WD VelociRaptor®

Workstation Hard Drives

WD VelociRaptor drives offer an unmatched combination of

high performance and high reliability, perfect for

workstations, high-end video and photo editing, low-end

servers and performance enthusiasts’ systems. Comes with

a 3.5-inch mounting frame for easy installation into today's

high-performance systems and chassis.

INTERFACE

SATA 6 Gb/s

WIDTH/HEIGHT

3.5-inch/1-inch

ROTATIONAL SPEED

10,000 RPM

CAPACITIES

250 and 500 GB; 1 TB

MODEL NUMBERS

WD1000DHTZ

WD5000HHTZ

WD2500HHTZ

Note: Not all products may be

available in all regions of the

world.

Ultra fast

Designed around a 10,000 RPM spin

speed, these SATA 6 Gb/s drives include

a 64 MB cache and deliver the ultimate

performance for photo and video editing.

Rock-solid reliability

With 1.4 million hours MTBF, these drives

have the highest available reliability rating

on a high capacity SATA drive.

High capacity

State-of-the-art technology delivers a

balance of high performance and high

capacity perfect for data-intensive

workloads that require large amounts of

storage such as video editing, 3D

rendering and scientific modeling.

Ultra-cool operation

Consumes less idle power and uses

similar active power as the previous

generation WD VelociRaptor, while

offering double the capacity and higher

performance.

Advanced Format (AF)

Technology adopted by WD and other

drive manufacturers as one of multiple

ways to continue growing hard drive

capacities. AF is a more efficient media

format that enables increased areal

densities.

IcePack™ mounting frame

The 2.5-inch WD VelociRaptor is

enclosed in a backplane-ready 3.5-inch

enterprise-class mounting frame with a

built-in heat sink that keeps this powerful

little drive extra cool when installed in

high-performance desktop chassis.

Rotary Acceleration Feed

Forward (RAFF™)

Optimizes operation and performance

when the drives are used in vibration-

prone, multi-drive chassis.

NoTouch™ ramp load

technology

The recording head never touches the

disk media ensuring significantly less

wear to the recording head and media as

well as better drive protection in transit.

Environmentally conscious

In addition to being ROHS compliant, this

generation of WD VelociRaptor is also a

halogen free design.

Pre-emptive Wear Leveling

(PWL)

Ensures reliability for applications that

perform a high incidence of read/write

operations at the same physical location

on the disk.

5-year limited warranty

Product Benefits

Applications

High-performance computing, 3D rendering, digital content creation and editing, scientific computing and image management.

WD VelociRaptor

Specifications11 TB 500 GB 250 GB

Model number WD1000DHTZ WD5000HHTZ WD2500HHTZ

Interface SATA 6 Gb/s SATA 6 Gb/s SATA 6 Gb/s

Formatted capacity 1 TB 500 GB 250 GB

User sectors per drive 1,953,525,168 976,773,168 488,397,168

Advanced Format (AF) Yes Yes Yes

SATA latching connector Yes Yes Yes

Form factor 3.5-inch 3.5-inch 3.5-inch

RoHS compliant2Yes Ye s Yes

Performance

Data transfer rate (max)

Buffer to host

Host to/from drive (sustained)

6 Gb/s

200 MB/s

6 Gb/s

200 MB/s

6 Gb/s

200 MB/s

Cache (MB) 64 64 64

Rotational speed (RPM) 10,000 10,000 10,000

Average drive ready time (sec) 8 8 8

Reliability/Data Integrity

Load/unload cycles3600,000 600,000 600,000

Non-recoverable read errors per bits read <10 in 1016 <10 in 1016 <10 in 1016

Limited warranty (years)4555

Power Management

12VDC (A, max) 1.8 1.8 1.8

Average power requirements (W)

Random Read/Write

Sequential Read/Write

Idle

Standby and Sleep

5.1

5.8

4.2

1.1

5.1

5.8

4.2

1.1

5.1

5.8

4.2

1.1

Environmental Specifications5

Temperature (°C)

Operating

Non-operating

5 to 55

-40 to 70

5 to 55

-40 to 70

5 to 55

-40 to 70

Shock (Gs)

Operating (2 ms, read/write)

Operating (2 ms, read)

Non-operating (2 ms)

300

Average acoustics (dBA)6

Idle mode

Performance seek mode

Physical Dimensions

Height (in./mm, max) 1.028/26.1 1.028/26.1 1.028/26.1

Length (in./mm, max) 5.787/147 5.787/147 5.787/147

Width (in./mm, ± .01 in.) 4/101.6 4/101.6 4/101.6

Weight (lb./kg, ± 10%) 1.10/0.50 1.10/0.50 1.10/0.50

1As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576

bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabit per second (Gb/s) = one billion bits per second. Effective maximum SATA 3 Gb/s transfer rate calculated according to the Serial ATA specification published by the SATA-

IO organization as of the date of this specification sheet. Visit www.sata-io.org for details.

2WD hard drive products manufactured and sold worldwide after June 1, 2006, meet or exceed Restriction of Hazardous Substances (RoHS) compliance requirements as mandated by the RoHS Directive 2011/65/EU.

3Controlled unload at ambient condition

4The term of the limited warranty may vary by region. Visit support.wdc.com/warranty for details.

5No non-recoverable errors during operating tests or after non-operating tests.

6Sound power level.

Western Digital, WD, the WD logo, WD VelociRaptor, and Put Your Life On It are registered trademarks in the U.S. and other countries; and IcePack, RAFF, NoTouch, and FIT Lab are trademarks of

Western Digital Technologies, Inc. Other marks may be mentioned herein that belong to other companies. Product specifications subject to change without notice.

Western Digital

3355 Michelson Drive, Suite 100

Irvine, California 92612

U.S.A.

2879-701284-A05 Apr 2012

For service and literature:

http://support.wdc.com

www.westerndigital.com

800.ASK.4WDC North America

(800.475.4932)

800.832.4778 Spanish

+800.6008.6008 Asia Pacific

00800.27549338 Europe

(toll free where available)

+31.880062100 Europe/Middle East/Africa

Canada ICES-003 Class B / NMB-003 Classe B
