Hardware Guide 1
Hardware Specifications
The WatchGuard® XCS appliance is an easy-to-use, all-inclusive email and web appliance that provides
security and privacy of inbound and outbound traffic. It is the first product that provides correlated content
security and threat prevention with consolidated administration and reporting across multiple protocols.
The WatchGuard XCS provides content security that enables data loss prevention, encryption and content
filtering with integrated threat prevention for viruses, spam, spyware, phishing, and malware attacks, all in a
secured appliance.
Secure Operating System
The WatchGuard XCS delivers the most complete security available for messaging systems. The appliance runs
on a customized secure operating system that does not allow uncontrolled access to the system. There is no
command line access and the WatchGuard XCS runs as a closed system, preventing accidental or deliberate
misconfiguration by administrators, which is a common cause of security vulnerabilities.
Package Contents
XCS device
Quick Start Guide
Hardware warranty card and LiveSecurity® Service activation card
Power cord
Ear Bracket Screw Set
Hardware Specifications
2
About Your Hardware
Hardware Specifications
XCS 280 XCS 580
Processor Single Core 2.6GHz Intel E5300 800
FSB, LGA775, 2M Cache
Dual Core 2.6GHz Intel E5300 800
FSB, LGA775, 2M Cache
Memory 4GB (1 x 4 GB)
DDR3 STD DIMM
4GB (1 x 4 GB)
DDR3 STD DIMM
Hard Drives 320 GB SATA 320 GB SATA
Power
supply
Universal Power Supply 220W,
100–240 VAC, 1.2A MAX, 50/60 Hz,
Autosensing
Universal Power Supply 220W,
100–240 VAC, 1.2A MAX, 50/60 Hz,
Autosensing
Network
Interfaces
3 x Intel 82583V GBe (Onboard) 3 x Intel 82583V GBe (Onboard)
USB Ports 2 x USB ports 2 x USB ports
I/O
Interfaces
1 x SATA
1 x PS/2 Mouse
1 x PS/2 Keyboard
1 x VGA DB15
1 x Serial DB9
1 x SATA
1 x PS/2 Mouse
1 x PS/2 Keyboard
1 x VGA DB15
1 x Serial DB9
Dimensions D=10.9” (305 mm)
W=16.9” (431 mm)
H=1.7” (44 mm)
D=10.9” (305 mm)
W=16.9” (431 mm)
H=1.7” (44 mm)
Weight 15.4 lbs (7 kg) 15.4 lbs (7 kg)
Hardware Guide 3
Hardware Specifications
Environmental Requirements
To safely install your XCS device, we recommend that you:
Install it in a network rack.
Put it in a secure area, such as a locked room, to keep the device from people who do not have
permission to use it.
Connect it to a conditioned power supply to prevent damage from sudden power changes.
Other environmental requirements for the WatchGuard XCS device:
Operating temperature 0 – 40°C (32 – 104°F)
Non-operating temperature –20 – 70°C (–4 – 158°F)
Operating and Non-operating
relative humidity
5% – 90% Non-condensing
Hardware Specifications
4
Hardware Description
Front View
The front of the XCS device.
This is a close-up of the LED panel.
Power Button
Press the power button to power on and off the device. Before you power off your device, make sure
your operating system is correctly shut down. Hold the power button for at least five seconds to force
a power off.
Power Indicator
The power indicator lights when power is supplied to the device and the device is operational.
Hard Disk Activity
The hard disk activity indicator flashes when the disk drive is active.
Network Interface Activity (NIC1)
The network interface activity indicators flash when network activity is detected on the first onboard
network interface.
Network Interface Activity (NIC2)
The network interface activity indicators flash when network activity is detected on the second
onboard network interface.
Network Interface Activity (NIC3)
The network interface activity indicators flash when network activity is detected on the third onboard
network interface.
Hardware Guide 5
Hardware Specifications
Rear View
This is a close-up of the rear of the device.
PS/2 Ports
Two PS/2 ports are available to connect a keyboard and mouse for use with the XCS device console.
USB Interfaces
There are two USB interfaces that support additional peripherals, for example a USB keyboard (for use
with the XCS device console), and a USB DVD/CD-ROM drive.
Serial Port
You can use a DB9 connector for the serial port (COM1) to connect a UPS (Uninterruptible Power
Supply). The serial port can also be used to connect to the serial console if you do not have a monitor
and a keyboard.
VGA Video Interface (Console)
You can use the VGA video connector to connect a monitor and view the XCS device console screen.
AC Receptacle
Accepts a detachable AC power cord supplied with the device.
Power Supply Fan
The fans decrease the internal temperature of the device.
Caution
You must disconnect the power supply before you remove the cover of the XCS device.
If you open the cover without prior authorization from WatchGuard, the Hardware Warranty
is voided.
Hardware Specifications
6
Network Interfaces
This is a close-up of the network interfaces on the rear of the device.
Onboard Network Interfaces
The XCS device has three onboard network interfaces. The network interfaces have standard RJ45
connectors.
Network Interface Indicators
Each network interface has a pair of indicators. The left indicator is the activity indicator for the
interface. The right indicator shows the connection speed for the interface.
Indicator Indicator Color Interface Status
Activity (Left) Not lit No connection
Amber Connection established
Blinks Network activity, data sent and
received
Connection Speed
(Right)
Not lit Operates at 10 Mbps or no link
Green Operates at 100 Mbps
Amber Operates at 1000 Mbps
Hardware Guide 7
Hardware Specifications
Rack Mount Instructions
When you install the XCS device in a rack, make sure you consider:
Elevated Operating Ambient Temperature
If you install the XCS device in a closed or multi-unit rack assembly, the operating ambient
temperature of the rack environment could be greater than the ambient temperature of the room.
The XCS device is certified to operate correctly between 32–104°F (0–40°C).
Reduced Air Flow
When you install the XCS device in a rack, make sure that the amount of air flow required for safe
operation of the equipment is not compromised.
Mechanical Loading
When you mount the XCS device in the rack, avoid hazardous conditions caused by an uneven
mechanical load.
Circuit Overloading
Make sure you connect the XCS device to the power supply circuit in such a way that no circuits are
overloaded and there is no impact on overcurrent protection and supply wiring.
Reliable Grounding
Make sure all rack-mounted equipment is correctly grounded. For example, use power strips instead
of direct connections to the branch circuit.
Hardware Specifications
