Whirlpool XWT-759 Manuel utilisateur

XWT-759

INSTRUCTION MANUAL

Please read instructions carefully before using

Instructions for use

Preparation for use

Description of washing machine

Precautions and recommendations

Installation

Main functions

Preparation before washing

Guide on usage

Washing recommendations

Usage of detergent and bleach

Washing sequence

Maintenance

Clean lint filter

Clean machine

Remaining water is frozen

Trouble-shooting

Above picture for illustration purpose only. Actual product may vary.

Use appropriate plug. The earth

should be well connected.

Pull out the plug when not in

use.

If wiring is defective, do contact after-

sales service.

Do not install the washing machine in a damp

environment. Do not splash water on switches. Do

not put wet clothes on control panel.

Do not pour water with temperature above 50C into

the wash tub.

Do not put your hand into the spin or wash tub while



Do not dismantle, repair or refit washing machine by

yourself

Do not put hot or heavy object on the washing

machine.

Clothes stained with volatile substance(eg. Thinner,

fuel, etc) should not be washed in the washing

machine.

Do not let children play with washing machine. Keep the machine away from direct sunlight and

heat source.

Precautions and Recommendations

INSTALLATION

Please install your washing machine according to the instructions provided.

Using the drain hose

The hose should drain smoothly

1. The fixation height of the hose should be less than

10cm from the ground.

2. Maximum fixation height for the hanging hose(with a

hook) over a drain outlet (eg. Drain pipe, bath or

sink) should not be higher than 1.2meters above the

floor. (This is for pump drain model only)

3. Do not trample or press the hose.

Change the direction of the drain hose

Factory installation position of the drain hose is shown in

Figure 1.

The hose protrudes out of the washing tub side.

Lay down the machine. And take the hose out from the

fixing groove. (Figure 2)

Along with the grove of the washing tub side, insert the

hose with steps 1 to 3 and spread it to the washing side.

(Figure 3)

Insert the hose in the groove by hand, do not damage the

hose.

MAIN FUNCTIONS

1. Rinse and foam-

removing spinning

To remove excess

detergent, saving both time

and water.

Hand washing can

improve the washing ability

2. Hand washing

When filling the water into the washing tub,

please do not leave until the water level

reaches the anticipated level, then turn off

the tap

Preparation before washing

1. Install the water inlet hose. The max water pressure

permitted is between 0.5-0.6mpa

2. Be sure the earthing is in proper working condition and

insert the plug. The earthing should not join with any gas

pipe or water hose.

3. Lay down the drain hose. (Down drain)

4. Put up the drain hose (Up drain)

5. Please keep machine level, otherwise it will cause an

abnormal sound.

Attention before washing

Follow the washing instructions stated on the

clothing labels.

Remove all hard objects

(eg coins, hairpins etc.)

from clothing.

Fasten buttons and zippers.

The quantity of clothes

should not exceed the

rated capacity.

Always put clothes with

buttons in the middle of the

wash load to minimize

contact with the pulsator.

WASHING RECOMMENDATIONS

Total dry laundry weight should not exceed rated capacity.

The capacity will be affected by the thickness, size and type of the clothes.

If the weight of the clothing is below 2kg, do not select high water level, so as to prevent

splashing of water.

Reference weight

Work

Clothes

(1120g)

Pyjamas

(220g)

Shirt

(300g)

Undershirt

(180g)

Blanket

(900g)

Socks

(50g)

Underwear

(70g)

Jacket

(800g)

Coat

(800g)

Jeans

(800g)

Bedsheet

(600g)

USAGE OF DETERGENT AND BLEACH

How to use bleach

Fill water to the specified level, and pour the bleach into the wash tub.

Do not use bleach on coloured clothing.

Bleach should not come in direct contact with clothes.

Do refer to instructions provided by bleach manufacturer.

Powder bleach can be used, do follow instructions provided by bleach manufacturer.

Normal dissolving of washing powder

1. Fill quantity of water in the wash tub.

2. Add some washing powder, run for 30 seconds to dissolve it completely.

3. Put the clothes in and select the proper water level.

Quick dissolving of washing powder.

1. Prepare warm water of 30C in a container.

2. Put the powder in and stir.

When using powder detergent, do follow instructions provided by the detergent manufacturer.

How to use washing powder

WASHING SEQUENCE

Rinse (filling water)

1. Put clothes in the wash tub and select the suitable water flow according to the clothes.

2. Rinse

Adjust the wash timer to 5-7 minutes to do rinsing.

Rinse with water (Repeat the midway spinning and rinse for 2-3 times.)

1. Put clothes in the wash tub and select the suitable water flow according to the clothes.

2. Fill water to the specified level.

3. Rinse by adjusting the wash timer to 2-3 minutes. When the weight of the load is below 3kg, use

standard water flow, it may make the water splash.

Spray Rinse

1. Put the clothes into the spin tub.

2. Move the water inlet switch to spin side.

3. Select the spin time.

Notes: You may repeat the above 1-3 steps to do more than one spray rinse.

Rinsing

Spinning

1. Put the clothes in the spin tub.

2. Press the safety cover properly and close

the spin cover.

3. Spinning:

Select the spin time according to the type of

clothes.

If there is an abnormal sound produced, while

spinning, do switch off the washing machine

and re-arrange clothes.

While spinning, if spin cover is opened,

spinning will stop, just close it and it will

resume spinning.

Clothes

Spin time(m)

Bedsheet, blanket

About 4-5

Underwear(knitwear)

About 2-4

Sweater (fabric)

About 1-2

Thin clothes

About 1

Selection of spin time

To do spinning and draining or spinning(filling water) together, please first do spinning

for about 1 minute, then do draining or rinsing, otherwise the spinning will stop owing

to too much water stored in the spin tub.

WASHING SEQUENCE

1. Put the water inlet hose into

the inlet, move the water inlet

switch to wash the side.

2. Fill water to the

specified level and

add dissolved

washing powder.

3. Put in the clothes.

4. Select

the

program

according

to clothes.

5. Select the

wash time

according to

clothes.

6. After

washing, set

the selector

to position



Midway spinning sequence

1. Put the clothes into the spin tub.

2. Spin.

(1) Place the safety cover properly.

(2) Close the spin cover.

(3) Spin for 1-2 minutes.

3. Rinse and foam removing spin

(1) Open the spin cover

(2) Put the water inlet hose into the spin

inlet and fill water for 1 minute.

(3) Close the cover, spin for 1-2 minutes.

MAINTENANCE

After washing, clean lint and foreign objects from the lint filter and frame after each use.

Before cleaning, pull the plug out of the socket.

Clean the lint filter

During washing, the lint filter must

be used.

Be sure to clean it after use.

1. To remove filter, put your hand

in the groove, press and pull down

the filter.

2. Clean the filter in water.

3. After cleaning, insert the filter

into the frame, and press in the

upper part.

Clean the washing machine

Clean the machine with soft cloth.

Clean with neutral detergent.

Never wash it directly with water.

After washing, remove the water inlet hose.

Pull out the plug and hung up the wire.

Do not keep water in the wash tub for too long.

After washing, drain immediately.

Clean the outside and inside of the washing

machine with soft cloth. Leave upper cover

open and close it after 1 hour.

Hang up the drain hose as well.

When the remaining water is frozen

To prevent freezing, after each wash, drain water

completely

After complete draining, set the program/drain

selector to the strong or standard position.

If it is on the drain position, ice is hard to melt, when

it is frozen.

Pour water below 50C into wash tub to soak. Then

turn the pulsator with your hands gently until it

drains. After that, it is ready for use.

TROUBLESHOOTING

Problem

Reason

The machine does not work

Power failure

Machine is not plugged in or powered up.

Pulsator is clogged.

The draining hose does not work

Drain hose is not kept down.

Drain hose is frozen.

Drain hose is blocked.

Clothes outside spin tub.

Abnormal noise during washing

There are hairpins and coins or metal items

on the wash tub.

Abnormal noise and violent vibration

during spinning

Machine is not level.

Safety cover is not properly placed.

Clothes are outside spinning tub.

Amount of clothes beyond stated capacity.

Water flows from the drain hose during

first use

It is the water remained from factory

inspection of performance.

NOTE

1. Maximum allowed pressure at the water inlet : 0.6Mpa

2. Minimum allowed pressure at the water inlet : 0.3Mpa

3. The new hose-sets supplied with the appliance are to be used and that the old hose-sets

are not to be re-used.

WARNING

1. If the supply cord is damaged, it must be replace by the manufacturer or its service agent or

similarly qualified persons in order to avoid a hazard.

2. For washing machine with ventilation openings in the base, that a carpet must not obstruct

the opening.

3. This appliance is not intended for use of persons(including children) with reduced physical,

sensory or mental capabilities or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance by a person responsible

for their safety.

4. Children should be supervised to ensure that they do not play with the appliance.

Table des matières

Autres manuels Whirlpool Rondelle

Whirlpool

Whirlpool 7LSC9355BN0 Manuel utilisateur

Whirlpool

Whirlpool AWO/D 6928 - PROGRAM Manuel utilisateur

Whirlpool

Whirlpool LA5330XS Manuel utilisateur

Whirlpool

Whirlpool 3RLSQ8033SW2 Manuel utilisateur

Whirlpool

Whirlpool WTW4800XQ Instructions de montage

Whirlpool

Whirlpool 3967363 Manuel utilisateur

Whirlpool

Whirlpool LXR7144EQ2 Manuel utilisateur

Whirlpool

Whirlpool AWOE 8559 Manuel utilisateur

Whirlpool

Whirlpool LWT-800 Manuel utilisateur

Whirlpool

Whirlpool LSQ9110KQ1 Manuel utilisateur

Whirlpool

Whirlpool LA57l5XP Manuel utilisateur

Whirlpool

Whirlpool FULL ELECTRONIC WASHING MACHINE Manuel utilisateur

Whirlpool

Whirlpool WFW96HEYW Manuel utilisateur

Whirlpool

Whirlpool LLT8244BQ0 Manuel utilisateur

Whirlpool

Whirlpool WTW5105HC Manuel utilisateur

Whirlpool

Whirlpool LA553OXS Manuel utilisateur

Whirlpool

Whirlpool WFW9300VU - Duet Diamond Dust Washer Manuel utilisateur

Whirlpool

Whirlpool 3XLBR8543 Manuel utilisateur

Whirlpool

Whirlpool Cabrio,- WED7300X Manuel utilisateur

Whirlpool

Whirlpool 8316243 Manuel utilisateur

Whirlpool

Whirlpool GLSR5233AW1 Manuel utilisateur

Whirlpool

Whirlpool FSCR12420 Guide d'installation

Whirlpool

Whirlpool Michigan 49022 Manuel utilisateur

Whirlpool

Whirlpool GVW9959KL0 Manuel utilisateur

Manuels Rondelle populaires d'autres marques

Tricity Bendix

Tricity Bendix AW 1000 W Guide produit

Panasonic

Panasonic NA-F60L5WRB Manuel utilisateur

GE WSLP1500 Manuel

Electrolux

Electrolux EWF1284EDW Manuel utilisateur

Bosch

Bosch WAN2829BSN Manuel utilisateur

LG TV2516DV3B Manuel utilisateur

LG TH2517DSAV Manuel utilisateur

VESTEL

VESTEL CMH-XL 7510 TE Manuel utilisateur

AEG

AEG 74335 Manuel d'utilisation

Johnson

Johnson JWF721A Manuel utilisateur

Beko

Beko WTE7604XLW0 Manuel utilisateur

Danby

Danby DTT100A1WDB Instructions de montage

Amica

Amica WA 14 Ex Manuel utilisateur

Daewoo

Daewoo DWD-F1222 Manuel utilisateur

Bosch

Bosch WAS28461AU Manuel utilisateur

Miele

Miele PW 6080 Vario Manuel utilisateur

Finlux

Finlux FLX108CF220 Manuel utilisateur

Beko

Beko WKB 51231 PTMA Manuel utilisateur
