X-Micro XBT-DG5X Manuel utilisateur
X-Micro Bluetooth USB Dongle 2.0 PLUS
User Guide
V1.1
1
INFORMATION TO USER
Product Name: X-Micro Bluetooth USB Dongle 2.0 PLUS
Model Name: XBT-DG5X, XBT-DG6X
The Bluetooth USB Adapter must be installed and used in strict accordance with the manufacturer
instructions. This device complies with the following radio frequency and safety standards.
FCC (Federal Communications Commission)
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions:1.
This device may not cause harmful interference. 2. This device must accept any interference that may
cause undesired operation.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. The equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction, may cause
harmful interference to radio communication. However, there is no grantee that interference will not occur
in a particular installation. If this equipment dose cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Notice: The Part 15 radio device operates on a non-interference basis with other devices operating at this
frequency. Any changes or modification not expressly approved by the party responsible could void the
user authority to operate the device.
R&TTE Directive
This device complies with the specifications listed below:
- ETS 301 489 -1 & -17 General EMC requirements for Radio equipment.
- ETS 300 328 Technical requirements for Radio equipment.
- EN60950 Safety Requirements for Radio equipment.
2
Copyright
Copyright 2005 by X-Micro Technology Corp., All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of X-Micro Technology Corp.
Disclaimer
X-Micro Technology Corp. makes no representations or warranties, either expressed or implied, with
respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any
particular purpose. Any software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not this company, its distributor, or its
dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential
damages resulting from any defect in the software. Further, X-Micro Technology Corp., reserves the right
to revise this publication and to make changes from time to time in the contents hereof without obligation
to notify any person of such revision or change.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of
their respective holders.
More supports, please browse X-Micro’s global website
http://www.x-micro.com
3
Index
English………...................................................................................................................4
German……………………………………………………………………...............................8
French……………………………………………………..................................................12
Dutch…………………………………………………………………………………............16
Italian………………………………………………............ …………………………...............20
Spanish………………......……………………………..……………………………............24
Portuguese………………………....…………..……………………...................................28
Russian………………….……………………………..….. …………………………............32
Danish…………………………………………………………………………………............36
Swedish…………………………………………..……………...... ………………………….40
Norwegian……………………………….………………………………………………..........44
Hungarian…………………………….………………….....…………………………............48
Traditional Chinese…………………………………………………....….............................52
4
1. Specifications
Item Specificaiton
Product Name X-Micro Bluetooth USB Dongle 2.0 PLUS
Standard Bluetooth v2.0
Frequency Band 2.4~2.4835GHz unlicensed ISM band
Modulation Method GFSK dor 1Mbps; II/4-DQPSK for 2Mbps; 8-DPSK for 3Mbps
Spread Spectrum FHSS (Frequency Hopping Spread Spectrum)
Transfer rates (Max) Max UART baud rates of 3Mbps
RF Output Power Class 1 / Class2
Working distance Greater than 100m(Class1) in free space
Greater than 20m (Class2) in free space
Sensitivity <-82dBm at < 0.1% BER
Input power DC 5V (via USB Port)
I/O Interface USB
LED indicator Power / Active
Services supported
Serial Port, Dial Up Networking, Fax, Headset, PIM Item
Transfer, PIM Synchronization, AV File Transfer, Network
Access, Audio Gateway, HID
Environment
Operation temperature: 0 oC ~ + 60 Oc
Storage temperature: -10 oC ~ +70 oC
Humidity: 5 ~ 90% non-condensing
OS Support Windows Win 98SE / Me / 2000 / XP
Dimension/Weight 52.5(L) x 19.5(W) x 7.5(H) mm / 10g
5
2. Before you start
1). Remove any Microsoft native driver.
2). Please remove any previous version of Widcomm Bluetooth software existing in your
system.
The remove procedures are as follows:
Step 1 : Click Start/Settings, then select Control Panel.
Step 2 : In the Control Panel window, double click Add/Remove programs icon.
Step 3 : Find out the item Bluetooth Software x.x.x.x then remove it.
3. Install X-Micro Bluetooth USB Dongle 2.0 PLUS driver
Step 1:
1. Insert the Utility and Driver CD in the CD-ROM drive
and wait until the following welcome screen appears
on your screen.
2. Click [Install Driver], then the utility will auto-install in
your computer system.
Note: If the screen does not appear, in Windows
Explorer browse to your CD-ROM and double-click
the“ X-Micro.exe“ file
Step 2:
Click next in the next page.
6
Step 3:
Click [Next].Accept the software license agreement.
Step 4:
Select destination folder, you can choose the default or
change to your favorite.
Step 5:
Click [Install] to start the installation and files copying
in processing ...
7
Step 6:
Click [OK] to ignore un-signed driver warning.
Step 7:
If Bluetooth dongle is plugged in your PC now, the
screen will not be displayed, otherwise it will show up
and one reminding window will show up to ask you to
plug in the USB adapter.
Plug in your USB adapter if it has not been plugged in
before. Click [OK] to continue.
Step 8: Installation is complete.
My Bluetooth places should appear on your desktop
and a similar icon also appears on the lower right
corner of your screen.
8
1. Technische Daten
Gegenstand Spezifikation
Produktname X-Micro Bluetooth-USB-Dongle 2.0 PLUS
Standard Bluetooth v2.0
Frequenzband 2,4~2,4835GHz unlizenziertes ISM-Band
Modulations-methode GFSK für 1 Mbit/s; II/4-DQPSK für 2 Mbit/s; 8-DPSK für 3
Mbit/s
Spread-Spektrum FHSS (Frequency Hopping Spread Spectrum)
Übertragungsraten (Max) Max UART-Baudraten von 3 Mbit/s
HF-Ausgangs-leistung Klasse 1 / Klasse 2
Wirkungsbereich Weiter als 100 m (Klasse 1) bei offenem Raum
Weiter als 20 m (Klasse 2) bei offenem Raum
Empfindlichkeit <-82 dBm bei < 0,1% BER
Eingangsleistung 5 Volt Gleichstrom (über USB-Anschluss)
E/A-Interface USB
LED-Anzeige Stromversorgung / Aktiv
Unterstützte Dienste
Serieller Anschluss, DFÜ-Netzwerk, Fax, Headset, PIM-
Elementübertragung, PIM-Synchronisierung, AV-
Dateiübertragung, Netzwerkzugriff, Audio-Gateway, HID
Umgebung
Betriebstemperatur: 0ºC ~ + 60ºC
Lagertemperatur: -10ºC ~ +70ºC
Luftfeuchte: 5 ~ 90% nichtkondensierend
Unterstützte
Betriebssysteme Windows Win 98SE / Me / 2000 / XP
Abmessungen / Gewicht 52,5(L) x 19,5(B) x 7,5(H) mm / 10 g
9
2. Bevor Sie beginnen
1). Entfernen Sie alle Microsoft-eigenen Treiber.
2). Entfernen Sie alle vorherigen Versionen der Widcomm Bluetooth-Software, die eventuell
auf Ihrem System vorhanden sind.
Entfernen Sie diese wie folgt:
Schritt 1 : Klicken Sie auf Start/Einstellungen, wählen Sie Systemsteuerung.
Schritt 2 : Im Fenster Systemsteuerung klicken Sie das Symbol Software doppelt an.
Schritt 3 : Finden Sie die Bluetooth-Software x.x.x.x und löschen Sie sie dann.
3. Installieren des X-Micro Bluetooth-USB-Dongle 2.0 PLUS-Treibers
Schritt 1:
1.Legen Sie die Programm- und Treiber-CD in das CD-
ROM-Laufwerk und warten Sie, bis folgender
Begrüßungsbildschirm auf dem Bildschirm erscheint.
2.Klicken Sie auf [Install Driver] und das Programm
installiert sich automatisch auf Ihrem Computersystem.
Hinweis: Erscheint dieser Bildschirm nicht, wechseln Sie
im Windows Explorer zum CD-ROM-Laufwerk und klicken
Sie die Datei “X-Micro.exe“ doppelt an.
Schritt 2:
Klicken Sie auf der nächsten Seite auf Next.
