Precision measuring device
Watch Expert
Operating instructions
Read the instructions prior to performing any task!
Wits-35286-CH, 3, en_GB
Translation of the original operating instructions
© 2016 Witschi Electronic AG
Witschi Electronic AG
Bahnhofstrasse 26
3294 Büren a.A.
Switzerland
Telephone: +41 32 352 05 00
Fax: +41 32 351 32 92
Email: [email protected]
Internet: www.witschi.com
27.02.2018Precision measuring device Watch ...
2
This manual enables safe and efficient handling of the precision
measuring device (hereafter referred to as the “device” or “Watch
Expert”). The manual is part of the device and must be kept near
the device where it can be accessed by personnel at all times.
Personnel must have carefully read through and understood this
manual before starting work. The basic prerequisite for safe work is
compliance with all the safety, warning and procedural instructions
specified in this manual.
In addition, the local health and safety regulations and general
safety rules for the area in which the Watch Expert is used apply.
Illustrations in this manual are intended to aid basic understanding
and may deviate from the actual design.
The content of this manual is protected by copyright. It may be
used within the context of using the Watch Expert. No other use is
permitted without written approval from Witschi Electronic AG.
Your point of sale can provide you with technical information.
You can find your nearest point of sale on our website at “http://
www.witschi.com/de/firma/vertretungen”
We are also always interested in hearing from you about your
experiences of using the device and any information that could
help us improve our products.
Address Witschi Electronic AG
Bahnhofstrasse 26
3294 Büren a.A.
Switzerland
Phone +41 32 352 05 00
Fax +41 32 351 32 92
e-mail [email protected]
Internet www.witschi.com
About this manual
Copyright
Customer service
Customer service information
27.02.2018 Precision measuring device Watch ... 3
Table of contents
1Product description............................................................ 6
1.1 Watch Expert................................................................ 6
1.2 Microphone................................................................... 9
1.3 User interface............................................................. 10
1.4 Modes......................................................................... 12
1.5 Scope of delivery and accessories............................. 14
1.5.1 Scope of delivery..................................................... 14
1.5.2 Optional accessories............................................... 17
1.6 Technical data............................................................. 18
2 Safety................................................................................. 23
2.1 Symbols in this manual............................................... 23
2.2 Intended use............................................................... 24
2.3 Labels on the device................................................... 25
2.3.1 Labels on the power supply unit.............................. 25
2.3.2 Risk of material damage.......................................... 26
2.4 Owner’s responsibilities.............................................. 27
2.5 Personnel qualifications.............................................. 27
3 Storing the Watch Expert................................................. 29
3.1 Delivery and storage................................................... 29
3.2 Delivery....................................................................... 29
3.3 Transport inspection................................................... 29
3.4 Storage....................................................................... 30
4 Commissioning the Watch Expert................................... 31
4.1 Setting the inclination of the device............................ 31
4.2 Requirements for location........................................... 31
4.3 Connecting the power supply unit............................... 32
4.4 Connecting the microphone........................................ 33
4.5 Connecting the printer................................................ 33
4.6 Switching the Watch Expert on/off.............................. 34
5 Setting measuring parameters........................................ 36
5.1 Setting the beat number............................................. 36
5.2 Setting the lift angle.................................................... 39
5.3 Setting test mode........................................................ 42
5.4 Setting the integration time......................................... 43
5.5 Zooming in and out of the diagram............................. 44
5.6 Changing the display mode........................................ 44
6 Performing a measurement............................................. 45
6.1 Positioning the watch and starting a measurement
automatically............................................................... 45
6.2 Monitoring the measured results................................ 47
6.3 Setting the signal strength.......................................... 49
6.4 Switching the speaker on/off....................................... 50
Table of contents
27.02.2018Precision measuring device Watch ...4
6.5 Pausing and resuming the measuring procedure....... 50
6.6 Printing measured results........................................... 51
6.7 Generating screenshots.............................................. 52
6.8 Restarting a measuring procedure............................. 52
7 Configuring the user interface......................................... 53
7.1 Configuring touch buttons........................................... 55
7.2 Configuring the main display...................................... 56
7.3 Configuring microphone buttons................................. 58
7.4 Configuring a printer................................................... 61
7.5 Configuring system settings........................................ 62
7.6 Displaying device information..................................... 64
8 Servicing the Watch Expert............................................. 65
8.1 Safety during maintenance......................................... 65
8.2 Maintenance schedule................................................ 65
9 Performing firmware update............................................ 66
9.1 Registering Watch Expert........................................... 66
9.2 Updating firmware....................................................... 66
10 Troubleshooting................................................................ 68
10.1 Error messages on the touchscreen......................... 68
10.2 Troubleshooting........................................................ 68
11 Shutting down and disposing of the Watch Expert....... 69
12 Index................................................................................... 71
Appendix............................................................................ 74
A Declaration of conformity ............................................... 75
Table of contents
27.02.2018 Precision measuring device Watch ... 5
1 Product description
1.1 Watch Expert
Fig. 1: Watch Expert
No. Designation Function
1 Touchscreen nDisplays for the numerical test results
nDisplays for the graphical test results
nDisplays for test progress
nNavigating through the menus
nChanging parameters
2[Signal] LED display nLED flashes to the rhythm of the escapement noises.
3 Stand Adjustable stand for the Watch Expert (can be set to 6 incli-
nation angles)
Overview
Product description
Watch Expert
27.02.2018Precision measuring device Watch ...6
The Watch Expert is a precision measuring device for determining
the accuracy of mechanical watches.
The choice of parameters can be adjusted to suit the given require-
ments.
The Watch Expert automatically calculates measured values for
rate deviation, amplitude and beat errors, and displays them
numerically.
With the aid of 4 different test modes, mechanical watches with the
following escapement types can be measured:
nAnchor escapement
nDuplex escapement
nCylinder escapement
nChronometer escapement
nCo-axial escapement
nAP escapement
in addition to watches with unusual beat noise.
The typical beat numbers of all common watches are recognised
automatically by the Watch Expert. Alternatively, the beat number
can be entered manually.
In addition to the “Diagram display mode” , which shows the meas-
urement in the form of a diagram, the Watch Expert also features
the “VARIO display mode” , which shows rate accuracy and ampli-
tude measurements and displays the smallest, largest and
resulting mean values, in each case.
With the aid of the pivoting microphone, a watch can be measured
in 12 different test position.
The switching screw on the rear side of the microphone ensures a
stable handling position for left and right-handed users.
Bluetooth functionality allows the device to be connected to a suit-
able printer so the measured results can be printed out. Bluetooth
functionality is possible using an optional dongle. Otherwise the
connection is via the serial interface.
Description
Product description
Watch Expert
27.02.2018 Precision measuring device Watch ... 7
Fig. 2: Rear
No
.
Designation Function
1 Rating plate Identifying the device
Ä
page 20
2 Microphone socket Connection socket for the microphone
3 Printer port
(RS232)/connec-
tion for calibration
nConnection for the thermal printer
4 Ethernet interface Connection for future applications
5 2x USB connec-
tions
Connections for USB sticks
6 Power supply Connection socket for the power supply
unit
7[I/O] switch Switches the Watch Expert on/off
8 Openings for the
stand
Openings for inserting the stand, in 6
different positions
Connections and interfaces
Product description
Watch Expert
27.02.2018Precision measuring device Watch ...8
1.2 Microphone
Fig. 3: Microphone
1 Pivoting microphone
2 Clamping jaws
3 Switching screw for left/right-handed user
adjustment
4 Programmable keys
The pivoting microphone (Fig. 3/1) provides 12 different test posi-
tions for measuring mechanical watches. The neoprene clamping
jaw (Fig. 3/2) can be adjusted in accordance with the size of the
watch. To ensure a stable hand resting position, the microphone
can be adjusted for left/right-hand users with the aid of the
switching screw (Fig. 3/3). The freely programmable keys (Fig. 3/4)
are used to navigate through the menu. Alternatively, the keys can
be assigned an individual function.
Microphone
Product description
Microphone
27.02.2018 Precision measuring device Watch ... 9
1.3 User interface
The symbols and touch buttons on the software user interface
have the following functions:
Symbol Function
Starting/pausing the measuring procedure.
Deleting the current measured values and restarting the measuring procedure.
Automatic recognition/manual control of the signal strength.
Switching the integrated speaker on/off.
Generating screenshots of the current view, where a USB stick is connected.
Sending the measuring results to a connected printer and printing them out.
1x, 2x, 4x, 8x and 16x enlargement of the diagram.
Adjustment of the integration time.
Opening the settings menu.
Opening the keypad for manual parameter entry.
Quick guide to the user interface
Product description
User interface
27.02.2018Precision measuring device Watch ...10
Table des matières
Autres manuels Witschi Instrument de mesure
Manuels Instrument de mesure populaires d'autres marques
Endress+Hauser
Endress+Hauser Proline Promag 50 Caractéristiques techniques
Siemens
Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces
KLINGER
KLINGER CMF V Series Manuel utilisateur
EXFO
EXFO FTB-2 Manuel d'exploitation et d'entretien
Keysight
Keysight M8290A Manuel utilisateur
ADTEK
ADTEK MW-5 Manuel utilisateur
