Wolf 24 inch E Series Manuel utilisateur

Induction and Electric Cooktops Installation Guide

INDUCTION AND ELECTRIC COOKTOPS

Wolf Customer Care 800.222.7820

Contents

3Induction and Electric Cooktops

4Specications

9Installation

10 Troubleshooting

Features and specications are subject to change at any

time without notice. Visit wolfappliance.com/specs for the

most up-to-date information.

Important Note

To ensure this product is installed and operated as safely

and efciently as possible, take note of the following types

of highlighted information throughout this guide:

IMPORTANT NOTE highlights information that is especially

important.

CAUTION indicates a situation where minor injury or product

damage may occur if instructions are not followed.

WARNING states a hazard that may cause serious injury or

death if precautions are not followed.

IMPORTANT NOTE: Throughout this guide, dimensions in

parentheses are millimeters unless otherwise specied.

IMPORTANT NOTE: Save these instructions for the local

electrical inspector.

wolfappliance.com

Product Information

Important product information including the model and

serial number are listed on the product rating plate. The

rating plate is located on the bottom of the cooktop. Refer

to the illustration below.

If service is necessary, contact Wolf factory certied service

with the model and serial number. For the name of the

nearest Wolf factory certied service or for questions

regarding the installation, visit the contact & support section

of our website, wolfappliance.com or call Wolf customer

care at 800-222-7820.

Induction cooktop.

Electric cooktop.

RATING PLATE RATING PLATE

INDUCTION AND ELECTRIC COOKTOPS

Wolf Customer Care 800.222.7820

Installation Requirements

A minimum 2" (51) is required from the bottom of the

cooktop to combustible materials.

Clearance is required for the conduit located at the right rear

of induction and electric cooktops. Refer to the illustration

below for dimensions.

Refer to the illustrations on pages 6–8 for additional

minimum clearances. Installation dimensions are the same

for induction and electric cooktops of the same width.

WARNING

Failure to locate the cooktop without proper clearances

will result in a re hazard.

SPECIFICATIONS

11/4"(32)

(51)

Conduit dimensions.

FLUSH INSTALLATION

Contemporary induction and electric cooktops can be

mounted ush with the top of the countertop, or as a frame-

less standard installation sitting on top of the countertop

surface. If the cooktop is to be mounted ush with the coun-

tertop, a recessed area surrounding the cooktop cut-out

must be provided. Wolf downdraft systems cannot be used

with contemporary induction and electric cooktops.

An installation kit and instructions required for a ush

installation are provided with the contemporary cooktop.

CAUTION

Flush installation is intended for granite, solid surface

or stone countertop surfaces only.

MULTIPLE COOKTOPS

When multiple cooktops or modules are installed side by

side, the countertop cut-out width is determined by adding

the width of each unit, then subtracting 1" (25). Refer to the

illustration below.

IMPORTANT NOTE: Contemporary induction and electric

cooktops are not designed to be installed in combination

with other cooktops.

CUT-OUT WIDTH

(COMBINED WIDTH OF COOKTOPS MINUS 1")

191/2"

(495)

CUT-OUT

DEPTH

21/2" (64)

Countertop cut-out.

wolfappliance.com

WARNING

The complete appliance must be properly grounded at

all times when electrical power is applied.

Do not ground appliance with the neutral (white) house

supply wire. A separate ground wire must be utilized.

If aluminum house supply wiring is utilized, splice the

appliance copper wire to the aluminum house wiring

using special connectors design and agency certied

for joining copper and aluminum. Follow the connector

manufacturer's recommended procedure carefully.

Improper connection can result in a re hazard.

SPECIFICATIONS

Induction cooktop.

Electric cooktop.

RATING PLATE RATING PLATE

Electrical

Installation must comply with all applicable electrical codes.

Locate the electrical supply as shown in the illustrations

on the following pages. A separate circuit, servicing only

this appliance is required. A ground fault circuit interrupter

(GFCI) is not recommended and may cause interruption of

operation.

Performance may be compromised if the electrical supply is

less than 240 volts.

When multiple cooktops are installed side by side, each unit

must have its own separate recommended electrical circuit.

ELECTRICAL REQUIREMENTS

INDUCTION / ELECTRIC

Electrical Supply 3-wire, 240/208 VAC, 60 Hz

Conduit exible 4' (1.2 m)

SERVICE

15" Induction / Electric 20 amp dedicated circuit

24" Induction 30 amp dedicated circuit

30" Induction / Electric 40 amp dedicated circuit

36" Induction / Electric 50 amp dedicated circuit

Wolf Customer Care 800.222.7820

SPECIFICATIONS

15" Cooktop

STANDARD INSTALLATION

14"

(356)

191/2"

(495)

21/2" (64)

FRONT VIEW

SIDE

VIEW

COUNTERTOP CUT-OUT

TE: Shaded area above countertop indicates minimum clearance to combustible surfaces,

combus

tible materials cannot be located within this area.

13"

(330)

18"

(457)

30"

(762)

(51)

36" (914) min

FLOOR TO

COUNTERTOP

wolfappliance.com

SPECIFICATIONS

COUNTERTOP CUT-OUT

10" (254)

41/2" (114)

31/2" (89)

FRONT VIEW

SIDE

VIEW

TE: Shaded area above countertop indicates minimum clearance to combustible surfaces,

combus

tible materials cannot be located within this area.

ectrical supply location only applies to installations with built-in oven.

30"

(762)

13"

(330)

18"

(457)

(51)

WIDTH

191/2"

(495)

21/2" (64)

36" (914) min

FLOOR TO

COUNTERTOP

CUT-OUT WIDTH

INDUCTION / ELECTRIC COOKTOP W

24" Induction 221/8"(562)

30" Induction / Electric 29" (737)

36" Induction / Electric 35" (889)

24", 30" and 36" Cooktops

STANDARD INSTALLATION

Wolf Customer Care 800.222.7820

SPECIFICATIONS

24", 30" and 36" Cooktops

FLUSH INSTALLATION

RECESS

211/8"

(537)

RECESS

19/16" (40) min

CUT-OUT WIDTH

COUNTERTOP CUT-OUT

191/2"

(495)

21/2" (64)

10" (254)

41/2" (114)

31/2" (89)

FRONT VIEW

SIDE

VIEW

TE: Shaded area above countertop indicates minimum clearance to combustible surfaces,

combus

tible materials cannot be located within this area.

ectrical supply location only applies to installations with built-in oven.

Outsid

e corner radius 7/16"(11).

30"

(762)

13"

(330)

18"

(457)

(51)

5/16" (8)

7/8"

(22) MAX

COUNTERTOP

PROFILE

36" (914) min

FLOOR TO

COUNTERTOP

CUT-OUT WIDTH

INDUCTION / ELECTRIC COOKTOP W A

24" Induction 221/8"(562) 233/4"(603)

30" Induction / Electric 29" (737) 301/8"(765)

36" Induction / Electric 35" (889) 361/8"(918)

CLEAT OPTION

For this installation, the countertop cut-out will be the same

size as the outer edge of the cooktop glass.

Attach L-shaped cleats to the perimeter of the countertop

cut-out. The top edge of the cleat can not be wider than

7/8"(22) and will be attached 5/16"(8) below the surface of the

countertop. Refer to the illustration below. Attach the cleats

to the countertop. Consult a countertop supplier for proper

methods of attachment.

INSTALLATION

Flush Installation

To ensure a proper installation, a template for the countertop

cut-out should be created using the cooktop glass.

ROUTING OPTION

For this installation, a recessed area surrounding the coun-

tertop cut-out is required. Fabrication of the recessed area

must take place before the countertop is installed.

This option is not recommended for countertops with a

molded backsplash.

7/8"(22)

5/16"(8) L-SHAPED

CLEATS

Support cleats.

wolfappliance.com

Wolf Customer Care 800.222.7820

INSTALLATION

Cooktop Installation

Remove the cooktop and components from the shipping

package and recycle packing materials.

Lower the cooktop into the countertop cut-out. Center the

cooktop in the opening with the front edge aligned parallel

to the front edge of the countertop. Using a pencil, outline

the rear edge of the cooktop on the countertop. Remove the

cooktop.

Apply the foam strip provided, to the perimeter of the coun-

tertop opening. Refer to the illustration below. Do not seal

the cooktop to the countertop.

Insert the cooktop into the opening. Verify the cooktop is

aligned with the front edge of the countertop.

Attach the brackets provided, to the bottom of the unit.

Insert the 31/2"(89) clamping screws into the brackets. Use

a screwdriver to tighten the clamping screws against the

bottom of the countertop. Do not overtighten screws. Refer

to the illustration below.

Troubleshooting

IMPORTANT NOTE: If the cooktop does not operate prop-

erly, follow these troubleshooting steps:

•Verify electrical power is supplied to the cooktop.

•If the cooktop does not operate properly, contact Wolf

factory certied service. Do not attempt to repair the

cooktop. Wolf is not responsible for service required to

correct a faulty installation.

FOAM STRIP

COUNTERTOP

BRACKET CLAMPING

SCREW

Cooktop installation.
