Workplace Products TUFF HEAVY DUTY STORAGE WORKBENCH Manuel utilisateur

t. 01922 743 833 | e. [email protected] | w. workplace-products.co.uk

Workplace Products, Timmis Road, Lye, Stourbridge, West Midlands DY9 7BQ, United Kingdom

Information, data & speciﬁcations are correct at time of writing. E&OE. AK24072020.

TUFF HEAVY DUTY STORAGE WORKBENCHES

Page 1 of 4

• Once step one is completed, the next step is to do

the exact same with the other side of the middle

frame and the second leg frame.

• You can then add the second middle frame and

do the same.

ASSEMBLY INSTRUCTIONS

Parts Required

• Start with laying your worktop from an upside

down perspective.

• Place one leg frame and one middle frame

together. Use an allenkey and screws to join both

parts together. As displayed in right image.

• Once the middle frames are joirned to the legs,

you can then drill in to the holes provided to ﬁx

the frame on to the worktop. Shown in the right

image above.

• Once the middle frames are joirned to the legs,

you can then drill in to the holes provided to ﬁx

the frame on to the worktop. Shown in the right

image above.

t. 01922 743 833 | e. [email protected] | w. workplace-products.co.uk

Workplace Products, Timmis Road, Lye, Stourbridge, West Midlands DY9 7BQ, United Kingdom

Information, data & speciﬁcations are correct at time of writing. E&OE. AK24072020.

TUFF HEAVY DUTY STORAGE WORKBENCHES

Page 2 of 4

ASSEMBLY INSTRUCTIONS

• With the worktop still upside down, it’s time to add

the cupboard or drawers. Place the storage unit

in to one of the corners of the workbench. It’s

recommended that you think about what side is

best for your use.

• Using the two beams shown in the image to the left

(next to the door), you can then place these inside

the storage unit. Alligning the drills holes, you can

then drill to connect in each corner.

Adding Storage Units

t. 01922 743 833 | e. [email protected] | w. workplace-products.co.uk

Workplace Products, Timmis Road, Lye, Stourbridge, West Midlands DY9 7BQ, United Kingdom

Information, data & speciﬁcations are correct at time of writing. E&OE. AK24072020.

TUFF HEAVY DUTY STORAGE WORKBENCHES

Page 3 of 4

ASSEMBLY INSTRUCTIONS

• Please note that for drawer units. The process will

be similar. However, take out the drawers before

adding the unit. This is easily done through

pushing either latch on the drawers.

• You can then add a middle drawer unit and then a

third to the side if required.

• Once the units have been ﬁtted, you can now

safely turn your workbench over.

t. 01922 743 833 | e. [email protected] | w. workplace-products.co.uk

Workplace Products, Timmis Road, Lye, Stourbridge, West Midlands DY9 7BQ, United Kingdom

Information, data & speciﬁcations are correct at time of writing. E&OE. AK24072020.

TUFF HEAVY DUTY STORAGE WORKBENCHES

Page 4 of 4

CONGRATULATIONS!!!

You should now have your workbench assembled and it should look like the above image ^ or of course slightly

diﬀerent depending on the storage options you went for.

We’re aware that the real work for you starts now so we wish you all the productivity, success and will power to

make the most out of our TUFF Heavy Duty Storage Workbench.

All the best,

Workplace Products Team
