.0 in.

Legal..........................8.5 x 14.0 in.

A5...............................148 x 210 mm

B5 ...............................176 x 250 mm

A4...............................210 x 297 mm

1 2

6605 DN

W: 148.5–215.9 mm (5.8–8.5 in.)

L: 210–355.6 mm (8.27–14 in.)

W: 76.2–215.9 mm (3.0–8.5 in.)

L: 127.0–355.6 mm (5.0–14.0 in.)

1 2

Trays 1–2

EN Bypass Tray

Supported Paper

60–163 g/m2

(16 lb. Bond–60 lb. Cover)

EN 2-Sided EN See User Guide > Printing

60–105 g/m2

(16–32 lb. Bond)

EN Plain

106–163 g/m2

(28 lb. Bond–60 lb. Cover)

Light Card

LW Gloss Card

164–216 g/m2

(60–80 lb. Cover)

Heavy Card

HW Gloss Card

EN Custom

Printing

Y > 297 mm (11.7 in.)

Custom

Folio

Legal

1 2

3 4

Windows Macintosh

Basic Printing

Trays 1–2

Bypass Tray

EN Conﬁrm or change size and type settings on the control panel. Select printing options in the Xerox® print driver.

Printing

1 2 3 4

JPG

PDF

1 2

ABC@:./

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

EN Insert USB Flash drive EN Touch Print a File EN Select the ﬁle, or select the folder to navigate to the EN Change the quantity as needed

EN Change the settings as needed EN Press Start

EN Clear All clears the programmed job. Cancel stops the printing job.

Printing from USB Flash Drive

Printing

JPG

PDFPDF

1 2 3 4

JPG

1 2

ABC@:./

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

1.1

1.2 1.2

Press Power Saver, touch Print From, then touch

Saved Jobs Select the saved job, then touch OK ENEN Change settings and quantity as needed EN Press Start

EN To access password protected secure jobs, press Job Status, then touch Secure Jobs

Printing Saved and Secure Jobs

EN Clear All clears the programmed job. Cancel stops the printing job.

Copying

60–125 g/m2

(16–32 lb. Bond)

50–125 g/m2

(13–32 lb. Bond)

X: 139.7–215 mm (5.5–8.5 in.)

Y: 139.7–355.6 mm (5.5–14.0 in.)

1 2

ABC@:./

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

2.1 2.2

EN Load the original

EN See User Guide > Copying

Basic Copying

EN Change the quantity as needed

EN Change the settings as needed

EN Clear All clears the programmed job. Cancel

stops the printing job.

EN Press Start

Press Power Saver, then touch Copy
