SERVICE MANUAL

Page | 1

SERVICE MANUAL

Vertical Axis Washing Machine

Model: LSA 1100

Caution

:In this Manual, some parts technical specification can be

changed for improving, their performance without notice in

the parts list. So, if you need the latest parts information,

please contact the Service partner Manufacturer.

SERVICE MANUAL

Page | 2

1. TOP LOAD WASHING MACHINE…………………………………03

2. WASHER SPECIFICATION……………………………………………04

3. FULL MACHINE ASSEMBLY.…………………………………….....05

4. CONTROL COMPONENTS & SPECIFICATION..……….…….18

5. ERROR DISPLAY AND DIAGNOSIS..……………………..………20

6. CYCLE DURATION....…………………………………………..………23

7. SEQUENCE CHART……………………………………………..………24

8. FEATURE MATRIX.………...…………………………………..………25

9. WIRING DIAGRAM………………………………………..……………26

VERTICAL AXIS WASHING

MACHINE SERVICE MANUAL

INTEX

SERVICE MANUAL

Page | 3

sense

Automatic Precision Water Level Selection

Sense automatically selects optimum water level based on the load to ensure that no water

is wasted and you get an enhanced wash performance compared to other washers.

lexi Loading/ Add a Garment

The machine allows you to add clothes in between cycles such that precious time, water and

energy are saved by avoiding repetition of a cycle for the clothes that were left out.

Auto Tub Clean

All the programs are configured in such a way that after every wash rinse process the tub is

automatically cleaned without taking extra water, thus keeping your washer clean, while saving

precious water, as well.

Air Suspension System

The new suspension system which acts as an air cushion below the tub coupled with a unique

cabinet pattern reduces noise levels and machine walk, thus suppressing vibration.

# Available only on Select Programs. For details refer the Program Guide in user manual.

TOP LOAD WASHING MACHINE

SERVICE MANUAL

Page | 4

Model LSA 1100

Dimension (mm) 620 X 670 X 1020

Maximum Mass Of Textile (kg) 11 Kg Dry Linen

Machine Weight (kg) 40.2

Machine Weight - Packed (kg) 46.5

Spin Speed (RPM) 700-740

Operating Water Pressure 0.2 to 8 bar

WASHER

SPECI ICATION

SERVICE MANUAL

Page | 5

ULL MACHINE ASSEMBLY

SERVICE MANUAL

Page | 6

Sl. No Description

TOP AND LID ASSEMBLY

2 WASH UNIT

CABINET-ENCLOSURE

HYDRAULIC SYSTEM INLET

5 CONTROLS

DRIVE SYSTEM

7 HYDRAULIC SYSTEM OUTLET

ULL MACHINE ASSEMBLY

SERVICE MANUAL

Page | 7

Sl.

Part No

Description

Qty

1 P01882127 FRONT STIFFNER - VARI 1

P01882114 DAMPER PAD EPE WITH ADHESIVE

3 P01882134

CABINET ASSY COMPLETE - GRAPHITE 1

W10499895 INSPECTION COVER G62

P01889015 RAT MESH - PLASTIC -24 INCH - KOHINOOR

P01882129 FOOT ASSEMBLY

CABINET ENCLOSURE

SERVICE MANUAL

Page | 8

Sl. No

Part No

Part

Description

Qty

W10731723 LID ASSEMBLY WITH IFU - PHILIPPINES

2 P01881025

PLUG LEFT - GRAPHITE 1

3 P01881026A

PLUG RIGHT - GRAPHITE 1

W10698062

TOP SOFT 62 VARI GRAPHITE PAINT

5 W10732242 SWITCH LID - CHAGAL STYLE 1

P01883006 BRACKET LID SWITCH 24 INCH

7 W10520394

HINGE PIN-VARI 2

TOP AND LID ASSEMBLY

SERVICE MANUAL

Page | 9

Sl. No Part No Description Qty

1 - BASKET PLASTIC ASSEMBLY 1

2 P01880702 SUSPENSION ASSY 24" (AIR DAMPED) 4

3 W10597937 TUB WITH AIRDOME END CAP NON HEATER 1

BALANCE RING

WASH UNIT

SERVICE MANUAL

Page | 10

Sl. No Part No Description Qty

1 W10697171 BALANCE RING ASSY-24"-GLOBAL WHITE 1

2 W10697175 BASKET PLASTIC - 24"-GLOBAL WHITE 1

3 P01881308 DRIVE HUB - 24 1

P01881309

WRAPPER SS

WELDED

24 INC

W10697176

RING BOTTOM BASKET

24"

GLOBAL WHITE

BASKET ASSEMBLY
