Wiselazer X5 Manuel utilisateur
USER MANUAL
Please read this manual thoroughly before use and keep it handy for future reference.
02
1.PACKING LIST
HDMI CablePower Cable
Spare Dust Filter User Manual
Projector
(Batteries Not Included)
Remote Control
Please use a dry soft cloth
to wipe the projector.
Do not place the projector
in a damp environment to
avoid electrocution.
Do not cover the vents on
the side of the projector.
Do not look at the lens while
the projector is working.
Unplug the power cord if
the projector is not used
for a long time.
Must be disassembled by a
technician to ensure its
normal operation.
2.WARNING
03
The recommended projection screen is around 100 inches with a distance of around 10.04ft.
It is recommended to use the projector in dark and low light environments.
40” 70” 100” 120” 150”
(16:9)
4.31ft
(1.32m)
7.25ft
(2.21m)
10.04ft
(3.06m)
11.93ft
(3.64m)
14.75ft
(4.49m)
3.PROJECTION DISTANCE & SIZE
Air Inlet
Focus Knob
Inch Nut×4(M5) Rear Cover
Rear
Cover
Adjustable
Tilt Foot
Rubber Gasket
Infrared Receiver
Lens
Power Button
Keystone
Correction
Left
Volume +
Volume -
Play/Pause
HDMI Input
Source
Up
Right
Back
Menu
Fast Reverse
Fast Forward
Mute
Down
4.FUNCTION OVERVIEW
Infrared
Receiver
Speaker
Audio
Out
Power
Indicator
Power
Iuput USB
HDMI
Open the cover on the bottom and take
out the dust filter for cleaning
Dust Filter
(These nuts are under the rubber gaskets)
Power
Button
OK Back Left Right Up Down Menu Keystone
Correction
04
5.QUICK START
Please install the batteries
for the remote control.
1Plug the power cord into
an outlet.
2Take off the lens cover.
3
Press the power button on
the remote control to turn
off the projector.
7
Rotate the adjustable foot.
4Place the projector on a
flat surface.
5Press the power button to
turn on the projector.
•Tear off the rubber gaskets on the
four corners of the bottom of the
projector, and install the projector
on the ceiling.
•Go to Setting » Projection Image
Setting » Projection Mode to flip
the projection image.
(This product does not include the projector
ceiling mount)
6
Rotate the focus knob to focus until the picture is clear.
6.FOCUS
05
Select "Keystone Advanced"→"Front", select
"Vertical Keystone"and "Horizontal Keystone"
to adjust the image.
•Keystone Advanced Projection Mode
Keystone Advanced
Vertical Keystone
Horizontal Keystone
Front-Desktop
Front
0
0
Digital Zoom
*Select "Digital Zoom" to adjust the picture,
the zoom range is 50% to 100%.
7.KEYSTONE CORRECTION
Take one point as the standard, adjust the
other three points until the screen is rectangle.
•4-Point Keystone Projection Mode
Keystone Advanced
4-Point Keystone
Front-Desktop
Side
Press the＂ ＂button on the remote control,
enter the projection image setting interface.
You can choose two different keystone
correction methods.
*You can also find this function through the following path.
Homepage→Setting→Projection Image Setting
Projection Image
Setting
Setting
iOS Device Mirror
USB Connection
HDMI Connection
Android Device Mirror
8.INPUT SOURCE
06
1. Select "Setting" on the projection image.
2. Select "Other Setting"→"Language Setting"
on the projection image.
3. Select the language you want to use.
Other Setting
9.LANGUAGE SETTING
Setting
10.BLUETOOTH CONNECTION
1. Select "Setting" on the projection image.
2. Select "Bluetooth Setting" on the projection image.
3. Turn on the Bluetooth function and wait for the
projector to search for available Bluetooth devices.
Bluetooth Setting
Setting
(The Bluetooth function supports connecting audio devices, but
not smart devices such as mobile phones, tablets and computers.)
11.WIFI CONNECTION
1. Select "Setting" on the projection image.
2. Select "WiFi Setting" on the projection image.
3. Wait for the projector to search for available networks.
4. Choose your network name and enter the password to connect.
(Ensure you have your own WiFi at home. If not, please open your
phone personal hotspot to create the WiFi, and then connect to it.)
Setting WiFi Setting
•For iOS Device
1. Connect the projector to your home wifi, and make
sure that your iOS device is connected to the same
network as your projector.
2. Select "HummingBirdCast" on the projection image.
HummingBirdCast
12.WIRELESS SCREEN MIRRORING
07
3. On your iOS device, open "Control Center" and tap
"Screen Mirroring".
4. On your iOS device, looking for devices that can
be mirrored on.
5. Select "BirdCast-XXXX " from the list.
BirdCast-XXXX
•For Android Device
1. Select "MiraCast" on the projection image.
2. Turn on the wireless projection function of your
Android device.
3. On your Android device, looking for the signal
of the projector device.
4. Select " " from the list.
NEWLINK-XXXX
MiraCast
08
1. Due to the built-in LED bulb, heat will be generated when the projector is working. Don’t worry,
this is normal.
2. Due to copyright issues, Netflix / Disney / Amazon prohibits playing movies from the projector,
you can use a TV Stick to connect the projector to watch the videos from Netflix, Hulu and similar
services.
3. The fluency of wireless projection depends on the connected network and your phone model.
4. The USB interface can only be connected to USB flash disks. If your USB flash disk capacity exceeds
32GB, the format should be modified to NTFS.
5. When using the wired projection function, please use the USB-C/Lightning to HDMI data cable.
7. If the remote control is lost, we will send a new one to you. If you have any operational problems,
please let us know, and we will send operational steps and instructional videos to help you.
8. When the phone and the projector are mirrored on the same screen, if there is only sound but
no image, this is a video copyright issue, not a quality issue of the projector. If you have any
questions, please consult us.
9. Due to the danger of transportation of batteries, the remote control of this projector does not
contain batteries. Before using the projector, please purchase 2 "AAA" batteries by yourself.
13.WARM TIPS
When your devices are connected via HDMI and USB ports, parameters such as brightness and
contrast can be adjusted. When the projector is playing video, press the menu button on the
remote control to enter the setting, you can choose a variety of modes, adjust the picture and
sound parameters. Scan the QR code or visit the link (https://youtu.be/k7NgekXS3N0) to watch
the operation video.
6.
