Professional

Loudspeaker

Epic Sub 110

USER MANUAL

Professional Loudspeaker Technology

CONTENTS PageNo

1.INTRODUCTION 2

2.FEATURES 2

3.CARE&MAINTENANCE 3

4. TECHNICAL SPECIFICATIONS 4

5. PRODUCT DISPOSAL 5

W Audio Professional Loudspeaker User Manual

1-

1. INTRODUCTION

Thank you for purchasing this W Audio professional loudspeaker product. The Epic

Sub110loudspeaker is a portable bass reflex enclosure, featuring a very efficient 10” long

–throw bass speaker with high power 65 mm voice coil. It is designed for a variety of

portable sound reinforcement and club applications.

2. FEATURES

1. MDF trapezoid cabinet with scratch-resistance textured paint.

2. High intensity cabinet construction.

3. 10” high power LF speaker.

4. Crossover: passive –12db octave, 180HZ.

5. Hole with a diameter of 35mm for satellite use.

6. 11x M8 flying points

W Audio Professional Loudspeaker User Manual

2-

3. CARE & MAINTENANCE

1) Do not use this speaker near water.

2) Clean only with dry cloth.

3) Do not block any ventilation openings. Install in accordance with the instructions.

4) Do not install near any heat sources such as radiators, stoves, or other apparatus

(including amplifiers) that produce heat.

5) Protect the power cable from being walked on or pulled particularly at plugs.

6) Only use attachments or accessories specified by the manufacturer.

7) Do not connect this speaker during lightning storms or when being unused for a long

period.

8) Choose a suitable cable for the loudspeaker, cable which is too small will not give a high

output.

W Audio Professional Loudspeaker User Manual

3-

4. TECHNICAL SPECIFICATIONS

W Audio Professional Loudspeaker User Manual

4-

Model: Epic Sub110

Woofer: 1 x10” subwoofer (Ferrite )

Power (AES): 500W

Power(RMS) 250W

Recommended amps into( 8ohm) 200W-400W

Impedance: 8 Ω

Sensitivity(1W/m) f>100Hz: 96dB

Max sound Pressure at 1m: 120dB continuous, 123dB peak

Crossover Passive–12db /octave, 180HZ

Frequency response: 50Hz-----150Hz

Cabinet 15mm MDF

Accessory 11x M8 flying points

Dimensions (W x D x H) 320 x 360 x 480 mm

Net weight 14Kg

5. PRODUCT DISPOSAL

Specification is subject to change without prior notice.

W Audio Professional Loudspeaker User Manual

5-
