WIS WIS-EAP500-WALL Manuel utilisateur
Model: WIS-EAP500-WALL
WIS-EAP510-WALL
WIS-EAP520-WALL
www.wisnetworks.in
Quick Installation Guide
Wall AP
Only Suitable for safe use in
non-tropical climatic conditions.
Suitable for safe use in areas
below 2000 meters above sea level
2000m≤
Front
Back
WAN
System boots up successfully
Explanation
SYSTEM LED Green
LED Indicator Designation Normal status
Port Explanation
LED indicator definition
01 / Product introduction
Ports Definition
Operation environment
Connect to internet through ADSL modem or FTTH broadband. Under AP and repeater mode, WAN port
will be changed to LAN port
WAN
02 / Device installation
Step 1: Remove AP top cover with screw driver
Open top cover from here AP main body AP top cover
AP main body AP cover
①.Open wall socket cover
②.Insert LAN cable into RJ45
port at backside of the AP
③.Put AP into the wall socket
④.Fix the AP with screws
⑤.Install the cover onto AP,
finish installation
Steps
AP main bodyConnect to POE switch
Step 2: Install AP
Bypass mode topology：
POE Switch
AC
Laptop Mobile Monitor
Router
Cloud Server
INTERNET
AP1 AP2 AP3
03 / Device connection
AC Gateway mode topology：
Tips: If the AP supports 24V POE, pls use 24V PoE switch or POE adapter; if the AP is a standard
48V POE device, please use a standard IEEE802.3at POE switch or POE adapter. When deploy a large
wireless network, there are many APs in this network, it is recommended to use a wireless AC controller
in the network to centrallized-manage all APs in the network.
Laptop Mobile Monitor
Cloud Server
INTERNET
AC(AC gateway all in one)
POE Switch
AP1 AP2 AP3
Set PC wireless network card IP
04 / Device management
Connect PC by wireless
1.To connect an AP wirelessly, you need set the IP address of the TCP/IP properties of the
wireless network card to 192.168.2.2 (X is number range of 2-252) first, so that the AP
and PC in the same IP segment, and set the subnet mask to 255.255.255.0, as shown in
the following picture:
Management from WEB UI
4.1
2.2
2.After setting the IP address of PC, connect PC with AP in wireless,
double-click "Wireless network Connection", in the pop-up wireless SSID list,
select "Wireless 2.4G", click "Connect", then enter the password in the pop-up
password dialogue box, the default password is "66666666", click "OK" to
connect.
View wireless connection
NETWORK
WIS 2.4
Connect PC by wired port
Using the wired connection, set the IP address of the TCP/IP properties of the wired network card
to 192.168.188.X (X is number range of 2---252), and the PC will be the same IP segment as AP.
2.2
1.Use Internet Explorer to visit http://192.168.2.2, pop up the login dialogue box shown
in the following picture, input the default login password: admin, then press “Login” to
enter the wireless AP’s management user interface page.
Input password
Login
Information
Settings
2.By default it is in Fit AP mode, users need click the button at the right corner
to change it to FAT AP mode if needed.
Apply Reset Reboot
IP Address
Subnet
Mac Address
Gateway
AC Address
192.168.2.2
255.255.255.0
44:D1:FA:75:BF:3F
192.168.2.2
172.16.0.1
IP Mode DHCP
Fit AP
Information
Settings
