WUBEN Gecko E61 Manuel utilisateur

User Manual V1.1

MULTIFUNCTIONAL

PENLIGHT

CONTENTS

(EN) English

(DE) Deutsch

(CN) 中文

(JP) 日本語

(KR) 한국어

03

14

26

37

48

Please read user manual carefully before using the product.

Product will generate heat while working, please becautious with that to avoid any

possible harm.

Please don’t shine into eyes directly to avoid harm to eyes.

Please keep the product away from children.

Please use WUBEN or WUBEN recommended batteries.

Please don’t disassemble the product or it will not be covered by WUBEN warranty policy.

Please don't throw the product into ﬁre.

This is not a diving product, please don't use it underwater for a long time.

WARNINGS

- 03 -

E

N

Stylus pen × 1

34Ballpoint pen reﬁll

× 4

Gecko E61 × 1

12Ink-less pen × 1

Before using this product, please check whether the contents of the package are complete.

Package List

5Micro-USB charging

cable × 1

User manual, Warranty

card × 1

6

- 04 -

Switch(Battery

power indicator)

1. About Product

Product Operation Micro-USB

charging port

Multifunctional pen

(Zirconium bead head,

ballpoint pen head)

Body

Gecko E61 is a multifunctional penlight. The

ﬂashlight body can be rotated 270°,it emits

130 lumens max output, with red and blue

beacon lights function. It has built-in a

Li-polymer battery of 120 mAh, utilizes

convenient Micro-USB charging design. The

multifunctional pen is designed with 180°

rotating hidden type. Both ends are optional

to replace for stylus pen, ink-less pen,

ballpoint pen, zirconium bead head, it can

be easily and quickly replaced according to

users' demands.

- 05 -

E

N

2. Installation

Replacement method of multifunctional pen.

- 06 -

When the light is oﬀ, open the ﬂashlight body, connect

Micro-USB charging cable and adapter of 5V/1A to

charge. It takes about 2 hours to be fully charged.

4.Charging

1

2

3

3. Operation

ON/OFF: Single click on switch to turn on the ﬂashlight, click again to turn it oﬀ. Output

selections and red and blue beacon lights have memory function when power oﬀ .

Output Selections: When the ﬂashlight is on, long press switch to cycle through Low

-Med-High-Low.It will lockout the brightness once releasing the switch at any modes.

Flash Modes:Double click on switch to activate red and blue beacon lights at any

modes,long press switchto cycle throughthe main light modes,it will lockout the

brightness once releasing. Single click to exit ﬂash mode.

- 07 -

E

N

Red light constant onCharging

Blue light constant onCharging ﬁnished

5.Charging Status Indication

Blue light constant on(oﬀ after 5 seconds)

Blue light ﬂashes(oﬀ after 5 seconds)

Red light constant on(oﬀ after 5 seconds)

C ≥ 90%

Red light ﬂashes

90% > C ≥ 40%

40% > C ≥ 15%

15% > C > 0

6.Battery Capacity (C) Status Indication

- 08 -

Parameters

Parameters

2.5 /

15

10

All data from experiments of WUBEN lab according to the quality teststandard, may vary because of

diﬀerent experiment equipment, experiment environment or other factors. Experiments are based on

a WUBEN Li-Polymer battery of 120 mAh.

8 Meters 1Meter

IP66

54g/1.9oz

143mm × 17.8mm × 12.5mm | 5.63in × 0.7in × 0.49in (L × W × H)

High Med Low Red and Blue

Beacon Lights

Hoursmins Hours

130 40

Lumens

30

Lumens 3

Lumens Lumens

1 + 45

- 09 -

E

N

When it shows low power, please recharge it in time in order not to aﬀect the use of

the product.

When not in use for a long time, please recharge it every 3 months to ensure the

durability of the battery.

Please cover the rubber piece of the USB ports well after recharging or discharging

to avoid foreign matter.

Please store the product in a dry and ventilated place.

Maintenance
