Xerox®WorkCentre®5030/5050

Black-and-White

Multifunction System

Detailed Speciﬁcations 1

WorkCentre 5030 WorkCentre 5050

Output Speed

Printing and Copying Up to 30 ppm (pages per minute)

8.5 x 11 in. (A4/210 x 297 mm) LEF

Up to 50 ppm

8.5 x 11 in. (A4/210 x 297 mm) LEF

Up to 25 ppm

8.5 x 14 in. (216 x 356 mm)

Up to 36 ppm

8.5 x 14 in. (216 x 356 mm)

Up to 22 ppm

11 x 17 in. (A3/297 x 420 mm)

Up to 31 ppm

11 x 17 in. (A3/297 x 420 mm)

First-page-out Time (FPOT) – letter size, from platen to offset catch tray

As fast as 4.7 seconds As fast as 3.4 seconds

Copy Specifications

Copying

Document Scanner Duplex Automatic Document Handler (DADH) 75-sheet capacity (based on 80 gsm paper).

Sides (input:output) 1:1, 1:2, 2:2 and 2:1

Quantity 1 to 9,999

Resolution 600 x 600 dpi x 8 bit

Concurrency Full concurrency and unlimited program ahead consistent with configuration.

WorkCentre 5050

shown with Duplex Automatic

Document Feeder, High Capacity

Feeder and Office Finisher

WorkCentre 5030

shown with Duplex Automatic

Document Feeder, High Capacity

Feeder and Offset Catch Tray.

WorkCentre®5030/5050

Detailed Speciﬁcations 2

Digital Imaging AutoIQ automatic digital image quality control

Auto rotation 180° or 270° when needed

Image shift

Edge erase

Edge-to-edge copying

Auto centering

Original type selection (normal, text, halftone, photo)

Lighter/darker

Background suppression

Contrast

Sharpness

Screening

Copy Pre-Collation

Memory (EPC)

128 MB (expandable to 512 MB)

Reduction/Enlargement Variable Zoom from 25% - 400% in 1% increments

Anamorphic Zoom

Six User-Programmable percentages

Special Features Auto paper select

Auto reduction/enlargement to fit selected paper size

Auto registration

Auto tray switching

Automatic job recovery

Booklet creation

N-up – six to one maximum for 8.5 x 11 in. / 216 x 279 mm / A4

Transparency dividers (blank or printed)

Negative image

Mirror image

Covers insertion (front only, front and back, back only; blank or printed)

Build Job

Page programming of tabs or paper inserts

Store and recall job programming

Job interrupt

Bound document copying (produce multiple sets from stored job segments)

Sample set

Mixed-size originals

Context-sensitive help screens

Stapling (single/dual) with optional finisher

Foreign Device Interface

(FDI) (Optional)

Interface to third-party access control devices, coin machines, card readers

Supports a variety of vending stations available through the Xerox Custom Application Service

USB Port (Copier

function only)

PC interface for upload/download of Internal Auditron data and customer device administration/software upgrade

Accessibility Option Xerox Copier Assistant™(XCA) Software provides a PC-based alternative to the user interface touch screen.

Used in conjunction with a customer-supplied PC attached via the USB port, this software provides

text-to-speech, screen magnification and easy PC keyboard access to basic and advanced copy features.

WorkCentre®5030/5050

Detailed Speciﬁcations 3

Paper Handling – Duplex Automatic Document Feeder (DADF)

Capacity175 sheets

Speed WorkCentre 5030: Scan at rated speed (38 spm)

WorkCentre 5050: Scan at rated speed (55 spm)

(Letter / 8.5 x 11 in. / 216 x 279 mm / A4 long edge feed [LEF])

Paper Sizes Sensed Statement – 5.5 x 8.5 in. (A5/148 x 210 mm long edge feed (LEF) or short edge feed (SEF)

Letter – 8.5 x 11 in. (A4/210 x 297 mm) LEF or SEF

Legal – 8.5 x 14 in. (216 x 356 mm) SEF

Ledger – 11 x 17 in. (A3/297 x 420 mm) SEF

Weights 13 lb to 32 lb bond (50 to 120 gsm)

Paper Handling – Two Front Loading Paper Trays

Capacity1550 sheets each

Sizes User Adjustable from 5.5 x 8.5 in. (A5/148 x 210 mm) to 11 x 17 in. (A3/297 x 420 mm)

Weights 16 lb to 110 lb index (60 to 200 gsm)

Types Letterhead

Bond

Preprinted forms

Plain Paper

Tab Stock

Envelopes (optional, Tray 2 only)

Drilled/Hole-punched

Heavyweight

Recycled

Paper Handling – Bypass Tray

Capacity1100 sheets

Sizes User Adjustable from 4.13 x 5.83 in. (105 x 148 mm) to 11 x 17 in. (A3/297 x 420 mm)

Weights 16 lb to 80 lb cover (60 to 216 gsm)

Types Letterhead

Bond

Preprinted forms

Plain Paper

Tab Stock

Envelopes

Drilled/Hole-punched

Heavyweight

Recycled

Label Stock

Transparencies

Paper Handling – High Capacity Feeder (optional on 5030; standard on 5050)

Capacity1Two trays: 1,600 and 2,000 sheets

Sizes 8.5 x 11 in. (A4/210 x 297 mm) LEF

Weights 16 lb to 53 lb bond/110 lb index (60 to 200 gsm)

1Paper capacities are based on 20 lb/75 gsm stock; capacities will vary with different weight stocks.

Paper Handling – Total Capacity

Device Total Capacity14,800 sheets (with Bypass Tray, Front Loading Paper Trays and High Capacity Feeder)

Paper Handling – Offsetting Catch Tray (Optional)

Capacity1 300 sheets (Letter / 8.5 x 11 in. / 216 x 279 mm / A4)

Sizes 4.25 x 5.5 in. / A6 to 11 x 17 in. / A3

Output Option – Office Finisher Option

Capacity1Top Tray – 250 sheets

Stacking Tray – 2,000 sheets

Sizes 4.25 x 5.5 in. (A6/105 x 148 mm) to 11 x 17 in. (A3/297 x 420 mm)

Weights 16 lb to 80 lb cover (60 to 216 gsm)

Stapling1Single (any corner) and dual

Auto stapling (50 sheets maximum)

Statement, letter, legal, A5, A4, A3, tabloid sizes supported

Hole Punch (Optional) 3-hole punch

2-hole Legal punch

1Paper capacities are based on 20 lb/75 gsm stock; capacities will vary with different weight stocks.

WorkCentre®5030/5050

Detailed Speciﬁcations 4

Print Specifications

Network Printing – Smart Network Controller (optional)

Memory (ESS) 128 MB RAM

System Disk Minimum 9.1 GB

Processor Intel®Celeron®433 MHz

Printer Languages (PDL)

auto sensing/switching

• PCL®6/PCL®5e emulation

• PostScript®3™ emulation

• PDF

• TIFF, LCDS, SCS, XES and IPDS through third party transforms

Network Printing – Resolution (printing via CentreWare®software)

PostScript emulation: 600 x 600 dpi for 128 or 256 levels of grey:

1,200 x 1,200 dpi and 1,800 x 1,800 dpi for 256 levels of grey via patented emulation process

PCL emulation: 600 x 600 dpi

Network Printing – Printing Features

Bi-directional Print Drivers

Embedded web server for remote control/monitor/setup

Job monitoring at the device and at desktop

Advanced features include: Special font, Banner Sheet, Rotate Image, Offset

Network Printing – Print Driver Options

Paper Output Job Type

• Secure, Sample, Delay

• Save and Save & Print

Paper Selection by attribute (including transparency separators)

Duplex (2-sided)

Finishing

• Multiple stapling positions

• Hole punch (if configured)

• Booklet creation

• Fit to new paper size

Output tray selections

Store and recall driver setting

Image Options Light/Dark

Toner saver

Resolution options (600 x 600 and 1200 x 1200 dpi)

Reduction/Enlargement

Margins (edge to edge printing)

Invert Image (negative/mirror)

Layout/Watermark N-up (16)/Multi-up

Booklet Layout/Finishing

Fit to new paper size

Image orientation

Watermark options

WorkCentre®5030/5050

Detailed Speciﬁcations 5

Printing Protocols and Networks

Physical Ethernet 10/100BaseT, 10BaseT, 10Base2, Token ring (IEEE802.5) – via adapter, wireless Ethernet

(IEEE802.11a/b/g) – via third party adapter

USB 2.0

Operating Systems • Microsoft Windows 2000, XP, Windows Server XP, Windows Server 2003, Windows Server 2008, Vista

• Citrix

• Novell NetWare 4.x, 5.x, 6

• Mac OS 8.x, 9.x, OS 10.3

• Solaris 2.8, 2.9, 2.10

• HPUX 11.0

• IBM AIX 4.3.3

• Linux Fedora Core 1 (Intel)

• Linux Yellow Dog 3.0

Network Protocols

Administration Protocols

• TCP/IPv4/IPv6, LPR/LPD, Raw IP (Port 9100), NetBIOS SMB, IPX/SPX and Net BEUI, IPP

• AppleTalk/EtherTalk

Security Protocols DHCP, BOOTP, SNMP, WINS, Bonjour, DDNS, SLP v2, SSDP, HTTP/S, RARP, LDAP, SMTP, POP3

Security Protocols/Features Protocols

• HTTPS

• SNMPv3

Features

• IP filtering

• Unlimited Secure Print

• Audit log

• Image Overwrite

• Data Encryption

Fonts PCL: 80 scalable fonts, line printer and bitmap format line printer fonts (true type fonts)

PostScript 3: 136 PostScript standard fonts (true type fonts/send fonts as/substitution table)

Font Management Utility for downloading additional fonts (available for Windows and Mac)

Print Drivers Environment

Windows 2000/XP, Windows Server 2003/2003 64 Bit,

Windows Vista/Vista 64 Bit, Windows Walk-up (PS),

Microsoft Certified

PCL6/5e

Xerox custom graphical

user interface

Bi-directional features

• Job, Paper and Toner

status

• Job status notification

• Just in time Bi-Di

• Auto population of IP

address

• Delete jobs

PostScript 3

Xerox custom graphical

user interface

Bi-directional features

• Job, Paper and Toner

status

• Job status notification

• Just in time Bi-Di

• Auto population of IP

address

• Delete jobs

Macintosh System 8.x – 10.2 N/A Generic PPD

Macintosh System 10.3 and higher N/A Xerox custom graphical

user interface

Bi-directional features

• Toner, Fuser and

Xerographic

module status

Xerox Mobile Express

Driver (X-MED)

Makes it easy for mobile users to find, use and manage Xerox and non-Xerox devices in every new location. Plug into

a new network, and X-MED automatically discovers available printers and provides status and capability informa-

tion. Save a list of “favorite” printers for each location, store application print settings for use on any printer in any

network, and greatly reduce mobile support calls to IT.

• Printers are automatically discovered

• Printer list can be managed based on location

• Gives Bi-directional feedback device status, supplies, queue management

WorkCentre®5030/5050

Detailed Speciﬁcations 6

WorkCentre®5030/5050

Detailed Speciﬁcations 7

Xerox Global Print Driver

(X-GPD)

A truly universal print driver that lets IT administrators install, upgrade and manage Xerox and non-Xerox devices

from a single driver. It provides a consistent, easy-to-use interface for end-users, reducing the number of support

calls, and simplifying print services management.

• Printers are automatically discovered

• Printer list can be managed based on location

• Gives Bi-directional feedback device status, supplies, queue management

Print Submission Tools Environment

Solaris 2.8, 2.9, 2.10; HPUX 11.0, IBM AIX 4.3.3;

Linux Fedora Core 1 (Intel); Linux Yellow Dog 3.0

PCL

Submission Tool only

PostScript 3

Submission Tool with

full feature set (includes

administration, GUI/TTY

print driver and software

installation)

TIFF/PDF: Supported in Windows 98/Me/NT 4.0/2000/

XP, Windows Server 2003

Submission Tool for any

TIFF or PDF file

N/A

Device Management

Management Support SNMP Version 1. SNMP Version 2c and SNMP Version 3

MIB access (IETF-MIBII RFC 1213), host resources

MIB RFC 2790, Printer MIB RFC v.2

Xerox CentreWare®

Internet Services

Allows simple remote installation setting of configuration options and management of the device

Xerox CentreWare Web A Web-based server application for network administrators that permits Web browser-based device management

from any workstation, whether running Windows, UNIX or any other operating system.

Works with any SNMP-managed printer from any manufacturer.

Provides help with device discovery and installation, health checks and troubleshooting, and device upgrades, as well

as basic accounting and asset management.

Requires Windows XP or 2000 (Professional or Advanced Server) Windows 2003 and Internet Explorer 6.0 and higher

Novell NDPS/NEPS

(gateway for WorkCentre)

Server gateway application: centralized management tool

Xerox CentreWare for

Unicenter TNG

Provides added identification to the general discovery performed by Unicenter TNG and the ability to see the

WorkCentre under a Unicenter TNG Business Process View

Xerox CentreWare for

Tivoli NetView

Provides for the identification of Xerox WorkCentre multifunction systems in the general discovery performed by

Tivoli NetView

Xerox CentreWare for

HP OpenView

Provides for the identification of Xerox WorkCentre multifunction systems in the general discovery performed by

HP Openview

Provides traps and message updates to the Open View alarm browser and the ability to launch CentreWare Internet

Services for device management directly from OpenView

Xerox Barcode Pro PS

Information available at

www.xeroxofficesap

solutions.com

Enables intelligent PostScript printing on Xerox multifunction systems by storing Xerox software, as well as, the barcode

fonts on the printer hard disk. Enables the printing of barcodes from any application (SAP R/3 client or mainframe)

that supports PostScript printing. Automatically calculates the check digit, places start/stop and middle bar characters

in the data string, compresses and encodes the data string, and rotates the barcode through 90 or 270 degrees.

WorkCentre®5030/5050

Detailed Speciﬁcations 8

Xerox Device Types

for SAP R/3 Environment

are available at

www.xeroxofficesap

solutions.com

Simplifies printing in SAP R/3 environments by providing users of SAP R/3 3.x, 4.x, 4.5x, 4.6x, SAP Enterprise 4.7x, ERP

applications with enhanced WorkCentre printing functionality (PostScript and PCL):

• One- to Two-sided printing

• Finishing provides single or dual stapling

• Tray pull location from any tray

• # of copies – provide the ability to print multiple copies

• Paper Type and color – provide ability to select different paper types and paper colors, such as transparency, red, etc.

• Print security via PIN ID capability at the WorkCentre

• Network Accounting (JBA) – Provides capability to add Job Based Accounting User IDs to SAP print jobs

• Printer banner sheet – Provide the ability to enable/disable printer banner sheets

• Barcode printing – Xerox standard PostScript device types available at www.xeroxofficesapsolutions.com supports

Intelligent Barcode Printing with Xerox Barcode Pro PS. This Barcode Pro PS can be purchased at www.font.net

Xerox SAP R/3 Intelligent

Barcode Utility (optional)

Purchase via www.font.net

Provides built-in process intelligence that allows the printing of barcodes on any appropriately configured PostScript

printer on the SAP R/3 4.1x, 4.5x, 4.6x and within Latin-1 (ISO8859-1) SAP system code pages only. Used in conjunc-

tion with Xerox PostScript Device Types for SAP R/3 environment and Xerox Font Center Barcode Fonts. Utility enables

automated checksum calculation, placement of start/stop characters, encoding of data string and data compression.

CentreWare Internet Services – Integrated device Web page

Device Status Web server embedded on Controller

• Tray status/contents

• Consumables status

• Alerts

Job-Print Queue Viewing Complete job print queue management

Job Submission Print ready files PS, PCL (TIFF, PDF with Copier/Printer only)

Output feature selection (2-sided, staple, fold, hole punch, paper select)

Delivery options (Immediate, proof, delay and secure)

Device Administration Allows simple, remote installation setting of configuration options and management of the device

Scan Template

Management

250 templates can be created

Create device specific CentreWare scan templates

Select confirmation sheet options

Share scan templates via device cloning

Browsers Netscape 6.2, 7.x (Mozilla 1.x)

Internet Explorer 5.5.x, 6.x, 7.x

Safari 1.x

Mozilla Firefox 1.x

Support Online support available via web page

Scan Specifications

Scanning

Concurrency Scan while the system is printing, copying, or while it is transferring scan to network or fax jobs

Input Speed Scan at up to 85 ipm (Black and White) – 8.5 x 11 in. (A4/210 x 297 mm) LEF at all resolutions

Resolutions DPI Options

600 x 600 dpi

400 x 400 dpi

300 x 300 dpi

200 x 200 dpi

100 x 100 dpi

72 x 72 dpi

Scan Presets

• Archival Record (Normal Quality - Smallest file size) – 100 x 100

• For Sharing and Printing (Normal Quality - Small file size) – 200 x 200

• For High Quality Printing (High Quality - Large file size) – 300 x 300

• For OCR (High Quality - Large file size) – 300 x 300

• Simple Scan (Normal Quality - Small file size) – 200 x 200

Quality/File Size

• Normal Quality (Small file size)

• Higher Quality (Large file size)

• Maximum Quality (Largest file size)

Maximum Scan Area 11 x 17 in. (A3/297 x 420 mm)

File Formats TIFF 6.0 with G3 MH, G4 MMR, MRC or JPEG compression (single page or multiple pages)

PDF (image only with G3 MH, G4 MMR, JPEG or JBIG2 compression), PDF/A and XPS

Network Scanning (optional)

Capability • Enables device-specific network scan workflows (destination templates) to be easily created and edited via

CentreWare®Internet Services

• Scan to Home displays one template and populates with the user’s directory path after authentication

• Scan to file

• Scan to network server / directory

• Scan to Windows XP client via Windows Image Acquisition (WIA) or TWAIN driver downloadable from www.xerox.com

Network Protocol Novell (NCP via IPX/SPX)

FTP

Microsoft SMB via TCP/IP

HTTP/HTTPS

Document Management

Fields (Metadata)

Features only available in Network Scan to File Templates:

• 1-6 user programmable metadata fields per network scan to file templates and unlimited fields within the template

• Metadata Fields consists of field name, display at the LUI or not, default value and other configurations

Customized fields viewed on user interface

Variable data entered using virtual keyboard at device

Scan Template

Management

Share scan templates among WorkCentre via device cloning

Scan template management (250 templates) with CentreWare Internet Services

Select confirmation sheet option

Scan Features Build job for Scan to file and Scan to Email (enables special programming for different pages in one document –

can be used for inserts, mixing input from the document glass and document feeder), Duplex scanning, Auto detect

document size, Scan mixed size originals, scan to edge.

WorkCentre®5030/5050

Detailed Speciﬁcations 9

Scan to Email (optional)

Capability Scan to email (manual address entry or directory (Exchange/Notes/LDAP) address searching (internal address book

or Public address book – up to 128 recipients)

Network Protocol SMTP

MIME encoded

Scan Features Email signatures (6 lines each of 128 character max), email message body (user configurable),

email CWIS confirmation sheet options

Network Scanning Software Solutions

Scan to PC

Desktop Workgroup

Edition SE (optional)

A desktop offering that provides document imaging, archiving, editing and organization tools

ScanSoft PaperPort SE – image viewing and file management software

ScanSoft OmniPage SE – offer desktop/client installation – OCR and file format conversion software

Image Retriever – provides fully automated retrieval of scanned images direct from WorkCentre to individual desktops

Scan to PC

Desktop Workgroup Edition

Professional (optional)

A desktop offering that provides advanced document imaging, archiving, editing and organization tools.

ScanSoft PaperPort Professional image viewing and file management software

• Complete PDF functionality

• Secure PDF workflow of all scanning applications

ScanSoft OmniPage Pro Office (for desktop/client installation) Professional OCR software for digital archiving

and document conversion

Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox

WorkCentre to individual desktops. Also includes an email inbox polling capability.

SMARTsend2(optional) Server base document routing software that supports multiple scan-enabled multifunctional systems

Enables transformation, distribution and routing of scanned documents

Workflow creation via Web browser-based task creation (destinations, devices, document attributes – 20 file types

including PDF, workflow settings, workflow summary)

• Scan to File Destinations: email, Microsoft NetWare folder, network folder, FTP, Microsoft Exchange 2000 web

folders, web URL, remote printers

• Scan to Document Repository Destinations: DocuShare, Domino, Domino.doc, Microsoft SharePoint, Hummingbird

DNS, Open Text Livelink, Documentum, Interwoven Work Site

Workflow initiation via device scanning user interface (template selection at device UI)

Adding of Metadata information

SMARTsend2

Professional (optional)

Everything in SMARTsend, plus:

• Workflow initiation via Paperware (Scan coversheets)

• Server-based Optical Character Recognition (OCR)

• Searchable PDF

• Scan to Internet fax file destination

• TrueMatch patented search technology

2Features, conﬁgurations and options vary by location.

WorkCentre®5030/5050

Detailed Speciﬁcations 10

Autres manuels pour WORKCENTRE 5030

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Xerox Imprimante tout-en-un

Xerox

Xerox WorkCentre 7335 Manuel de service

Xerox

Xerox Phaser 6128 MFP Manuel utilisateur

Xerox

Xerox Phaser 3100MFP/S Manuel utilisateur

Xerox

Xerox WorkCentre 6025 Manuel utilisateur

Xerox

Xerox WorkCentre 4260S Manuel utilisateur

Xerox

Xerox WORKCENTRE 5030 Manuel du propriétaire

Xerox

Xerox WorkCentre 4265 Manuel d'utilisation

Xerox

Xerox AltaLink C8030 Manuel utilisateur

Xerox

Xerox Nuvera 120 EA Manuel utilisateur

Xerox

Xerox WorkCentre 7655 Manuel utilisateur

Xerox

Xerox WORKCENTRE 5150 Manuel utilisateur

Xerox

Xerox WorkCentre 4260S Manuel utilisateur

Xerox

Xerox ColorQube 9301 Manuel utilisateur

Xerox

Xerox WorkCentre Pro 657 Manuel utilisateur

Xerox

Xerox 4150 - WorkCentre B/W Laser Manuel utilisateur

Xerox

Xerox Wide Format 6030 Manuel utilisateur

Xerox

Xerox C123 Copycentre Manuel utilisateur

Xerox

Xerox WorkCentre 6015NI Manuel utilisateur

Xerox

Xerox Phaser 6140N Manuel de la liste des pièces

Xerox

Xerox WORKCENTRE 7120 Manuel utilisateur

Xerox

Xerox WorkCentre 4260 Series Manuel utilisateur

Xerox

Xerox Copycentre C118 Manuel utilisateur

Xerox

Xerox WORKCENTRE C2424 Manuel utilisateur

Xerox

Xerox WorkCentre 5325 Manuel d'utilisation

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur
