WIKA TFS135 Manuel utilisateur

Operating instructions

Betriebsanleitung

Mode d'emploi

Manual de instrucciones

Bimetal temperature switches, model TFS135

Bimetal temperature switch, model TFS135

Bimetall-Temperaturschalter, Typ TFS135

Thermostat bimétallique, type TFS135

Termostato bimetálico, modelo TFS135

14216392.01 12/2017 EN/DE/FR/ES

WIKA operating instructions model TFS135

Operating instructions model TFS135 Page 3 - 16

Betriebsanleitung Typ TFS135 Seite 17 - 30

Mode d'emploi type TFS135 Page 31 - 44

Manual de instrucciones modelo TFS135 Página 45 - 58

WIKA®is a registered trademark in various countries.

WIKA®ist eine geschützte Marke in verschiedenen Ländern.

Prior to starting any work, read the operating instructions!

Keep for later use!

Vor Beginn aller Arbeiten Betriebsanleitung lesen!

Zum späteren Gebrauch aufbewahren!

Lire le mode d'emploi avant de commencer toute opération !

A conserver pour une utilisation ultérieure !

¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!

¡Guardar el manual para una eventual consulta!

WIKA operating instructions model TFS135

14216392.01 12/2017 EN/DE/FR/ES

Contents

1. General information 4

2. Safety 6

3. Specications 9

4. Design and function 10

5. Transport, packaging and storage 11

6. Commissioning, operation 12

7. Maintenance and cleaning 14

8. Dismounting, return and disposal 15

Contents

14216392.01 12/2017 EN/DE/FR/ES

WIKA operating instructions model TFS135

1. General information

■

The bimetal temperature switch described in the operating

instructions has been designed and manufactured using state-of-

the-art technology. All components are subject to stringent quality

and environmental criteria during production. Our management

systems are certied to ISO 9001 and ISO 14001.

■

These operating instructions contain important information on

handling the instrument. Working safely requires that all safety

instructions and work instructions are observed.

■

Observe the relevant local accident prevention regulations and

general safety regulations for the instrument's range of use.

■

The operating instructions are part of the product and must be kept

in the immediate vicinity of the instrument and readily accessible to

skilled personnel at any time.

■

Skilled personnel must have carefully read and understood the

operating instructions prior to beginning any work.

■

The manufacturer's liability is void in the case of any damage

caused by using the product contrary to its intended use,

non-compliance with these operating instructions, assignment

of insuciently qualied skilled personnel or unauthorised

modications to the instrument.

■

The general terms and conditions contained in the sales

documentation shall apply.

■

Subject to technical modications.

■

Further information:

- Internet address: www.wika.de / www.wika.com

- Relevant data sheet: TV 35.02

- Application consultant: Tel.: +49 9372 132-0

Fax: +49 9372 132-406

inf[email protected]

WIKA operating instructions model TFS135

14216392.01 12/2017 EN/DE/FR/ES

1. General information

Explanation of symbols

WARNING!

... indicates a potentially dangerous situation that can

result in serious injury or death, if not avoided.

CAUTION!

... indicates a potentially dangerous situation that can

result in light injuries or damage to equipment or the

environment, if not avoided.

Information

... points out useful tips, recommendations and

information for ecient and trouble-free operation.

DANGER!

... identies hazards caused by electrical power. Should

the safety instructions not be observed, there is a risk of

serious or fatal injury.

WARNING!

... indicates a potentially dangerous situation that can

result in burns, caused by hot surfaces or liquids, if not

avoided.

14216392.01 12/2017 EN/DE/FR/ES

WIKA operating instructions model TFS135

2. Safety

WARNING!

Before installation, commissioning and operation, ensure

that the appropriate switch has been selected in terms

of switching temperature, design and specic measuring

conditions.

Non-observance can result in serious injury and/or

damage to the equipment.

Further important safety instructions can be found in the

individual chapters of these operating instructions.

2.1 Intended use

The model TFS135 bimetal temperature switches are used to limit

temperatures within a wide variety of industries.

The TFS135 are temperature limiting instruments.They are not

intended to provide any safety or protective functionality.

They monitor the temperature of machinery and equipment during

normal operation and, for example, switch o machinery if it

overheats.

The instrument has been designed and built solely for the intended

use described here, and may only be used accordingly.

The technical specications contained in these operating instructions

must be observed. Improper handling or operation of the bimetal

temperature switch outside of its technical specications requires the

instrument to be taken out of service immediately and inspected by

an authorised WIKA service engineer.

The manufacturer shall not be liable for claims of any type based on

operation contrary to the intended use.

WIKA operating instructions model TFS135

14216392.01 12/2017 EN/DE/FR/ES

2. Safety

2.2 Personnel qualication

WARNING!

Risk of injury should qualication be insucient!

Improper handling can result in considerable injury and

damage to equipment.

■

The activities described in these operating instructions

may only be carried out by skilled personnel who have

the qualications described below.

■

Keep unqualied personnel away from hazardous

areas.

Skilled personnel

Skilled personnel are understood to be personnel who, based on

their technical training, knowledge of measurement and control

technology and on their experience and knowledge of country-

specic regulations, current standards and directives, are capable

of carrying out the work described and independently recognising

potential hazards.

Special operating conditions require further appropriate knowledge,

e.g. of aggressive media.

2.3 Special hazards

WARNING!

For hazardous media such as oxygen, acetylene,

ammable or toxic gases or liquids, and refrigeration

plants, compressors, etc., in addition to all standard

regulations, the appropriate existing codes or regulations

must also be followed.

14216392.01 12/2017 EN/DE/FR/ES

WIKA operating instructions model TFS135

2. Safety

WARNING!

To ensure safe working on the instrument, the operating

company must ensure

■

that suitable rst-aid equipment is available and aid is

provided whenever required.

■

that the operating personnel are regularly instructed

in all topics regarding work safety, rst aid and

environmental protection and know the operating

instructions and in particular, the safety instructions

contained therein.

DANGER!

Danger of death caused by electric current

Upon contact with live parts, there is a direct danger of

death.

■

The instrument may only be installed and mounted by

skilled personnel.

■

Any connection work may only be carried out once the

equipment has been isolated.

■

Operation using a defective power supply unit (e.g.

short circuit from the mains voltage to the output

voltage) can result in life-threatening voltages at the

bimetal temperature switch!

WARNING!

Residual media in the dismounted instrument can result

in a risk to persons, the environment and equipment.Take

sucient precautionary measures.

Do not use this instrument in safety or emergency stop

devices. Incorrect use of the instrument can result in

injury.

Should a failure occur, aggressive media with extremely

high temperature and under high pressure or vacuum

may be present at the instrument.

WIKA operating instructions model TFS135

14216392.01 12/2017 EN/DE/FR/ES

2. Safety / 3. Specications

TFS135 NC 60 °C 12345678

2.4 Labelling, safety marking

Product label

Model

Contact design (NC = normally closed)

Nominal switching temperature

Number of production order

Approval logos

Before mounting and commissioning the instrument,

ensure you read the operating instructions!

3. Specications

Rectangular connector per DIN EN 175301-803

Switching voltage: AC 120 V / 60 Hz / 5 A

AC 250 V / 50 Hz / 2.5 A

Medium temperature range: -30 … +130 °C

Ambient temperature range: -30 … +85 °C

Pressure load: max. 50 bar

Circular connector M12 x 1

Switching voltage: AC 120 V / 60 Hz / 1 A

AC 250 V / 50 Hz / 1 A

Medium temperature range: -25 … +130 °C

Ambient temperature range: -25 … +55 °C

Pressure load: max. 50 bar

    

14216392.01 12/2017 EN/DE/FR/ES

WIKA operating instructions model TFS135

4. Design and function

4.1 Description

The model TFS135 bimetal temperature switch consists of a

thermowell with integrated switching element and a permanently

mounted connector.The bimetal temperature switch is screwed

directly into the process.

All electrical components are protected against splash water.The

electrical connection is via the connector.

4.2 Dimensions in mm

4.3 Scope of delivery

Cross-check scope of delivery with delivery note.

Circular connector

M12 x 1

Circular connector

M12 x 1 with neck tube

45 mm

Rectangular connector

per DIN EN 175301-803

14182125.01
