Xcruiser XS9900D Manuel utilisateur
XS9900D
© COPYRIGHT 2011 XCRUISER CORPORATION KOREA
- Please read this manual carefully before using
your Satellite Finder for the first time.
- The technical specifications and operating
methods included in this manual are subject to
changes without notice. In case of any inquires
after a period of usage, please contact the
manufacturer.
- Please charge the battery before using your
meter for the first time. (Recommend 5 hours)
XS9900D
XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 4
Table of Contents
Description ...................................................................................................... 6
Safety instructions .......................................................................................... 7
Safety of persons .............................................................................................. 7
General information .......................................................................................... 8
Appropriate Usage .......................................................................................... 9
Delivery range ................................................................................................. 9
Device overview ............................................................................................ 10
Start of operation .......................................................................................... 13
Battery ............................................................................................................. 13
Switch-on the Device ...................................................................................... 13
Lithium-ions-battery ..................................................................................... 14
Charging the battery ....................................................................................... 14
Storing of the batteries .................................................................................... 15
System setting .............................................................................................. 15
Timer ............................................................................................................... 17
Delete channels .............................................................................................. 17
Factory reset ................................................................................................... 17
Software Version ............................................................................................. 17
XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 5
Factory reset ................................................................................................. 19
Satellite finding ............................................................................................. 21
Finding channels manual ................................................................................ 21
Lining satellite aerial up .................................................................................. 22
Satellite setting ............................................................................................. 24
Automatic search .......................................................................................... 30
Angle calculation .......................................................................................... 32
Spectrum Analyzer ....................................................................................... 36
Adjustment ...................................................................................................... 36
Disposal ......................................................................................................... 36
Technical specifications .............................................................................. 41
Warrenty ........................................................................................................ 43
Declaration of conformity ........................................................................... 43
XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 6
Description
The Satellite Meter is a handy digital antenna measuring device for a quick and easy alignment of satellite antennas. If
a satellite is found, the meter shows it on the display and emits a audible signal. Signal strength and quality are
displayed as numerical values and bar graphs. Another measurement value is the forward error correction (FEC) and
the bit error rate (BER). In addition, the picture quality can be revised on the high-resolution 3.5-inch TFT LCD screen.
Many satellites are pre-programmed in order to a quick antenna adjustment.
The scope of supply contains, among the charger, a USB cable which allows you to update software.
A carrying case serves as protection and for the transport. It cares for better readability of the display at sunshine.
XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 7
Safety instructions
Attention!
Please read the safety instructions carefully before operating the device.
Please follow all warnings and instructions on the equipment and in the operating manual.
Safety of persons
Ensure that nobody can be hurt by falling tools or parts of the satellite antenna during the adjustment and installation
of the antenna. For your own security use a rope on sloping roofs.
XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 8
General information
Attention!
The devise should only be operated with the supplied AC adapter at the mains.
Do not open the meter or the included AC adapter. There is danger of life through electric shock!
Wrong usage of the ports can lead to the destruction of the measuring device.
Proceed carefully with the measuring device:
• Avoid low temperature (below 0 °C) or to high humidity.
• The TFT display can be damaged by mechanical impacts.
• Avoid excessive input voltages. Please refer to the technical data starting from page 35.
Do not operate with the device:
• if it has visible damage,
• if there are loose parts in the device,
• if the device was located outdoors or in damp rooms a extended period of time.
XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 9
Appropriate Usage
The measuring device meter was developed to measure signals of digital satellite antennas and satellite systems. It is
exclusively for this purpose and should only be used for this purpose. Use the equipment only for the purpose, which
is described in this manual.
Follow all information in this manual, particularly the safety instructions on page 5.
Any other usage is rated as not properly and can result in damage or even injury.
There will be no liability for damages caused by a non-intended use.
Delivery range
Please check if the delivery is complete.
Included in delivery:
• device meter,
• a carrying bag with sunshade,
• a PC connection cable with RS-232- and USB plug (Type A),
• a car adapter cable 12 V,
• an extern charger,
• a power cable.
• an user manual,
• an AV in/out cable
• a CD-ROM including the Software
If the above packing list was incomplete, contact your specialist dealer.
