Whispbar K426W Manuel utilisateur

K426W

Fitting Kit

EN Fitting Instructions for Basic Carrier

DMontageanleitung für Basisträgersystem

ES Instrucciones de montaje para el sistema

de transporte

FInstructions de montage pour Basic Carrier

NO Monteringsanvisning for takstativ

PT Instruções de Montagem para sistema de

transporte.

RU Установочные Инструкции для

Поперечных Балок

x 1 x 2 x 4 x 4

x 4 x 2 x 2 x 4

x 4

Revision No: 10D 1

Fitting Kit K426W

MAX kgs (lbs)

W/P WHD

Holden

Commodore VE, 4dr Sedan Aug 06-May 13 AU 75 kgs (165 lbs) 75 kgs (165 lbs)

Commodore VF, 4dr Sedan Jun 13-+ NZ 75 kgs (165 lbs) 75 kgs (165 lbs)

Commodore VF, 4dr Sedan Jun 13-+ AU 75 kgs (165 lbs) 75 kgs (165 lbs)

Commodore VE, 4dr Sedan Sep 06-May 13 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)

Commodore VE, 5dr Wagon Apr 08-May 13 AU 75 kgs (165 lbs) 75 kgs (165 lbs)

Commodore VE, 5dr Wagon Jul 08-May 13 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)

Commodore VF, 5dr Wagon Jun 13-+ NZ 75 kgs (165 lbs) 75 kgs (165 lbs)

Commodore VF, 5dr Wagon Jun 13-+ AU 75 kgs (165 lbs) 75 kgs (165 lbs)

Pontiac

G8 , 4dr Sedan 08-+ US 75 kgs (165 lbs) 75 kgs (165 lbs)

Chevrolet

SS , 4dr Sedan 14-+ US 75 kgs (165 lbs) 75 kgs (165 lbs)

Fitting Kit EN

K426W

First Time Installation

●Remove parts from inside the package and

check. Contact your dealer if any parts are

missing or damaged.

●This kit fits type A, B, C and D.

●These instructions show type A crossbar

fitted. They also apply to type B, C and D.

●Use keys to remove covers.

Fitting Kit EN

K426W

●Use hex screwdriver to reverse adjusting

screw 10 turns.

●Press adjusting screw and pull crossbar

legs out. Refer to the crossbar instructions

for crossbar adjustment method.

●Ensure each end of the crossbar is

adjusted equally.

●Set bars to length (revert to rear of these

instructions).

●Please check the rear of this manual for

information relating specifically to your

vehicle.

Fitting Kit EN

K426W

●Tighten adjusting screw to 3 Nm (2.2 ft lb)

hand tight.

●Remove plastic clamp block by gripping bar

leg with fingers and push firmly with

thumbs until clamp block drops out behind

leg.

●Select plastic internal block (from fitting kit)

and insert into foot.

●Repeat for all legs.

Fitting Kit EN

K426W

Fitment

●Cut protective strip as shown.

●Open or remove fixed-point covers.

●Apply protective strip to roof of the vehicle

as shown.

Trim if required.

●Note C: Excess sealant may need to be

removed to fit/attach parts correctly.

●Note D: There are concealed mounting

points hidden by the vehicles rubber insert

on the roof.

●Do not mistake rubber insert for mounting

point attachment.

Fitting Kit EN

K426W

●Loosen both screws on the clamp so there

is a gap between part A and part B.

●Insert clamp into the mounting point.

●Slide parts B under mounting point.

●Ensure part B is engaged under mounting

point and part A is behind the mounting

point.

Fitting Kit EN

K426W

●Clamp placement as shown.

●Clamps shown engaged under mounting

point.

●Repeat for all four positions.

●Select four internal clamps and fit them to

the inside of the installed clamps on the

vehicle.

Fitting Kit EN

K426W

●Tighten locking screws on both sides of

clamps evenly.

●Ensure clamp A and B are secure.

●Ensure internal clamp sits upright.

●Refer to the underside of the pad for the

part number.

●It is important to put the pads in the correct

position on the vehicle.

●Letters refer to the pad part numbers and

position.

●Pad Part Number:

A = 11-04-229

B = 11-04-230

Fitting Kit EN

K426W

●Fit rubber pads (supplied with fitting kit)

over clamp. Pad may vary in shape to that

shown.

●Repeat for all four positions.

●Ensure the roof rack face towards the front

of vehicle.

●Place crossbar foot over clamp bolt.

●Place washer over clamp thread as shown.

●Ensure that tab is inserted into clamp

block.
