Wizard ON-W7534-7 Manuel utilisateur
4pcs Low illumination 720P HD WIFI IP cameras;
1pc 4CH 1080P WIFI NVR;
2.4G WIFI video transmission, no need network
cables;
With smart link technology, WIFI IP cameras connect
to NVR automatically, no settings needed;
Plug and play. After power on, IP cameras are added
to NVR automatically. NVR outputs image;
Professional enhanced WIFI module ensures
transmission open distance up to 120m, through wall
distance 30m, stable and reliable;
Support Android/ IOS smart phone remote viewing;
IP cameras with max resolution 720P high definition;
1/4” low illumination 1.0MP image sensor has good
day/night vision.
NVR supports max 1080P output;
WIFI HD IP cameras support 4ch motion detection;
WIFI HD IP cameras support 4 privacy mask zones. It
helps to avoid private zones;
H.264 High profile video compression ensures less
bandwidth and less pressure of WIFI transmission
channels, thus makes a more stable transmission.
No.
Item Quantity
1 4CH 1080P NVR 1
2 WIFI IP Camera 720P 4
3 Mouse 1
4 DC 12V 3A Power supply (NVR)
1
5 DC 12V 1A Power supply ( IPC)
4
6 User Manual 1
ON-W7534-7 is a 4CH 720P WIFI NVR KIT, a wireless
solution especially for small surveillance systems. The IP
cameras with low illumination image sensor achieve bright
and colorful day vision, clean and smooth night vision.
NVR adopts high-performance processor, outputs high
definition image. Enhanced image rendering technology
makes image brighter and more beautiful without distortion.
You can experience perfect surveillance.
IP cameras and NVR use professional WIFI module.
Strong signals and anti-jamming technique ensure wireless
transmission stable and reliable, transmission open
distance up to 120m, through wall distance 30m.
WIFI IP cameras can be installed anywhere without
network cables needed. The cameras with beautiful
housing design can match indoor/outdoor decorative
environment.
Unique smart link technology makes sure that IP
cameras and NVR connect together automatically after
power on. NVR outputs image immediately. No technical
skills are needed during operation, very easy and
convenient.
Easy operation makes this kit widely used in home,
small shop, office and small factory surveillance.
Features
Order list
Model : ON-W7534-7 1.0MP 4CH 720P Wireless NVR KIT
Appearance
Description
IP Camera Specification：
ON-N7004HD
Model 720P WIFI IP Camera
Image sensor 1/4" 1.0MP CMOS OV1045 + HISI 3518E
Lens Megapixel 3.6mm fixed lens
IR LED 36pcs IR LEDs, IR distance 30m
SNR ≥39dB
Electronic shutter 1/5 - 1/20,000s
Day/night vision Auto IR-CUT filter color to B/L, fixed B/L, fixed color, external control
AGC control Auto / manual
White Balance Auto/indoor/outdoor /manual
Wide dynamic Support D-WDR
DNR Support 3DNR
Video compression H.264 High profile / M-JPEG
Max resolution 1280x720@30fps
Main stream（
1280×720、720×576、640×480
）
Video resolution Sub stream（
640×480、352×288、320×240、176×144
）
Output bitrate CBR or VBR rate variable: 32K~10M
Motion Detection Support 4 motion detection zones
Privacy mask Support 4 privacy zones
Smartphone remote viewing
Support Android/ IOS smart phone
Protocol TCP/IP，HTTP，NTP，IGMP，DHCP，UDP，SMTP，RTP，RTSP，ARP，DDNS，
DNS，HTTPS，802.1X，P2P
Network interface 1ch10/100BaseT, RJ45 interface
WIFI 2.4G
WIFI transmission distance Open distance up to 100m, through wall distance 30m, variable to actual
environment
Power 12VDC
Working Temperature -30°C ~60°C
Working Humidity 0%-90% RH (non-condensing)
Specification
NVR Specification:
ON-P0004HW
Model 4CH 1080P WIFI NVR
Processor Industrial-grade embedded microprocessor
System Operation system Embedded LINUX operation system
Video compression H.264 High Profile Lever 4.2
Display quality Max 1920x1080
Video
Video input 4*1080P/4*960P/4*720P
Compression G.711
Audio Two-way audio No
Record mode Manual/Motion detection/ Timing/ Alarm
Record and
playback Playback 4CH 720P playback, speed variable 1/4,1/2,2X,4X
Each channel storage
Video:720P 20G/day
Store and
backup Backup mode Support HDD/U disc storage and backup
Protocol TCP/IP,HTTP,DHCP,UDP,RTP,RTSP,FTP,NTP,ONVIF,SADP(IP auto
search),P2P
Smartphone Support Android/ IOS smart phone
Network
Browser Support IE
WIFI Professional enhanced WIFI receiving module
WIFI antenna 2pcs 5dB antenna
WIFI Transmission distance
Open distance up to 100m, through wall distance 30m, variable to actual
environment
Video input 4*1080P/4*960P/4*720P
Video output 1ch VGA, 1ch HDMI
Audio input No
Audio output 1CH
Alarm input No
Alarm output No
Network interface RJ45 10M/100Mbps/1000Mbps adaptive Ethernet port
USB 2*USB 2.0
Interface
HDD Support 1HDD (max 4TB)
Power DC +12V /3A
Power consumption 5W (without HDD)
Working Temperature
-10°C ~55°C
Others
Working Humidity 10%－90%
