Planning Information

Model W422210(R) Pro Wall Hood

Dimensions in parentheses are in

millimeters unless otherwise specified.

9/06

Wolf Pro wall hoods provide the ultimate in ventila-

tion. With standard elements like heat sentry and dual

setting halogen lighting, Wolf elevates the need for

ventilation to an enjoyable perk.

This 22" (559) deep model is the low-profile version,

42" (1067) wide and available in the classic stainless

steel finish. You also have the option of a decorative

rail. While a classic stainless steel rail is standard on

the (R) model, a platinum or brass rail is available as a

sales accessory.

For optimal performance, a Pro 27" (686) deep wall

hood is recommended for use with ranges and range-

tops that contain a charbroiler or griddle.

Wolf Pro low-profile wall hoods are

10" (254) high by 22" (559) deep and

come in the classic stainless steel finish.

Rail option hoods (R) include a classic

stainless steel decorative rail and stand-

offs. Optional platinum or brass rails

match dual fuel range bezels. These Pro

low-profile wall hoods are sold as a shell

only; internal, in-line and remote blower

options are available.

Model W422210

Model W422210R

Rail Option

Classic stainless

steel finish

Backdraft damper

Stainless steel

baffle filters

Infinite speed

blower control

Welded seams

and hemmed edges

Halogen lighting

Hand finished

craftsmanship

Recessed easy

access controls

Decorative rail

(optional)

Model W422210R shown with standard classic stainless steel

decorative rail, platinum or brass rail available as a sales accessory

10"(254)

OVERALL

HEIGHT

42" (1067)

OVERALL WIDTH

4"(102)

42" (1067)

OVERALL WIDTH

22" (559)

OVERALL DEPTH

12"

(305)

10"(254)

OVERALL

HEIGHT

4"(102)

22" (559)

OVERALL DEPTH

12"

(305)

(51)

3/4" (19)

DIAMETER

OF RAIL

OVERALL DIMENSIONS

FEATURES

Low-profile ventilation hood with classic

stainless steel finish

Rail option hoods (R) come with a classic

stainless steel decorative rail and stand-offs –

optional platinum or brass rail available as a

sales accessory

Internal, in-line and remote blower options

Heavy-duty 16-gauge brushed stainless steel

construction

Stainless steel enclosed liner

Continually welded seams, hemmed edges

and sides and hand finished craftsmanship

Recessed easy-access controls

Infinite -peed blower control

Heat sentry feature automatically turns unit

on when heat is sensed and automatically

adjusts blower speed

Halogen lighting with two settings

Removable, dishwasher-safe, restaurant-

grade stainless steel baffle filters

Transition with backdraft damper included

UL listed to US and Canadian safety

standards

UL approved for covered outdoor applications

Two and five year residential warranty –

exclusions apply; warranty information can

be found on our website, wolfappliance.com

Planning Information

Model W422210(R) Pro Wall Hood

Dimensions in parentheses are in

millimeters unless otherwise specified.

Dimensions may vary by ±

" (3).

Models W422210I

Models W422210IR with Rail

Planning Information

Model W422210(R) Pro Wall Hood

Dimensions in parentheses are in

millimeters unless otherwise specified.

BLOWER OPTIONS

600 CFM Internal Blower 807614

600 CFM In-Line Blower 808331

600 CFM Remote Blower 801640

900 CFM Remote Blower 801641

Refer to the Pro Ventilation

Recommendations chart at the end

of this section.

ACCESSORIES

Platinum or brass decorative rail

and stand-offs

38" (965) high stainless steel

backsplash

38" (965) high stainless steel

backsplash with warming rack

6" (152) and 12" (305) duct

covers

Accessories are available through your

Wolf dealer. To obtain local dealer

information, visit the Locator section of

our website, wolfappliance.com.

SPECIFICATIONS

Overall Width of Hood 42" (1067)

Overall Height of Hood 10" (254)

Overall Depth of Hood – W422210 22" (559)

W422210R (including rail) 24" (610)

Duct Size 8" (203) Round

Discharge Vertical or Horizontal

Electrical Supply Requirements 110 / 120 V AC, 60 Hz

15 amp dedicated circuit

Shipping Weight (shell only) 50 lbs (23 kg)

For optimal performance, a Pro 27" (686) deep wall hood is

recommended for use with ranges and rangetops that contain a

charbroiler or griddle..

Specifications are subject to change without notice.

Planning Information

Model W422210(R) Pro Wall Hood

Dimensions in parentheses are in

millimeters unless otherwise specified.

INSTALLATION SPECIFICATIONS

22" (559)

DEPTH OF HOOD

42" (1067)

WIDTH OF HOOD

(152)

(127)

LOCATION OF

ELECTRICAL

30" TO 36"

(762–914)

TO COUNTERTOP

30" TO 36"

(762–914)

TO COUNTERTOP

10" (254)

HEIGHT

OF HOOD

DIMENSIONS

Overall Width of Hood 42" (1067)

Overall Height of Hood 10" (254)

Overall Depth of Hood (excluding rail) 22" (559)

Countertop to Bottom of Hood 30" (762) to 36" (914)

Location of Electrical Within shaded area

See Installation Instructions shipped with unit for detailed specifications.

NOTE: Hood can be vertical or horizontal discharge, except with WBLOWER-60INT or BLOWER-60IL

which require vertical discharge.

For optimal performance, a Pro 27" (686) deep wall hood is recommended for use with ranges and

rangetops that contain a charbroiler or griddle.

Planning Information

Model W422210(R) Pro Wall Hood

Dimensions in parentheses are in

millimeters unless otherwise specified.

INSTALLATION NOTES

Refer to the illustrations and specifications

for overall dimensions and installation specifics.

For optimal performance, a Pro 27" (686)

deep wall hood is recommended for use with

ranges and rangetops that contain a charbroiler

or griddle.

The hood should be as least as wide as the

cooking surface. It is recommended that the

hood overlap the cooking surface by 3" (76) on

either side.

Installation of all Pro wall hoods should be

30" (762) to 36" (914) from the bottom of the

hood to the countertop. Follow the dimensions

shown in the Installation illustration.

Wolf Pro low-profile wall hoods are shipped

without the blower assembly. Internal, in-line

and remote blower assemblies are available.

Blower options also vary with the volume of air

that needs to be moved and the length of the

duct run. Refer to the end of this section for

Pro ventilation recommendations and blower

options.

IMPORTANT NOTE: Install this ventilation hood

only with a Wolf blower.

Pro wall hoods require a separate, grounded

110/120 V AC, 60 Hz power supply. The service

should have its own 15 amp circuit breaker.

Placement of the electrical supply is not critical,

as long as you provide a minimum of 6" (152)

of 120 V AC, 60 Hz power cable. Locate electri-

cal within the shaded area shown in the Instal-

lation illustration. Note that the location of the

electrical supply will differ between vertical and

horizontal discharge blowers.

You must follow all National Electrical Code

regulations. In addition, be aware of local codes

and ordinances when installing your service.

Vertical or horizontal discharge is applicable

on the low-profile wall hoods.

Refer to the installation instructions shipped

with each Wolf product for detailed specifica-

tions. This information can also be found on

our website, wolfappliance.com.

Planning Information

Model W422210(R) Pro Wall Hood

Dimensions in parentheses are in

millimeters unless otherwise specified.

Ducting considerations for

Pro low-profile wall

hoods.

DUCTWORK INSTALLATION

THROUGH ROOF

22" (559)

DEPTH OF HOOD

8" ROUND DUCT

SOFIT OR CABINET

OR DUCT COVER

REMOTE BLOWER

*HORIZONTAL DISCHARGE APPLICABLE ON LOW-PROFILE WALL HOODS

(EXCLUDING W302210I AND W362210I) USING A REMOTE BLOWER. LOW-PROFILE

WALL HOODS WITH AN INTERNAL BLOWER MUST USE VERTICAL DISCHARGE.

DUCTWORK INSTALLATION

THROUGH WALL

DISCHARGE COLLAR

HORIZONTAL

DISCHARGE*

VERTICAL DISCHARGE

TRANSITION

173/4"W x 41/4"D TO 8" ROUND

93/8"H (INCLUDING FLANGES)

30" TO 36"

(762–914)

COUNTERTOP

TO BOTTOM OF

VENTILATION HOOD

36" (914)

STANDARD

FLOOR TO

COUNTERTOP

HEIGHT

10" (254)

HEIGHT OF HOOD

WALL HOOD

ROOF CAP OR REMOTE BLOWER –

TRANSITION FROM 8" (203) TO 10" (254) DUCT

REQUIRED FOR REMOTE BLOWER

DUCTING CONSIDERATIONS

Models W302210I and W362210I come with

internal blowers, all other Wolf Pro low-profile

wall hoods are shipped without the blower

assembly. Internal, in-line or remote blower

assemblies are available. The remote blower can

be mounted on the roof or an exterior wall. Refer

to the illustration below for ducting options.

Pro low-profile wall hoods have an adjustable

discharge location that can run vertically or

horizontally. Horizontal discharge is applicable on

low-profile wall hoods (excluding Models

W302210I and W362210I) using a remote

blower.

Refer to the Pro ventilation charts at the end of

this section for recommendations and blower

options.

Planning Information

Wolf Ventilation Recommendations

Dimensions in parentheses are in

millimeters unless otherwise specified.

Dimensions may vary by ±

" (3).

241/2"

(622)

151/2"

(394)

281/4"

(718)

203/4"

(527)

243/4"

(629)

14"

(356)

43/4"

(121)

10" (254)

Diameter

143/4"

(375)

291/2"

(749)

291/2"

(749)

18" (457)

22"

(559)

101/8"

(257)

71/4"

(184)

10"

(254)

10" (254)

Diameter

Remote BLOWER-60REM and

BLOWER-90REM

143/4"

(375)

291/2"

(749)

291/2"

(749)

21" (533)

25"

(635)

103/8"

(264)

71/4"

(184)

10"

(254)

10" (254)

Diameter

WOLF BLOWER ASSEMBLIES

A ventilation system must include a blower

assembly. With a few exceptions where internal

blowers are included, Wolf ventilation hoods and

downdrafts are shipped without the blower

assembly. An internal, in-line or remote blower

assembly must be selected to accommodate the

cooking appliance, CFM requirements and home-

owner preferences. Internal, in-line and remote

blower assemblies are available as sales acces-

sories through your Wolf dealer.

Wolf internal, in-line and remote blowers are for

use with Wolf cooktop hoods, downdraft

systems and Pro ventilation hoods and hood

liners.

IMPORTANT NOTE: Use only a Wolf blower

with all Wolf ventilation products.

Internal blowers are mounted inside the hood

canopy or downdraft blower box. In-line blowers

are mounted in between the hood and the

exterior of the home. Remote blowers can be

mounted on the roof or in some cases, on an

exterior wall. Refer to the illustrations below for

dimensions of Wolf in-line and remote blowers.

Ventilation recommendation charts on the

following pages provide minimum CFM recom-

mendations according to the cooking appliance

and ventilation system used and blower options

for each specific ventilation hood or downdraft.

Remote BLOWER-120REM Remote BLOWER-150REM

113/4"

(298)

211/2"

(546)

243/8"

(619)

181/2"

(470)

121/4"

(311)

41/2"

(114)

18"

(457)

22"

(559)

247/8"

(632)

12"

(305)

18"

(457)

(203)

In-line BLOWER-60IL In-line BLOWER-110IL

Planning Information

Wolf Ventilation Recommendations

Dimensions in parentheses are in

millimeters unless otherwise specified.

PRO VENTILATION CFM RECOMMENDATIONS

Pro Low-Profile Wall Hoods

W302210I

W362210(I)

W422210 W482210

DF304 / R304 / SRT304 600 600

DF366 / R366 / SRT366 / RT366 900 900

DF364 / R364 / SRT364 / RT364 900 900

RT362 900 900

DF484 / R484 / SRT484 / RT484 900

R482 / RT482 900

NOTE: For optimal performance, a Pro 27" (686) deep wall hood is recommended for use with ranges and rangetops that contain a

charbroiler or griddle.

Model numbers for dual fuel ranges, gas ranges, sealed burner rangetops and gas rangetops indicate width and number of surface

burners. Features such as a charbroiler, griddle and/or French Top will vary.

CFM recommendations are based on total Btu/hr output. Wolf recommends 1 CFM per 100 Btu/hr (.03 kW). Additional CFM may be

required for long duct runs.

PRO VENTILATION BLOWER OPTIONS

Pro Low-Profile Wall Hoods

Blower Description Blower Number Wall Hood Models

600 CFM Internal* Included with (I) Models W302210I / W362210I

600 CFM Internal* WBLOWER-60INT (807614) W362210 / W422210

600 CFM In-Line* BLOWER-60IL (808331) W362210 / W422210 / W482210

600 CFM Remote BLOWER-60REM (801640) W362210 / W422210 / W482210

900 CFM Remote BLOWER-90REM (801641) W362210 / W422210 / W482210

*Vertical discharge with 8" (203) round duct. Remote blowers are adjustable discharge with 8" (203) round duct. NOTE: For optimal

performance, a Pro 27" (686) deep wall hood is recommended for use with ranges and rangetops that contain a charbroiler or griddle.

Wall hood models without decorative rail listed; blower options are the same for (R) models. Transition with backdraft damper included

with all wall hoods. Blower configurations are for reference only. Refer to minimum CFM recommendations for your specific cooking

product. Always consult a qualified HVAC Engineer for specific applications.

Ce manuel convient aux modèles suivants

Autres manuels Wolf hotte de ventilation

Wolf

Wolf L282212I Manuel utilisateur

Wolf

Wolf DD30I Manuel utilisateur

Wolf

Wolf PL462212 Instructions d'utilisation

Wolf

Wolf PWC422418(R) Instructions d'utilisation

Wolf

Wolf ICBPW482418 Manuel du propriétaire

Wolf

Wolf W302210I Instructions d'utilisation

Wolf

Wolf Pro Wall Ventilation hoods Manuel utilisateur

Wolf

Wolf PW362418 Instructions d'utilisation

Wolf

Wolf PWC362418 Manuel utilisateur

Wolf

Wolf PL342212 Instructions d'utilisation

Wolf

Wolf Pro Hood Liner Manuel utilisateur

Wolf

Wolf PW362210 Instructions d'utilisation

Wolf

Wolf W302418 Instructions d'utilisation

Wolf

Wolf Pro Wall Hood Manuel utilisateur

Wolf

Wolf L282212I Manuel utilisateur

Wolf

Wolf Drawer Microwave Oven Manuel utilisateur

Wolf

Wolf I423418 Instructions d'utilisation

Wolf

Wolf PW302210 Manuel utilisateur

Wolf

Wolf PW602418(R) Instructions d'utilisation

Wolf

Wolf Cooktop Ventilation Hoods Manuel utilisateur

Wolf

Wolf PW662418 Instructions d'utilisation

Wolf

Wolf PL402212 Instructions d'utilisation

Wolf

Wolf PW362718R Instructions d'utilisation

Wolf

Wolf VW36B Manuel utilisateur

Manuels hotte de ventilation populaires d'autres marques

emmeti

emmeti RECUPA MED A-140 Mode d’emploi

Nibe

Nibe F135 Manuel utilisateur

Kuppersberg

Kuppersberg INTRO 60 Instructions d'installation et d'entretien

Zephyr

Zephyr Spruce AK9834BS Guide d'installation

Hisense

Hisense MH6INBG Manuel utilisateur

Miele

Miele DA 1255 Manuel utilisateur

Broan

Broan 46000 Manuel utilisateur

GE Profile PV977 Instructions originales

FALMEC

FALMEC FFRIA24W5FS Manuel utilisateur

Whirlpool

Whirlpool RH2600XL-1 SERIES Manuel utilisateur

Küppersbusch

Küppersbusch DX ISLA Manuel utilisateur

ETNA

ETNA AV360RVS Manuel utilisateur

JUNO

JUNO JDF603E6 Manuel utilisateur

Miele

Miele DA 6708 D Manuel utilisateur

Tricity Bendix

Tricity Bendix LE 150 Manuel

AEG

AEG X68163BV1 Manuel utilisateur

AEG

AEG 125 D Manuel utilisateur

Smeg

Smeg KSEV97X Manuel utilisateur
