Whirlpool SS226 Manuel utilisateur
IONIZER
SS226
SS226
ionizer catechin
Various symbols are used throughout this manual and on the product to
alert you to measures for safe use.
These symbols are classified according to the seriousness of the risk of
ignoring them, and are explained below.
Your safety and that of others is very important
We have shown a number of important safety tips in this manual and on
your appliance. Always read and observe these safety tips.
1
DEHUMIDIFIER SAFETY
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be madeby children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarlyqualified persons in order to avoid a hazard.
This instruction shall also be found on our website：
https://www.whirlpool.com.hk/
The appliance shall be installed in
accordance with national wiring
regulations.
This product must be connected to the
ground wire.
The compressor is set to rest for at lest three minutes after the unit being switched
off or just started so as to eusure a smooth start of the compressor. This action
also extends the working life of the unit.
2
PROBLEM SOLVING
3
DEHUMIDIFIER SAFETY
Make sure the louver slide cover is
opened before operating.
Closed air outlet may cause overheat or fire.
Otherwise water may spill and damage
household effects.
Do not splash or wash the unit.
The may cause electric shock or fire.
If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
220-240Vac, 50Hz.
Check and replace the 3-in-1 filter
every 3-6 monthes. Check and clean
the nano-silver pre-filter every two
weeks.
Insufficientventilation may cause low
dehumidification performance, frosting, dripping,
overheating or fire.
4
DEHUMIDIFIER SAFETY
5
1. Unique air purifying function
The unit contains a nano-silver pre-filter and a 3-in-1 (catachin, deodor,
charcoal) filter.
It operates as dehumidifier and air purifier simultaneously or simply as an air
purifier.
Negative ions are provided with discharged air under the dehumidifying or air
purifying mode (low fan speed) to give you fresh and healthy breath.
2. High efficient drying and dehumidifying
Three range selections for the vertical louver in a maximum range of 150O.
Thus, the dried air can be delivered to the desired portions.
Dry clothes quickly and efficiently.
3. Three function modes, additional internal drying function, and three
colors humidity display
Dehumidifying, drying, and air cleanng modes.
You can inhibit mildew on the cooler inside the machine by applying a one-hour
internal drying mode after turning off.
The humidity status display shows room humidity status in three corresponding
colors.
4. Movable and compact
Compact design with retractable handle makes lifting easy.
Its slim shape enables storage in a laundry room or other confined space.
5. Automatic defrost
Automatic defrosting ensures dehumidifying above 5OC.
SS226
12.1 liters per day (26.7 C, 60%RH).
20 liters per day (30
O
O
C, 80%RH).
Dimensions in mm
SPECIFICATIONS
FEATURES
574
387 172
2HR
4HR
8HR
12HR
LOW
AUTO
HIGH
Do not insert small
objects, that could
cause damage and danger.
could cause dripping.
6
POSITIONING THE UNIT
SAFE OPERATION
The slide cover was closed for the
shipment status.
Open it before operating.
2HR
4HR
8HR
12HR
LOW
AUTO
HIGH
BEFORE USING
Installing 3-in-1( catechin, deodor, charcoal) filter.
AFTER USING
When bucket is full or inserted, ‘Full’
(bucket-full indicator) illuminates and stops
the unit. Continuous draining is dipicted in
page 10.
7
3-in-1 filter
Internal drying
1. Run Internal drying (automatically for an hour)
or Air cleaning at least an hour to dry the inside.
2. Switch off and unplug.
3. Clean and dry the bucket.
4. Close the slide cover or cover the unit to
prevent dust accumulation. Store vertically in a
cool, dry place. Do not expose to diresct sunlight.
Close the
slide-cover
Press the function key to start Iternal drying after shutdown of dehumidifying. It
dries the machine internal moisture, inhibits mildew on the cooler. The internal
dry approximately runs for an hour.
Preparing for restore
and fit as illustrated
2 HR
4 HR
8 HR
12 HR
LOW
AUTO
HIGH
3-in-1 filter
2 HR
4 HR
8 HR
12 HR
LOW
AUTO
HIGH
SS 226
8
ON/OFF keyFUNCTION keyHUMIDITY keyTIMER key
LOUVER setting
CONTROL PANEL
A
12
3
6
5
4
13
12
11
10
16
15
14
9
8
7
BCDE
AON/OFF key
1. Plug to the mains and the default mode is off. Press the button first time to set the
unit operate in Dehumidifying mode, the indicator lights and other functions are off.
2. The unit will remember the operation settings when there is no power break. It will run
the same operation settings (including louver, timer, humidity and function) for the next
boot.
Dehumidifier operation modes: 1st press - Laundry, 2nd press - Air cleaning, 3th press -
Dehumidifying, and so looped.
BFUNCTION key
3
DTIMER key
4Dehumidifying: Low fan speed dehumidifying, the humidity can be set (Ionizer is also
on in Dehumidifying mode).
5Laundry: High fan speed dehumidifying, the humidity can not be set.
6Air cleaning with ionizer: Air cleaning only. In low fan speed and Ionizer is on.
Internal drying: Workable after shutdown. The machine will run the fan for an hour
to help drying the cooler, then shut down automatically.
CHUMIDITY key
Press to set the humidity range as the indicator lights. When all indicators are off, it means
continuous dehumidifying. This setting is applicable to Dehumidifying mode only.
Press to set autooff timer as the indicator lights. When all indicators are off, it means
continuous running.
1
2
: Flashes when bucket is full or not positioned. Please empty or reposition.
: Flashes when defrosting. It will return to dehumidifying when finished.
10
11
12
13
2 hours : The unit stops automatically after 2 hours.
4 hours : The unit stops automatically after 4 hours.
8 hours : The unit stops automatically after 8 hours.
12 hours : The unit stops automatically after 12 hours.
8
9
10
60-70% : The unit stops dehumidifying automatically when reaches 60-70% humidity.
50-60% : The unit stops dehumidifying automatically when reaches 50-60% humidity.
40-50% : The unit stops dehumidifying automatically when reaches 40-50% humidity.
EVertical louver setting
Press and the louver swings vertically in 3 ranges. The indicators light accordingly.
When all lights are off, the louver stops at the angle when you press.
Note:
Status Humidity indicator:
Note:
1.Vertical louver will go to the closed position after plugged or
shut down.
2.Make sure the slide cover has been opened before turn on.
3.The vertical louver will automatically turn upwards, and the
horizontal blades turn foreward when the unit is re-plugged
and turned on.
9
LOUVER SETTING
When room humidity is around above 60%: lights orange color.
When room humidity is around 50~60%: lights yellow color.
When room humidity is around below 50%: lights green color.
1. Switch off and unplug.
2. Clean air intake and outlet with a
soft cloth. Dust tends to accumulate
here.
3. Do not use petrol or solvents.
4. Clean the surface with a soft damp
cloth, using only water or mild detergent.
5. Wipe dry with a dry cloth.
NOTE: Never use water to wash the unit.
MAINTENANCE
Cleaning the unit
Humidity Status indicators
14
15
16
: The vertical louver swings upwards about 75o.
: The vertical louver swings forwards about 75o.
: The vertical louver swings in wide range about 150o.
Make sure the slide cover
has been opened
2HR
4HR
8HR
12HR
LOW
AUTO
HIGH
2HR
4HR
8HR
12HR
LOW
AUTO
HIGH
