WFE Technology Corp.
1
■ Content
•Specifcation ................................................................................................... 02
•Appearance .......................................................................................... 03
•Program New User Card/Program New Pin Code........................................... 04
•Program New Finger Print/Open door with User Card ( Lock status )........... 05
•Open door with Pin Code / Open door with Finger Print / Backup Mechanical Key............06
•Delete All User Cards / Delete All Pin Codes................................................07
•Delete Individual Pin Code/Delete All Finger Print.............................. 08
•Set Voice Volume /How to enable key alarm function....................................... 09
•How to Activate / Deactivate key alarm...........................................10
•Deactivate Security Mode/Low Battery Warning/External Power Supply........... 11
•Troubleshooting Q & AQ&A........................................................................................ 12
Measurements indicated in mm
20 17.5 75
130
75
67.5 66
183.6
320
WFE Technology Corp.
2
■ SPECIFICATIONS
•Door thickness: (L379) 40mm ~ 100mm / (L779) 35mm~60mm
•Latch & Deadbolt: Solid Brass with Steel Roller
•Anti-panic Exit Function
•Mechanical Key Override
•Fingerprint + M-touch Panel keypad + Mifare Reader
•Transponder: Mifare Classic (13.56Mhz)
•Reading Distance up to 30 mm
•Total User Code & Card: 90
•Adjustable Voice Volume
•Battery Life: 60,000 Operation or 2 Years Standby
•Battery Spec: AAA 1.5V x 4pcs
•Smart Sleep Mode
•Acoustic Low Power Warning
•Operation Temperature:-20°C ~ 60°C
•Support 9V External Power Supply
•US ANSI Grade 1 Mortise Lock
•UL 3H Fire Rated Mortise Lock
WFE Technology Corp.
3
■ Apperance
Deadbolt
Key Pad
Card Reading Area
9V Battery Contact Point
Mechanical Cylinder
Mechanical Cylinder Slide Cover
Outer Handle
Finger Print Sensor
Latch
Tamper-proof
Sensor
Side Plate
Inner Handle
AAA Battery X 4pcs
Inner Knob
Battery Slide Cover
WFE Technology Corp.
4
■ Operation
Program New User Card
● You could program user cards continuously when blue light ashes
Step 1:
Step 1:
Step 2:
Step 2:
Step 3:
Step 3:
Approach the card you
would like to program
as user card, and there
will be a voice sound
meaning program is
successful.
Approach reading area
with programming card,
there will be a voice
sound instruction, and
number (1,2,3) light
ashes.
Press digit one, there
will be a voice sound,
and blue light ashes.
● Press "touch" button and repeat step 3 to program new pin codes
during white light ashing.
● When key in digits more or less than 6, there will short beeps X 4
and red lights X 2.
Program New Pin Code
Approach reading area
with programming card,
there will be a voice
sound instruction, and
number (1,2,3) light
ashes.
Press digit two, there
will be a voice sound,
numbers light up and blue
light ashes.
Key in 6 digit pin codes
and press as end up.
there will be a voice
sound meaning new
code is programmed
successfully.
Remark
Remark
WFE Technology Corp.
5
Open door with User Card ( Lock status )
Step 1: Step 2:
● When user cards are
wrong, there will red
lightsX 2.
Approach reading area
with user cards, and
there will be a voice
sound meaning door
unlock.
White numbers light up
in cycles and open door.
● The max. is 20 sets to program nger prints.
● Water will aect the sensitivities, so please swab the water and make sure there is no
water on the sensor before using your nger print.
● Kid nger prints may change during the growth. Please reprogram again when it is invalid.
Program New Finger Print
Step 2: Step 3: Step 4:
Press digit three,
there will be a voice
sound, and blue light
ashes.
Press the nger
print wakeup button
and follow the voice
instruction to press
the sensor with your
nger print.
Follow the voice
instruction to
remove your nger
print and repress
until you hear voice
instruction, nger
print is programmed.
Approach
reading area with
programming card,
there will be a voice
sound instruction,
and number (1,2,3)
light ashes.
Step 1:
Remark
Remark
WFE Technology Corp.
6
Open door with Finger Print ( Lock status )
Backup Mechanical Key ( Lock status )
Open door with Pin Code ( Lock status )
● When key in wrong pin
codes 5 times, door
key pad will be locked
automatically and. key
pad will not response to
any codes until using
programmed user
cards to open door or 3
minutes pass.
● When pin codes are
wrong, there will short
beeps X 4 and red
lightsX 2.
● Press wakeup "TOUCH"
button again, and rekey
the pin codes when
pressing wrong number.
Step 2:
Step 2:
Step 2:
Press wakeup
"TOUCH" button
and white numbers
light up.
Press 6 digit pin codes
and end with , and there
will be a voice sound with
white numbers light up
in cycles meaning door
unlock, and open door.
Step 1:
Step 1:
Step 1:
Hold the outer handle and
press nger print wakeup
button. When LED light
up, press the sensor with
thumb, and there will be a
voice sound meaning door
unlock.
Slide the cover
down to bottom.
White numbers
light up in cycles
meaning door
unlock, and open
door.
Use mechanical key
to unlock and open
door.
● Using mechanical key
does not go through
electronic control, so it
will trigger alarm.
Please use programmed
user cards or pind codes
to disarm the alarm.
Remark
Remark
WFE Technology Corp.
7
Delete All User Cards
Step 2: Step 3: Step 4:
Press digit one,
there will be a voice
sound, and blue light
ashes.
Press wakeup
"TOUCH" button and
numbers light up.
Key in , and
there will be a voice
sound instruction
meaning all user
cards are deleted,
then light off.
Approach
reading area with
programming card,
there will be a voice
sound instruction,
and number (1,2,3)
light ashes.
Step 1:
Delete All Pin Codes
Approach reading area
with programming card,
there will be a voice
sound instruction, and
number (1,2,3) light
ashes.
Step 1: Step 2: Step 3:
Press digit two, there
will be a voice sound,
numbers light up and
blue light ashes.
Key in , and
there will be a voice
sound instruction
meaning all pin codes
are deleted, then light
off.
WFE Technology Corp.
8
Delete All Finger Print
Approach reading area
with programming card,
there will be a voice
sound instruction, and
number (1,2,3) light
ashes.
Step 1: Step 2: Step 3:
Press digit three, there
will be a voice sound,
numbers light up and
blue light ashes.
Press wakeup "TOUCH"
button and numbers
light up.
Key in , and
there will be a voice
sound instruction
meaning all user cards
are deleted, then light
off.
● Press "touch" button and repeat step 3 to program new pin codes during
blue light ashing.
● When pin codes are wrong, there will short beeps X 4 and red lights X 2.
Delete Individual Pin Code
Step 1: Step 2: Step 3:
Approach reading area
with programming card,
there will be a voice
sound instruction, and
number (1,2,3) light
ashes.
Press digit two, there
will be a voice sound,
numbers light up and
blue light ashes.
Key in the pin code you
would like to delete, and
then . There will be
a voice sound meaning
the pin code is deleted.
Remark
WFE Technology Corp.
9
Set Voice Volume
Approach
reading area with
programming card,
there will be a voice
sound instruction,
and number (1,2,3)
light ashes.
Step 1: Step 2: Step 4:Step 3:
Press digit two,
there will be a voice
sound, numbers light
up and blue light
ashes.
Press( 3) to
enter voice volume
setting
press:
001# to change to
silence mode with
two short beeps.
or 002#, to change
to low voice mode
with two short
beeps.
or 003#, to change
to loud voice mode
with two short
beeps.
How to enable key alarm function
Approach
reading area with
programming card,
there will be a voice
sound instruction,
and number (1,2,3)
light ashes.
Step 1: Step 2: Step 4:Step 3:
Press digit two,
there will be a voice
sound, numbers light
up and blue light
ashes.
Press( 3) to enter
alarm setting
『001#』：
Disable key alarm
『002#』：
Enable key alarm
WFE Technology Corp.
10
Approach reading
area with user card.
Step 1: Step 2:
Steady the user cards at reading area for 5
seconds, and there will be long beep with
blue light on meaning the security mode is
setting.
5
s
e
c
Press "TOUCH"
button and numbers
light up.
Step 1: Step 2: Step 3:
Key in pin codes
and . There will
be a voice sound,
door lock, no matter
it is lock or unlock
status.
there will be long
beep with blue light
on meaning the
security mode is
setting.
How to Activate / Deactivate key alarm
Activate by card：
Activate by Pin code：
blue light
blue light
