WEG CFW700 Manuel utilisateur

Frequency Inverter

Convertidor de Frecuencia

Inversor de Frequência

CFW700

Motors | Automation | Energy | Transmission & Distribution | Coatings

Quick Parameter Reference, Faults and Alarms

Referencia Rápida de los Parámetros, Fallas y Alarmas

Referência Rápida dos Parâmetros, Falhas e Alarmes

Quick Parameter Reference,

Faults and Alarms

Series: CFW700

English

Document: 10000849536 / 04

Software Version: 2.0X

Date: 01/2017

CFW700 | 3

Quick Parameter Reference, Faults and Alarms

English

QUICK PARAMETER REFERENCE, FAULTS AND ALARMS

Param. Description Adjustable Range Factory

Setting

User

Setting Prop. Groups Pag.

P0000 Access to Parameters 0 to 9999 0 5-1

P0001 Speed Reference 0 to 18000 rpm ro READ 16-1

P0002 Motor Speed 0 to 18000 rpm ro READ 16-1

P0003 Motor Current 0.0 to 4500.0 A ro READ 16-1

P0004 DC Link Voltage (Ud) 0 to 2000 V ro READ 16-2

P0005 Motor Frequency 0.0 to 1020.0 Hz ro READ 16-2

P0006 VFD Status 0 = Ready

1 = Run

2 = Undervoltage

3 = Fault

4 = Self-Tuning

5 = Conﬁguration

6 = DC Braking

7 = STO

ro READ 16-2

P0007 Motor Voltage 0 to 2000 V ro READ 16-3

P0009 Motor Torque -1000.0 to 1000.0 % ro READ 16-3

P0010 Output Power 0.0 to 6553.5 kW ro READ 16-4

P0011 Output Cos phi 0.00 to 1.00 ro READ 16-4

P0012 DI8 to DI1 Status Bit 0 = DI1

Bit 1 = DI2

Bit 2 = DI3

Bit 3 = DI4

Bit 4 = DI5

Bit 5 = DI6

Bit 6 = DI7

Bit 7 = DI8

ro READ,

I/O

13-9

P0013 DO5 to DO1 Status Bit 0 = DO1

Bit 1 = DO2

Bit 2 = DO3

Bit 3 = DO4

Bit 4 = DO5

ro READ,

I/O

13-14

P0014 AO1 Value 0.00 to 100.00 % ro READ,

I/O

13-5

P0015 AO2 Value 0.00 to 100.00 % ro READ,

I/O

13-5

P0018 AI1 Value -100.00 to 100.00 % ro READ,

I/O

13-1

P0019 AI2 Value -100.00 to 100.00 % ro READ,

I/O

13-1

P0022 Frequency Input 3.0 to 6500.0 Hz ro READ 13-23

P0023 Software Version 0.00 to 655.35 ro READ 6-1

P0028 Accessories Conﬁguration 0000h to FFFFh ro READ 6-2

P0029 Power Hardware

Conﬁguration

Bit 0 to 5 = Rated Current

Bit 6 and 7 = Rated Voltage

Bit 8 = RFI Filter

Bit 9 = Safety Relay

Bit 10 = (0)24 V/(1) DC Link

Bit 11 = Always 0

Bit 12 = Dyn. Braking IGBT

Bit 13 = Special

Bit 14 and 15 = Reserved

ro READ 6-2

P0030 IGBTs Temperature -20.0 to 150.0 °C ro READ 15-3

P0034 Internal Air Temperature -20.0 to 150.0 °C ro READ 15-3

P0036 Heatsink Fan Speed 0 to 15000 rpm ro READ 16-5

4 | CFW700

Quick Parameter Reference, Faults and Alarms

English

Param. Description Adjustable Range Factory

Setting

User

Setting Prop. Groups Pag.

P0037 Motor Overload Status 0 to 100 % ro READ 16-5

P0038 Encoder Speed 0 to 65535 rpm ro READ 16-5

P0039 Encoder Pulse Counter 0 to 40000 ro READ 16-6

P0042 Powered Time 0 to 65535 h ro READ 16-6

P0043 Enabled Time 0.0 to 6553.5 h ro READ 16-6

P0044 kWh Output Energy 0 to 65535 kWh ro READ 16-6

P0045 Enabled Fan Time 0 to 65535 h ro READ 16-7

P0048 Present Alarm 0 to 999 ro READ 16-7

P0049 Present Fault 0 to 999 ro READ 16-7

P0050 Last Fault 0 to 999 ro READ 16-8

P0054 Second Fault 0 to 999 ro READ 16-8

P0058 Third Fault 0 to 999 ro READ 16-8

P0062 Fourth Fault 0 to 999 ro READ 16-8

P0066 Fifth Fault 0 to 999 ro READ 16-9

P0090 Last Fault Current 0.0 to 4500.0 A ro READ 16-9

P0091 Last Fault DC Link Voltage 0 to 2000 V ro READ 16-9

P0092 Last Fault Speed 0 to 18000 rpm ro READ 16-9

P0093 Last Fault Reference 0 to 18000 rpm ro READ 16-10

P0094 Last Fault Frequency 0.0 to 1020.0 Hz ro READ 16-10

P0095 Last Fault Motor Voltage 0 to 2000 V ro READ 16-10

P0096 Last Fault DIx Status Bit 0 = DI1

Bit 1 = DI2

Bit 2 = DI3

Bit 3 = DI4

Bit 4 = DI5

Bit 5 = DI6

Bit 6 = DI7

Bit 7 = DI8

ro READ 16-10

P0097 Last Fault DOx Status Bit 0 = DO1

Bit 1 = DO2

Bit 2 = DO3

Bit 3 = DO4

Bit 4 = DO5

ro READ 16-11

P0100 Acceleration Time 0.0 to 999.0 s 20.0 s BASIC 12-1

P0101 Deceleration Time 0.0 to 999.0 s 20.0 s BASIC 12-1

P0102 Acceleration Time 2 0.0 to 999.0 s 20.0 s 12-1

P0103 Deceleration Time 2 0.0 to 999.0 s 20.0 s 12-1

P0104 Ramp Type 0 = Linear

1 = S Curve

012-2

P0105 1st/2nd Ramp Selection 0 = 1st Ramp

1 = 2nd Ramp

2 = DIx

3 = Serial

4 = CO/DN/DP

5 = SoftPLC

2cfg 12-3

P0120 Speed Reference Backup 0 = Inactive

1 = Active

112-3

P0121 Keypad Reference 0 to 18000 rpm 90 rpm 12-4

P0122 JOG/JOG+ Reference 0 to 18000 rpm 150 (125)

rpm

12-4

12-5

P0123 JOG- Reference 0 to 18000 rpm 150 (125)

rpm

Vector 12-5

P0132 Maximum Overspeed Level 0 to 100 % 10 % cfg 12-5

P0133 Minimum Speed 0 to 18000 rpm 90 (75) rpm BASIC 12-6

CFW700 | 5

Quick Parameter Reference, Faults and Alarms

English

Param. Description Adjustable Range Factory

Setting

User

Setting Prop. Groups Pag.

P0134 Maximum Speed 0 to 18000 rpm 1800 (1500)

rpm

BASIC 12-6

P0135 Maximum Output Current 0.2 to 2 x Inom-HD 1.5 x Inom-HD V/f,

VVW

BASIC 9-7

P0136 Manual Torque Boost 0 to 9 According

to the

inverter

model

V/f BASIC 9-2

P0137 Automatic Torque Boost 0.00 to 1.00 0.00 V/f 9-2

P0138 Slip Compensation -10.0 to 10.0 % 0.0 % V/f 9-3

P0139 Output Current Filter 0.0 to 16.0 s 0.2 s V/f,

VVW

9-4

P0142 Maximum Output Voltage 0.0 to 100.0 % 100.0 % cfg, Adj 9-5

P0143 Intermediate Output

Voltage

0.0 to 100.0 % 50.0 % cfg, Adj 9-5

P0144 3 Hz Output Voltage 0.0 to 100.0 % 8.0 % cfg, Adj 9-5

P0145 Field Weakening Speed 0 to 18000 rpm 1800 rpm cfg, Adj 9-5

P0146 Intermediate Speed 0 to 18000 rpm 900 rpm cfg, Adj 9-5

P0150 V/f DC Regulation Type 0 = Ramp Hold

1 = Ramp Acceleration

0 cfg, V/f,

VVW

9-10

P0151 V/f DC Regulation Level 339 to 1000 V 800 V V/f, V V W 9-11

P0152 V/f DC Regulation P Gain 0.00 to 9.99 1.50 V/f,

VVW

9-11

P0153 Dynamic Braking Level 339 to 1000 V 748 V 14-1

P0156 100 % Speed Overload

Current

0.1 to 1.5 x Inom-ND 1.05 x Inom-ND 15-4

P0157 50 % Speed Overload

Current

0.1 to 1.5 x Inom-ND 0.9 x Inom-ND 15-4

P0158 5 % Speed Overload

Current

0.1 to 1.5 x Inom-ND 0.65 x Inom-ND 15-4

P0159 Motor Tripping Class 0 = Class 5

1 = Class 10

2 = Class 15

3 = Class 20

4 = Class 25

5 = Class 30

6 = Class 35

7 = Class 40

8 = Class 45

1cfg 15-5

P0160 Speed Regulation

Optimization

0 = Normal

1 = Saturated

0 cfg,

Vector

11-13

P0161 Speed Proportional Gain 0.0 to 63.9 7.4 Vector 11-13

P0162 Speed Integral Gain 0.000 to 9.999 0.023 Vector 11-13

P0163 LOC Reference Offset -999 to 999 0Vector 11-14

P0164 REM Reference Offset -999 to 999 0Vector 11-14

P0165 Speed Filter 0.012 to 1.000 s 0.012 s Vector 11-14

P0166 Speed Differential Gain 0.00 to 7.99 0.00 Vector 11-15

P0167 Current Proportional Gain 0.00 to 1.99 0.50 Vector 11-15

P0168 Current Integral Gain 0.000 to 1.999 0.010 Vector 11-15

P0169 Maximum + Torque

Current

0.0 to 350.0 % 125.0 % Vector 11-22

P0170 Maximum - Torque Current 0.0 to 350.0 % 125.0 % Vector 11-22

P0175 Flux Proportional Gain 0.0 to 31.9 2.0 Vector 11-16

P0176 Flux Integral Gain 0.000 to 9.999 0.020 Vector 11-16

P0178 Rated Flux 0 to 120 % 100 % Vector 11-16

6 | CFW700

Quick Parameter Reference, Faults and Alarms

English

Param. Description Adjustable Range Factory

Setting

User

Setting Prop. Groups Pag.

P0180 Iq* after I/f 0 to 350 % 10 % Sless 11-17

P0182 Speed for I/f Activation 0 to 90 rpm 18 rpm Sless 11-17

P0183 Current in I/f Mode 0 to 9 1 Sless 11-18

P0184 DC Link Regulation Mode 0 = With Losses

1 = Without Losses

2 = Enable/Disable DIx

1 cfg,

Vector

11-24

P0185 DC Link Regulation Level 339 to 1000 V 800 V Vector 11-25

P0186 DC Link Proportional Gain 0.0 to 63.9 26.0 Vector 11-25

P0187 DC Link Integral Gain 0.000 to 9.999 0.010 Vector 11-25

P0190 Maximum Output Voltage 0 to 600 V 440 V Vector 11-17

P0191 Encoder Zero Search 0 = Inactive

1 = Active

012-20

P0192 Encoder Zero Search

Status

0 = Inactive

1 = Finished

0ro READ 12-20

P0200 Password 0 = Inactive

1 = Active

2 = Change Password

1HMI 5-2

P0202 Control Type 0 = V/f 60 Hz

1 = V/f 50 Hz

2 = V/f Adjustable

3 = VV W

4 = Sensorless

5 = Encoder

0cfg 9-5

P0204 Load/Save Parameters 0 = Not Used

1 = Not Used

2 = Reset P0045

3 = Reset P0043

4 = Reset P0044

5 = Load 60 Hz

6 = Load 50 Hz

7 = Load User 1

8 = Load User 2

9 = Save User 1

10 = Save User 2

0cfg 7-1

P0205 Main Display Parameter

Selection

0 to 1199 2 HMI 5-3

P0206 Secondary Display

Parameter Selection

0 to 1199 1 HMI 5-3

P0207 Bar Graph Parameter

Selection

0 to 1199 3 HMI 5-3

P0208 Main Display Scale Factor 0.1 to 1000.0 % 100.0 % HMI 5-4

CFW700 | 7

Quick Parameter Reference, Faults and Alarms

English

Param. Description Adjustable Range Factory

Setting

User

Setting Prop. Groups Pag.

P0209 Main Display Engineering

Unit

0 = None

1 = V

2 = A

3 = rpm

4 = s

5 = ms

6 = N

7 = m

8 = Nm

9 = mA

10 = %

11 = °C

12 = CV

13 = Hz

14 = HP

15 = h

16 = W

17 = kW

18 = kWh

19 = H

20 = According to P0510

21 = According to P0512

22 = According to P0514

23 = According to P0516

3HMI 5-4

P0210 Main Display Decimal Point 0 = wxyz

1 = wxy.z

2 = wx.yz

3 = w.xyz

4 = According to P0511

5 = According to P0513

6 = According to P0515

7 = According to P0517

0HMI 5-4

P0211 Secondary Display Scale

Factor

0.1 to 1000.0 % 100.0 % HMI 5-4

P0212 Secondary Display

Decimal Point

0 = wxyz

1 = wxy.z

2 = wx.yz

3 = w.xyz

4 = According to P0511

5 = According to P0513

6 = According to P0515

7 = According to P0517

0HMI 5-4

P0213 Bar Full Scale 1 to 65535 1 HMI 5-5

P0216 HMI Backlighting 0 to 15 15 HMI 5-5

P0217 Zero Speed Disable 0 = Inactive

1 = Active (N* and N)

2 = Active (N*)

0cfg 12-7

P0218 Condition to Leave Zero

Speed Disable

0 = Reference or Speed

1 = Reference

012-7

P0219 Delay for Zero Speed

Disable

0 to 999 s 0 s 12-8

P0220 LOC/REM Selection

Source

0 = Always LOC

1 = Always REM

2 = LR Key LOC

3 = LR Key REM

4 = DIx

5 = Serial LOC

6 = Serial REM

7 = CO/DN/DP LOC

8 = CO/DN/DP REM

9 = SoftPLC LOC

10 = SoftPLC REM

2cfg I/O 13-24

8 | CFW700

Quick Parameter Reference, Faults and Alarms

English

Param. Description Adjustable Range Factory

Setting

User

Setting Prop. Groups Pag.

P0221 LOC Reference Selection 0 = HMI

1 = AI1

2 = AI2

3 = Sum AIs > 0

4 = Sum AIs

5 = Serial

6 = CO/DN/DP

7 = SoftPLC

0cfg I/O 13-24

P0222 REM Reference Selection Refer to the P0221 options 1 cfg I/O 13-24

P0223 LOC FWD/REV Selection 0 = Forward

1 = Reverse

2 = FR Key FWD

3 = FR Key REV

4 = DIx

5 = Serial FWD

6 = Serial REV

7 = CO/DN/DP (FWD)

8 = CO/DN/DP (REV)

9 = SoftPLC (FWD)

10 = SoftPLC (REV)

11 = AI2 Polarity

2cfg I/O 13-25

P0224 LOC Run/Stop Selection 0 = I/O Keys

1 = DIx

2 = Serial

3 = CO/DN/DP

4 = SoftPLC

0cfg I/O 13-25

P0225 Selection of JOG – LOCAL

Situation

0 = Inactive

1 = JOG Key

2 = DIx

3 = Serial

4 = CO/DN/DP

5 = SoftPLC

1cfg I/O 13-26

P0226 REM FWD/REV Selection Refer to the P0223 options 4 cfg I/O 13-25

P0227 REM Run/Stop Selection 0 = I/O Keys

1 = DIx

2 = Serial

3 = CO/DN/DP

4 = SoftPLC

1cfg I/O 13-25

P0228 Selection of JOG –

REMOTE Situation

Refer to the P0225 options 2 cfg I/O 13-26

P0229 Stop Mode Selection 0 = Ramp to Stop

1 = Coast to Stop

2 = Fast Stop

3 = By Ramp with Iq* = 0

4 = Fast Stop with Iq* = 0

0cfg 13-26

P0230 Analog Input Dead Zone 0 = Inactive

1 = Active

0I/O 13-1

P0231 AI1 Signal Function 0 = Speed Reference

1 = N* without Ramp

2 = Maximum Torque

Current

3 = SoftPLC

4 = PTC

5 = Application Function 1

6 = Application Function 2

7 = Application Function 3

8 = Application Function 4

9 = Application Function 5

10 = Application Function 6

11 = Application Function 7

12 = Application Function 8

0cfg I/O 13-2

CFW700 | 9

Quick Parameter Reference, Faults and Alarms

English

Param. Description Adjustable Range Factory

Setting

User

Setting Prop. Groups Pag.

P0232 AI1 Gain 0.000 to 9.999 1.000 I/O 13-3

P0233 AI1 Signal Type 0 = 0 to 10 V / 20 mA

1 = 4 to 20 mA

2 = 10 V / 20 mA to 0

3 = 20 to 4 mA

4 = -10 V to 10 V

0cfg I/O 13-4

P0234 AI1 Offset -100.00 to 100.00 % 0.00 % I/O 13-3

P0235 AI1 Filter 0.00 to 16.00 s 0.00 s I/O 13-3

P0236 AI2 Signal Function Refer to the P0231 options 0 cfg I/O 13-2

P0237 AI2 Gain 0.000 to 9.999 1.000 I/O 13-3

P0238 AI2 Signal Type 0 = 0 to 10 V / 20 mA

1 = 4 to 20 mA

2 = 10 V / 20 mA to 0

3 = 20 to 4 mA

4 = -10 V to 10 V

0cfg I/O 13-4

P0239 AI2 Offset -100.00 to 100.00 % 0.00 % I/O 13-3

P0240 AI2 Filter 0.00 to 16.00 s 0.00 s I/O 13-3

P0246 Frequency Input

Conﬁguration

0 = Off

1 = DI3

2 = DI4

0cfg 13-23

P0251 AO1 Function 0 = Speed Reference

1 = Total Reference

2 = Real Speed

3 = Torque Current

Reference

4 = Torque Current

5 = Output Current

6 = Active Current

7 = Output Power

8 = Torque Current >0

9 = Motor Torque

10 = SoftPLC

11 = PTC

12 = Motor I x t

13 = Encoder Speed

14 = P0696 Value

15 = P0697 Value

16 = Id* Current

17 = Application Function 1

18 = Application Function 2

19 = Application Function 3

20 = Application Function 4

21 = Application Function 5

22 = Application Function 6

23 = Application Function 7

24 = Application Function 8

2I/O 13-6

P0252 AO1 Gain 0.000 to 9.999 1.000 I/O 13-6

P0253 AO1 Signal Type 0 = 0 to 10 V / 20 mA

1 = 4 to 20 mA

2 = 10 V / 20 mA to 0

3 = 20 to 4 mA

0cfg I/O 13-8

P0254 AO2 Function Refer to the P0251 options 5 I/O 13-6

P0255 AO2 Gain 0.000 to 9.999 1.000 I/O 13-6

P0256 AO2 Signal Type 0 = 0 to 10 V / 20 mA

1 = 4 to 20 mA

2 = 10 V / 20 mA to 0

3 = 20 to 4 mA

0cfg I/O 13-8

Autres manuels pour CFW700

Table des matières

Langues :

Autres manuels WEG Entraînement CC

WEG

WEG CFW-11 Series Manuel utilisateur

WEG

WEG CFW-09 Manuel utilisateur

WEG

WEG CFW-11 Series Manuel utilisateur

WEG

WEG MW500 series Manuel utilisateur

WEG

WEG CFW-11W Instructions d'installation et d'utilisation

WEG

WEG CFW-11 Series Manuel utilisateur

WEG

WEG CFW100 series Manuel du propriétaire

WEG

WEG CFW-11 Series Manuel du propriétaire

WEG

WEG CFW-11 Series Manuel d'utilisation et d'entretien

WEG

WEG CFW700 Manuel utilisateur

WEG

WEG CFW300 V1.3X Manuel du propriétaire

WEG

WEG Easy Drive CFW10 Manuel utilisateur

WEG

WEG DeviceNet CFW500 Manuel utilisateur

WEG

WEG MVW01 Manuel utilisateur

WEG

WEG DeviceNet CFW500 Manuel utilisateur

WEG

WEG CFW500 V1.8X Manuel du propriétaire

WEG

WEG CFW100 series Manuel du propriétaire

WEG

WEG bacnet CFW701 Manuel utilisateur

WEG

WEG MW500 series Manuel utilisateur

WEG

WEG DeviceNet CFW500 Instructions d'utilisation

WEG

WEG CFW-11 Series Manuel utilisateur

WEG

WEG SCA06 Manuel utilisateur

WEG

WEG CFW-11 Series Manuel utilisateur

WEG

WEG CFW11M G2 Series Manuel utilisateur

Manuels Entraînement CC populaires d'autres marques

Vincent Associates

Vincent Associates UNIBLITZ ED12DSS Manuel utilisateur

EKSMA OPTICS

EKSMA OPTICS DQ-100-4 Manuel de la liste des pièces

Chamberlain Garog

Chamberlain Garog D Series Manuel utilisateur

Parker

Parker PDS Series Manuel utilisateur

Festo

Festo DGC G Series Guide de configuration

Binks

Binks QS-5012-1-CE Manuel utilisateur

Danfoss

Danfoss VLT 2800 Series Fiche technique

ABB

ABB ACQ580-01 Series Manuel d'installation

YASKAWA

YASKAWA CANopen SI-S3 Manuel utilisateur

GE D20A6 Manuel utilisateur

Unex

Unex MC-D-250-1000-050W-TW Manuel utilisateur

Geckodrive

Geckodrive G213V Manuel utilisateur

ABB

ABB RSYC-01 Manuel utilisateur

Rockwell Automation

Rockwell Automation PowerFlex 700S Manuel du propriétaire

Siemens

Siemens SINAMICS G Fiche technique

Siemens

Siemens SINAMICS SM150 6SL3815-7NP41-0AA1 Mode d'emploi

SOMFY

SOMFY JR RU 30 Manuel utilisateur

Beckhoff

Beckhoff AX8911 Manuel de l'opérateur
