Whalen WS3062426FP Manuel utilisateur

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.

PLEASE READ AND KEEP FOR FUTURE REFERENCE.

Whalen Furniture Mfg., Inc. Page 1 Factory No. DOGULU

Date: 2014-07-12 Rev 1

CHARLESTON 54'' Media Fireplace

Model # WS3062426FP

ADULT ASSEMBLY AND SET-UP REQUIRED

If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the

store where it was purchased. Please call our customer service number and have your instructions and

parts list ready to provide the model name, part name or factory number:

1-866-942-5362

Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday

Or visit our web site 24 hours a day, 7 days a week for product assistance at

www.whalenfurniture.com

Or e-mail your request to [email protected]

LOT NUMBER:

DATE PURCHASED: / /

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 2 Factory No. DOGULU

QUALITY GUARANTEE

We are confident that you will be delighted with your Whalen Furniture purchase.

Should this product be defective in workmanship or materials or fail under normal use, we will

repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is

designed to meet your highest expectations. We guarantee that you will immediately see the value of

our fine furniture.

This warranty gives you specific legal rights and you may also have other rights which vary from

province to province (state to state).

Customer Service: 1-866-942-5362

8:30 a.m. - 4:30 p.m., PST, Monday to Friday

www.whalenfurniture.com

MANUFACTURER: Whalen Furniture Mfg., Inc.

CATALOG: CHARLESTON 54'' Media Fireplace (WS3062426FP)

DATE OF MANUFACTURE: August 2014

MADE IN CHINA

MAXIMUM RECOMMENDED WEIGHT LOADS

FITS UP TO MOST 60” FLAT PANEL TVs

MAXIMUM LOAD 135 lb. (61.2 kg)

MAXIMUM LOAD 30 lb. (13.6 kg)

PLACE TV BEHIND THE STOPPER

THIS UNIT IS NOT INTENDED FOR USE WITH CRT TVS. USE ONLY WITH

FLAT PANEL TVS AND AUDIO/VIDEO EQUIPMENT MEETING RECOMMENDED SIZE AND

WEIGHT LIMITS. NEVER USE WITH LARGER/HEAVIER THAN RECOMMENDED FLAT PANEL

TVS OR EQUIPMENT. TO AVOID INSTABILITY, PLACE FLAT PANEL TV IN THE CENTRE OF

THE UNIT; DO NOT ALLOW TV TO OVERHANG UNIT IN ANY DIMENSION, IMPROPERLY

POSITIONED FLAT PANEL TVS, OR FLAT PANEL TVS OR OTHER EQUIPMENT THAT EXCEED

RECOMMENDED SIZE AND WEIGHT LIMITS COULD FALL OFF OR BREAK THE UNIT,

CAUSING POSSIBLE SERIOUS INJURY.

MAXIMUM LOAD 50 lb. (22.6 kg)

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 3 Factory No. DOGULU

Important

Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-

abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.

NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED

OFF WITH DAMP CLOTH.

Insert the Dowel at least half way by tapping lightly with a rubber mallet, IF NECESSARY.

CAM LOCK SYSTEM OPERATION

HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS

1. Screw the Cam Bolt into the threaded inserts on the panel. Connect both panels together; making sure Cam

Bolt goes into the pre-drilled hole on the end of panel for Cam Lock.

2. Insert the Cam Lock into the pre-drilled large hole on the panel. Make sure the arrow on the face of Cam

Lock faces out and points towards Cam Bolt.

3. Take a Phillips screwdriver and rotate the Cam Lock clockwise to lock the Cam Bolt in place.

4. Plug the Cam Lock Cover into the cross slot of the Cam Lock to conceal the Cam.

You are now ready to assemble the KD unit.

XXFINAL

12 43

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 4 Factory No. DOGULU

Parts and Hardware List

Please read completely through the instructions and verify that all listed parts and hardware are present

before beginning assembly.

Tools required: Allen wrench (provided) and Phillips screwdriver (not provided).

A- Mantel with Fireplace (1)

(8) Acrylic Stopper (1)

(11) Remote Control

with Battery (1)

(9) Tipping Restraint

Hardware Kit (2)

(Included in plastic bag)

B- Top Panel (1)

D- Side Panel (2) E- Partition Panel (1)

C- Upper Back Panel (1)

(1) Cam Lock

(12+1 extra) (4) Plastic Cover

(14+1 extra)

(6) Shelf Support

(8+ 1 extra) (7) Handle w/Bolts

(2)

G- Adjustable Shelf (2)F- Middle Support Leg (1)

(2) Cam Bolt

(12+1 extra)

(10) Touch-up Pen

(1) (12) Glue (1)

(5) 1/2” Washer Head

Screw (16+1 extra)

(3) M8x30 mm Wood

Dowel (10+1 extra)

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 5 Factory No. DOGULU

Assembly Instructions

NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled,

go back and fully tighten all bolts. This will make the assembly easier.

1. Unpack the unit and confirm that you have all the hardware and required parts listed. Assembly the unit on

a carpeted floor or the empty carton to avoid any scratch.

2. Lay down the Mantel with Fireplace (A), Securely screw the Middle Support Leg (F) into the designated

small hole in the bottom of bottom panel and make sure fully tighten, as shown below.

3. Locate the Mantel with Fireplace (A), Top Panel (B) with the holes facing up. Securely screw the Cam

Bolts (2) into the designated small holes, as shown above. Fully tighten with a Phillips screwdriver.

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 6 Factory No. DOGULU

Assembly Instructions

4. Insert five M8 x 30 mm Wood Dowels (3) into the inner holes of the Side Panel (D) and Partition Panel (E).

Tap in with a rubber mallet, if necessary. Make sure that you use a small amount of glue with both ends of

all dowels.

5. Align the drilled holes on the Top Panel (B) with the inserted Wood Dowels (3) on the Side Panel (D) and

Partition Panel (E), and then press them together. Secure the Top Panel (B) into place by engaging six Cam

Locks (1) (Refer to page 3 on Cam Lock system operation supplement).

6. Insert five M8 x 30 mm Wood Dowels (3) into the inner holes of the Side Panel (D) and Partition Panel (E).

Tap in with a rubber mallet, if necessary. Make sure that you use a small amount of glue with both ends of

all dowels.

7. Align the drilled holes on the Mantel with Fireplace (A) with the inserted Wood Dowels (3) on the Side

Panel (D) and Partition Panel (E), and then press them together. Secure the Mantel with Fireplace (A) into

place by engaging six Cam Locks (1) (Refer to page 3 on Cam Lock system operation supplement). Then

Plug Plastic Covers (4) to cover the Small Cam Locks for nice looking

E D

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 7 Factory No. DOGULU

Assembly Instructions

8. Open the doors and attach the Handle (7) to the front side of each door with the provided Handle Bolt (7).

9. With the doors open, insert the Shelf Supports (6) into the desired holes in the sides of the compartments.

Make sure you place the four Shelf Pins in the same level so the shelf is not tilted. Tilt and rest the

Adjustable Shelves (G) onto the Shelf Supports (6) with the finished edge facing the front of the unit.

10. Attach the upper back panel (C) to the back of assembled console and the mantel (A) by using the 1/2”

Washer Head Screws (5) through the pilot holes. As shown.

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 8 Factory No. DOGULU

Assembly Instructions

NOTE: You must install the Acrylic TV Stopper to prevent TV from tipping when placing your flat panel

television on the table-top.

11. Ask for assistance to place the assembled fireplace near the final installation location.

12. Remove the tape of the Acrylic Stopper (8) and place it in the cut-out of the Acrylic Stopper Template on

the Top Panel (B). Make sure that it is properly aligned before applying pressure.

13. Remove the Acrylic Stopper Template from the top panel carefully. As shown below.

14. Ask for assistance to position the assembled fireplace at the desired location against a wall. In case of

uneven floor, floor levelers are provided at the bottom of the mantel. If necessary, adjust the floor levelers

by hand to correct tilting, until the unit is level.

15. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach

the tip-over restraint to the unit and the wall.

NOTE: Young children can be seriously injured by tipping furniture. You must install the Tipping

Restraint Hardware with the unit to prevent the unit from tipping, causing any accidents or damage. The

tipping restraints are intended only as a deterrent, they are not a substitute for proper adult supervision.

The tipping restraints are not earthquake restraints. If you wish to add the extra security of earthquake

restraints, they must be purchased and installed separately.

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 9 Factory No. DOGULU

Assembly Instructions

16. Connect the fireplace to the power transformer. Follow the separated operating manual of electric fireplace

insert to control your fireplace.

Tools required: Phillips Screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet.

Care and Maintenance

Use a soft, clean cloth that will not scratch the surface when dusting.

Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an

inconspicuous area.

Using solvents of any kind on your furniture may damage the finish.

Never use water to clean your furniture as it may cause damage to the finish.

Always use coasters under beverage glasses and flowerpots.

Liquid spills should be removed immediately. Using a soft clean cloth, blot the spill gently. Avoid

rubbing.

Always use protective pads under hot dishes and plates. Heat can cause chemical changes that may

create spotting within the furniture finish.

Stains or marks from crayons or ink markers will be difficult to remove.

In the event that your furniture is stained or otherwise damaged during use, we recommend that

you call a professional to repair your furniture.

Check bolts/screws periodically and tighten them if necessary.

Model# WS3062426FP

Please call for replacement parts or assistance: 1-866-942-5362

Whalen Furniture Mfg., Inc. Page 10 Factory No. DOGULU

Further advice about wood furniture care

It is best to keep your furniture in a climate-controlled environment. Extreme temperature and

humidity changes can cause fading, warping, shrinking and splitting of wood. It is advised to keep

furniture away from direct sunlight as sun may damage the finish.

Proper care and cleaning at home will extend the life of your purchase. Following these important and

helpful tips will enhance your furniture as it ages.

Cleaning trim for fireplace

Clean the metal trim using a soft cloth, slightly dampened with citrus oil based product and buff with a

clean soft cloth. DO NOT use brass polish or household cleaners as these products will damage the

metal trim. Citrus oil based products can be obtained at supermarkets or hardware stores.

A Touch-up Pen has been provided to repair any small nicks or scratches that may occur during

assembly or shipping.

We hope you enjoy your purchase for many years.

Thank you for choosing Whalen Furniture!
