Westomatic Primo Compact Manuel utilisateur

CLEANING MANUAL

Daily / Weekly

Cleaning instructions

Westomatic Vending Services Ltd

Units 7 – 8 Block 4 Forde Court, Forde Road

Newton Abbot, Devon

TQ12 4BT

+44 (0) 1626 323100

sales@westomatic.com

www.westomatic.com

PRIMO COMPACT

Cleaning Manual

Page 1of 11 P-COM-Cleaning

Primo Compact Fresh Milk

Description

Qty Part Number

1 Litre Milk line clear (Acid based)

1053009

Brewer cleaning tablets – 50 tablets

1015015

Screen Cleaner 100ml

1015014

Microfibre cloth

1015012

Primo Compact Instant Milk

Description

Qty Part Number

Microfibre cloth

1015012

Screen Cleaner 100ml

1015014

Brewer cleaning tablets – 50 tablets

1015015

To follow the Primo Compact cleaning guide you will

need the following customer care kit.

FOR PRIMO COMPACT WITH FRESH MILK OPTION

•1 Litre Milk line cleaner (Acid based)

•Brewer cleaning tablets – 50 tablets

•Screen cleaner 100ml

•Microfibre Cloth

FOR PRIMO COMPACT INSTANT ONLY

•Microfibre Cloth

•Screen Cleaner 100ml

•Brewer cleaning tablets – 50 tablets

These kits can be re-ordered on

WestoNET

call 01626 323100

PRIMO COMPACT

Cleaning Manual

Page 2of 11 P-COM-Cleaning

DAILY CLEANING

These instructions show the steps for daily cleaning

including:

•Empty and clean the waste container and the trays

•Clean the coffee machine

Before you start, carefully read the “Safety instructions and

environmental information” provided with the machine.

Remove the drip tray

Rinse and clean the drip tray

Remove the cup tray grid

PRIMO COMPACT

Cleaning Manual

Page 3of 11 P-COM-Cleaning

DAILY CLEANING

Clean the cup tray

Open the machine with the key

Remove the waste container

Empty and clean the waste container.

Remove the outlet cover:

1. Lift the tab on the inside of the machine

2. Pull the outlet cover

out from the door

PRIMO COMPACT

Cleaning Manual

Page 4of 11 P-COM-Cleaning

DAILY CLEANING

Clean the outlet

Place all parts back into the machine

Clean the back cover behind the cup tray with a damp

cloth.

If you have accessories like a cup warmer or milk

cooler, then clean them with a damp cloth as well.

The machine is now ready to use

If you have a milk cooler continue with the Fresh Milk system cleaning before refill.

PRIMO COMPACT

Cleaning Manual

Page 5of 11 P-COM-Cleaning

WEEKLY CLEANING

These instructions show the steps for weekly cleaning including:

•Clean the ingredient mixer parts

•Clean the bean supply parts and grinder

Before you start, carefully read the “Safety instructions

and environmental information” provided with the

machine.

On the touchscreen:

Select the machine menu

Select CLEAN MACHINE

The steps on the screen will guide you through the

cleaning procedure.

Open the machine with the key

PRIMO COMPACT

Cleaning Manual

Page 6of 11 P-COM-Cleaning

WEEKLY CLEANING

Open the lid

Turn the canister outlets upwards

Remove the instant canisters by

lifting them and pulling them

forward

Turn the mounting ring

counterclockwise to

unlock the mixer bowl

Remove the mixer bowl

PRIMO COMPACT

Cleaning Manual

Page 7of 11 P-COM-Cleaning

WEEKLY CLEANING

Remove the hose from the mixer bowl

Remove the hose and the coffee

splitter

Remove the coffee hose from the coffee splitter

Remove the mixer fan

1. Turn the mounting ring further clockwise

2. Remove the mounting ring

PRIMO COMPACT

Cleaning Manual

Page 8of 11 P-COM-Cleaning

WEEKLY CLEANING

Remove the dust tray

Clean and rinse the parts

Note: If you have a hygiene kit with duplicate

parts you can place these in the machine and

clean the removed parts later

Clean the canister area using the brush

Note: The cleaning brush is found on left side in

the machine.

Place the dust tray back

1. Carefully re-place the mounting ring

2. Lock the ring by rotating it clockwise

PRIMO COMPACT

Cleaning Manual

Page 9of 11 P-COM-Cleaning

WEEKLY CLEANING

Carefully position the mixer fan and press it firmly

until it fits

1. Attach the hoses to the coffee splitter

2. Re-place the coffee splitter in its holder

Place the instant canister back in the machine

Make sure that the canister connects to the rotor on the back

and falls into the hole on the front

Rotate the canister outlets

downwards into the mixer bowl

Close the lid
