Wharfedale Pro Opus Manuel utilisateur

opus

Opus 1

Opus 2

Opus 3

Tri-centre

Tri-surround

USER MANUAL

User Warnings

Quick Start Guide

About Your Loudspeaker

Specifications

Qua ity Assurance

Certificate of Qua ity Assurance

Systems and Driver Unit Test Reports

4 x White Cotton G oves

Accessories

CONTENTS

WITHIN THIS PACK

opus

Please read the following notes carefully. They will help you to install your loudspeakers correctly and safely.

Switch off the amp ifier and a sources before making connections to your sound system. When you switch on

the system or change sources, set the vo ume contro to minimum and turn up the eve gradua y.

The position of your Vo ume Contro is NOT a re iab e guide as to the maximum capabi ities of your system.

P aying the system with extreme settings of vo ume and tone contro s may damage the amp ifier and oudspeakers.

Do not connect oudspeaker termina s to the mains supp y.

Ensure that your oudspeakers are correct y wired and are in phase.

Do not subject your oudspeakers to excessive co d, heat or sun ight.

WARNING: To reduce the risk of fire or e ectrica shock do not expose this product to rain or moisture.

The product must not be exposed to dripping and sp ashing and no object fi ed with iquids – such as a vase

of f owers – shou d be p aced on the product.

No naked f ame sources – such as cand es – must be p aced on the product.

Do not p ace heavy objects on top of oudspeaker cabinets. If you p ay them with the gri es removed be

carefu to protect the drive units from chi dren and pets.

Do not use makeshift stands. A ways fit a manufacturer’ approved stand using the instructions and the

fixings provided. Your dea er wi advise you.

Do not attempt to dismant e the oudspeaker. There are no user serviceab e parts inside and you wi

inva idate the warranty.

Site your oudspeaker at east 0.5m away from TV sets and magnetic storage media.

USER WARNINGS

opus

QUICK SETUP GUIDE

(Opus Series)

opus

Setting Up the Opus Series

Safe y unpacking

Check you have

Loudspeaker preparation

Positioning stereo Hi-fi speakers

Connecting stereo Hi-fi speakers

Positioning AV speakers

Connecting AV speakers

Setting up AV systems

Looking after your oudspeakers

A ways take care when ifting heavy objects.

Lift the speakers out by their sides.

SAFELY UNPACKING

If possib e, keep the packaging in case you need to

move or return your speakers.

Carefu y remove each oudspeaker from its packing carton.

Be especia y carefu when removing the po ythene bag. The

speakers come with the p inth comp ete and a ready fitted.

The carton top says, “Open other end”. So you,

– Open the bottom

– Remove po ystyrene

– Open bag containing speaker

– Tape the carton f aps back

– Turn over carton with oudspeaker sti inside

– Lift carton off, eaving oudspeaker standing on the f oor

– Be carefu not to damage soft f oor surfaces with spikes

Your Opus speakers are heavy. Take care when

removing them from their packaging.

opus

CHECK YOU HAVE

Opus 1, 2, 3 Opus Tri-Centre Opus Tri-Surround

User Pack User Pack User Pack

Accessories:

• 4 G oves

• Long spike set (4)

• Soft f oor spike seats

• Foam pad (4)

• Bi-wire Links (4)

Accessories:

• 2 G oves

• Rubber Feet

• Bi-wire Links

Accessories:

• 2 G oves

• Rubber Feet

LOUDSPEAKER PREPARATION

opus

OPUS 1, 2 & 3 SPIKES

Your f oor standing Opus speakers are de ivered with the p inth and spikes a ready

fitted. Leve ing/seating the speaker is best achieved by adjusting either of the rear

spikes unti the speaker is stab e without rocking. Re ease the top knob, on the

underside. Turn spike out and down to eve . Re- ock top knob.

For wood or soft f oors 8 meta spike seats and se f-adhesive pads are provided for

use as required. A set of extra ong spikes for deep carpets are provided and may be

used as required.

WARNING: Opus speakers are heavy and the spikes can penetrate softer f oors

materia s over extended periods.

CONNECTIONS AND TERMINALS

Choosing and Preparing Cables

Specia ist audio cab e usua y offers better performance than genera purpose

‘be ’ or ‘zip’ wire.

Choose a cab e of suitab e diameter – cab e that is too thin wi imit the

dynamics of the sound and may impair the bass response. Audio cab e is

po arised, with two cores of different co ours, or often a raised rib of co oured

tracer in the case of twin cab e.

Sp it the twin cores to a depth of about 40mm. Carefu y strip the insu ation

from each end, eaving about 10mm of bare wire. If the cab e is stranded,

ight y twist to gather any oose strands.

Crossover Networks

OPUS front and centre oudspeakers use a specia y designed bi-wireab e

crossover pane with six termina binding posts. P ease fo ow the drawing care-

fu y to see the correct orientation of the oudspeaker termina s. The upper ter-

mina s connect to the treb e unit, the midd e pair to the mid-range and the

ower pair to the bass units. As supp ied, the treb e termina pair is connected

to the mid-range pair and bass termina pair via removab e meta straps.

These shou d be eft in p ace for standard sing e cab e insta ations.

The OPUS surround uses a conventiona twin termina crossover pane .

Connecting Loudspeaker Terminals

Unscrew the termina . Thread the bored end of each cab e through the ho e in

the bottom of the termina post. Ensure that there are no oose strands which

may touch adjacent termina s. Retighten the termina secure y.

NOTE: When connecting oudspeakers, the cab es to eft and right channe s

shou d be of equa ength, regard ess of the distance of the speakers from the

amp ifier. This app ies to front and rear channe s.

40mm

10mm

opus

POSITIONING FRONT SPEAKERS

Ang e speakers inward by 5º to 30º for a

c earer, more tunefu mid range.

If the loudspeakers are placed too close to the walls the bass will increase but may be

boomy and indistinct. If the loudspeakers are placed further away from the walls, the

inward angle may be increased by upto 0%, although this may restrict the width of the

optimum listening position. As personal taste plays a large role, experiment with different

configurations and play a wide range of programme before finalising the position of your

speakers.

Positioning the speakers. P ace the speakers so

that you are the same distance from each. The

distance between the speakers shou d be the

same as between you and the speakers.

For best resu ts the speakers shou d be at best

10 inches (20cm) in front of a wa and at east

30 inches (70cm) from any corner.

70cm

20cm

CONNECTING HIFI SPEAKERS

Sing e wired a sing e amp ifier, tri- ink bar is fitted

Tri or Bi-wired – a sing e amp ifier, with separate wires

to drive the bass/mid unit and the treb e unit.

Additiona inks are supp ied to a ow Bi-wiring.

Tri or Bi-amp ified – two or three amp ifiers. One drives

each section or 2 sections with Bi-wire ink e.g mid/hf.

(Remove a ink sections when Tri-Amping)

Important Note, p ease make sure that heavy mu ti-standard

cab es are we connected and c amped. Sing e oose strands

arcing can cause noise in the woofers ike a fau ty speaker.

opus

Using separate cables for

treble, mid and bass units in

Tri or Bi-wiring configuration

reduces intermodulation

effects and improves

headroom and clarity. To

Bi-wire, you will need to install

two lengths of twin core cable

between the amplifier and

each loudspeaker.

Unscrew each terminal a few

turns and remove the metal

tri-link straps. Use the

bi-link straps (supplied in

accessories) to connect the

treble and mid-range

terminals. Connect the cables

between the amplifier and the

loudspeakers as indicated and

re-tighten all the terminals

securely.

Note: Some amplifiers have

two pairs of output terminals

to facilitate bi-wiring but this is

not essential. The advantages

of bi-wiring are fully retained if

your amplifier has only one

pair of output terminals per

channel (as in the illustration).

R.SPKR L.SPKR

AMPLIFIER

R.SPKR L.SPKR

RIGHT

SPEAKER

LEFT

SPEAKER

RIGHT

SPEAKER

LEFT

SPEAKER

Amp
