Warmup 3IE Manuel utilisateur

INSTALLATION AND

OPERATION MANUAL

MANUEL D’INSTALLATION ET DE

PROGRAMMATION

Warmup®3iE™

Energy-Monitoring

Thermostat

Ecoénergétique

24/7 Technical Hotline

(888) 592 - 7687

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

CONTENTS

Introduction Page 3

Getting started Page 4

Setting your programs Page 5

View and edit a schedule Page 8

Holiday mode Page 9

Energy monitor Page 10

Settings Page 12

Setting heating target Page 14

Advanced settings Page 15

Setting your heating system Page 16

Probes Page 17

Warranty Page 18

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

Your thermostat’s default screen is the Home Screen. This screen

displays important information such as the time, current floor and

air temperature as well as the target set temperature. From this page

you can either access the “MENU” page (press “menu”) or override

the current program (press “ ” or “ ”).

When using the 3IE thermostat there are some simple rules to keep

in mind:

1. Pressing “ ” allows you to confirm your selection

2. Pressing “ ” takes you back to a previous page in the menu

sequence

3. Pressing the “ ” and “ ” buttons allow you to change the

setting which is highlighted

4. Pressing an illuminated button in this group will allow you to highlight another setting to edit

5. Pressing an illuminated button in this group will allow you to select another option in the menu

6. When this light is illuminated it indicates that power is being directed to the heating systems (can be

turned off).

If you do not press any button on the thermostat for 1 minute, then it will go to standby mode. In standby

mode the screen will be dimmed but the thermostat will continue to function as normal. To exit standby

mode press “wake” ( ).

The button on bottom of the 3IE (button 7) is the power button. You can turn off your thermostat and

your Warmup floor heating system by holding down this button for 3 seconds. You can turn it on again by

holding it down for another 3 seconds.

INTRODUCTION

GROUND FAULT CIRCUIT INTERRUPTER

The GFCI feature is used to detect any leakage of current from your heating system. During a ground fault

the two lines of the load will be cut off. Once your thermostat is installed and connected to a power supply

you can test the GFCI function by increasing the set temperature until heating is on - the red light in the

top corner must be illuminated - and pressing the “TEST” button (see 8).

If your test is successful you will see the GROUND FAULT screen and you will need to hold “cancel” for 3

seconds in order to restore heating operation.

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

GETTING STARTED

1. Language

2. Time perefrences and settings

3. Date preference and settings

4. Daylight savings

5. Temperature preferences

6. Theme

7. Brightness

8. Standby Brightness

9. Heating LED

10. Audio Feedback

11. Floor type

12. Set heating target

13. Program schedule

14. Set energy monitor

15. (You may skip this section and

complete at a later date )

16. Energy settings

On initial power up the thermostat will guide you through set up procedure.

By accessing the main menu you can program your thermostat or make any changes to the thermostat

settings. To access the menu press “menu” on the main screen.

If the thermostat is in sleep mode press ”wake”.

LThe energy monitoring menu will be skipped automatically if a pre set program is selected on initial

setup.

GROUND FAULT CIRCUIT INTERRUPTER (cont’d)

However if the thermostat detects that one of the relays has FAILED to open correctly you will see the

Control Fault screen and the TEST LED will illuminate.

In the following circumstances you should immediately isolate the power supply to the thermostat and

contact Warmup customer service:

1. Press the TEST button when heating is on (the red light in the top corner is on) and the screen does

not display GROUND FAULT or cut power to the load.

2. The thermostat shows the GROUND FAULT screen during normal operation.

3. The thermostat shows the CONTROL FAULT screen.

Note: The GFCI test should be carried out monthly.

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

Press “ ” and “ ” to set the start time for the first of the

day.

If you want to change the target floor temperature press

“floor temp”, you can now press “up” and “down” to change

the target floor temperature.

If you want the target temperature to change later on in the

day then press “add another period”. You can add up to 10

periods in each day.

SETTING YOUR PROGRAM

Press “menu”, then Press “set program”.

You may have to press “wake” first, if the stat is in standby

mode.

Press the programming option that suits your needs.

• Set each day separately: set each day of the week with

a different program

• Set weekday and weekend: set a program for Monday –

Friday and a different program for Saturday and Sunday

• Set all days the same: one program is set for all the days

of the week

• Set fixed temperature: set a single temperature to be

held constantly

• Select a pre-set: see explanation in table

LIf you hold a button for several seconds it will scroll

continuously until you release your finger

72°F

next period

LIf you would rather use your thermostat to target

an air temperature then see page 12.

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

Once you have set all the desired periods in the day press

“OK” to go to the summary page.

This summary page allows you to see the program you have

set for this day. If you need to change something press

“edit”. This will take you back to the first period of the day.

Remember that you will need to add all the periods again.

If you are happy with the program and would like to set the

same program for the following day press “copy to …”

SETTING YOUR PROGRAM

LIt is recommended that you finish your daily program

on a low target temperature so that you save energy

overnight.

If you do not need the heating to protect against

frost then you can scroll down to the bottom of the

temperature range to set the target temperature to

“OFF”. With this setting the heating will not come on

regardless of the temperature.

If you are happy with the program but would like to set a

different program for the following day press “OK”

If you would like to return to the preceding day press “back”.

When you have set a program for all the days including

Sunday (or Weekend in the case of Weekday/Weekend) then

pressing “OK” will enter the schedule and return you to the

home screen.

LThe set temperature for the time before the first

period of the day comes from the night before.

104 F

- oor

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

SETTING YOUR PROGRAM

If you are using your 3IE thermostat in the bathroom, bedroom, kitchen or living room then the pre-set

schedules might help you set a program appropriate for you. Just select the desired pre-set room and

everything is done automatically.

PRE-SET PROGRAMS TABLE :

Bathroom Kitchen Bedroom Living room

Time Floor Temp Time Floor Temp Time Floor Temp Time Floor Temp

Monday

to Friday

06:00 72°F/ 25°C 06:00 73°F / 23°C 06:00 72°F / 25°C

08:00 50°F / 10°C 08:00 50°F /10°C 08:00 50°F /10°C

19:00 68°F / 20°C 18:00 73°F / 23°C 20:00 68°F / 20°C 18:00 73°F / 23°C

23:00 59°F / 15°C 22:00 50°F /10°C 23:00 50°F / 10°C 21:30 50°F / 10°C

Saturday -

Sunday

07:00 72°F / 25°C 07:00 73°F/23°C 06:00 72°F / 25°C 08:00 73°F / 23°C

11:00 64°F / 18°C 11:00 64°F /18°C 08:00 50°F / 10°C

18:00 68°F / 20°C 18:00 73°F/ 23°C 20:00 68°F / 20°C 18:00 68°F / 20°C

23:00 59°F / 15°C 22:00 50°F /10°C 23:00 50°F / 10°C 20:00 50°F / 10°C

LIf you have used a pre-set schedule but want to make some changes just use the edit schedule

function explained in the “View and Edit a Schedule” section.

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

If you would like to view or edit the time and temperature

settings of each day then press “view / edit program”.

Press “up” and “down” until the day that you would like to

view is highlighted, then press “OK” to view that day.

To exit the “VIEW / EDIT PROGRAM” menu, press “back”.

Note that if you have edited any days these changes will be

saved.

Here you can see review the heating schedule for the

selected day.

If you would like to change any of the heating periods press

“edit”. Remember that you will have to set all the heating

periods. You can view the schedule for the following day by

pressing “view …”.

To return to the day selection, press “OK”.

VIEW AND EDIT A SCHEDULE

LIf you want to change the settings of multiple days it

might be easier to set a new program using the “set

program” option

104 F

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

HOLIDAY MODE allows you to over-ride your schedule with

a fixed temperature for a prolonged period of time. This

can help save energy if you know that you will be out of the

house and only want minimal heating.

Press the highlighted button next to “holiday”.

Press “up” and “down” to set the first day you would like the

HOLIDAY MODE to start.

Press “holiday end at” and then press “up” and “down” to

set the day when you would like holiday mode to stop. At

the end of the HOLIDAY MODE your program will return to

the current settings. If you would like HOLIDAY MODE to

continue indefinitely, leave the end date on “not specified”.

Press “holiday temperature” to set the fixed temperature

that will be held for the entire HOLIDAY MODE period.

Pressing “OK” will confirm the selection and HOLIDAY MODE

will start at 12:00 pm on the specified date.

During the HOLIDAY MODE you will have a modified home

screen. To cancel the HOLIDAY MODE at any time just press

“cancel”.

If you want to return to HOLIDAY MODE you will need to set

it again.

HOLIDAY MODE

2011

50 F

24/7 Technical hotline - Ligne d’assistance technique - Línea de asistencia técnica

US 1.888.927.6333 / CA 1.888.592.7687

ENERGY MONITOR

Your thermostat monitors the amount of energy your floor

heating system is using, you can use these pages to view the

amount of energy used and set parameters to estimate the

cost of that energy.

If you want to see how much energy you have used then

select “view energy use” and then select the time period you

would like to review.

* If you see the “load settings” option you will need to enter

the total power in watts of the floor heating system connect

to the thermostat. If you are unclear about the power of your

floor heating then contact your installer.

After you press “view energy use”, you will need to select the

length of time in which you are interested.

On the graph each red bar indicates a time period (in this

case it is months). The height of the bar indicates that

amount of energy in KWH used by the floor heating system

during that period. The bar in the far right is the most recent

time period and the bar on the far left is the oldest.

The total amount of energy used in the entire time span is

displayed in the bottom bar.

Press “OK” to return to the ENERGY MONITOR menu.

LIf you are interested in seeing how much energy you

can save by adjusting the settings of your thermostat,

then alter your heating program and wait a few days

before comparing the daily energy used before and

after you changed your program.

Autres manuels pour 3IE

Table des matières

Langues :

Autres manuels Warmup Thermostat

Warmup

Warmup 4iE WiFi Guide de démarrage rapide

Warmup

Warmup 3IE Manuel utilisateur

Warmup

Warmup 4iE WiFi Manuel utilisateur

Warmup

Warmup TH115-AF-GA Manuel utilisateur

Warmup

Warmup 3IE Manuel utilisateur

Warmup

Warmup 3IE Manuel utilisateur

Warmup

Warmup 3IE Manuel utilisateur

Warmup

Warmup 3IE Manuel utilisateur

Warmup

Warmup Tempo Manuel utilisateur

Warmup

Warmup OTN-1991-WA Manuel utilisateur

Warmup

Warmup OCC2 Manuel utilisateur

Warmup

Warmup W3115DT AU Manuel utilisateur

Warmup

Warmup WA-XSTAT Manuel utilisateur

Warmup

Warmup MTC-1991-WU Manuel utilisateur

Warmup

Warmup One Manuel utilisateur

Warmup

Warmup Portrait 4iE Instructions d'installation

Warmup

Warmup Luxury 2 LUXY2D44 Manuel utilisateur

Warmup

Warmup 5iE Manuel utilisateur

Warmup

Warmup tempo Manuel utilisateur

Warmup

Warmup WT01 Manuel utilisateur

Warmup

Warmup 5iE Guide de démarrage rapide

Warmup

Warmup 6iE Manuel utilisateur

Warmup

Warmup WA-XSTAT-V Manuel utilisateur

Warmup

Warmup 4iE WiFi Manuel utilisateur

Manuels Thermostat populaires d'autres marques

EWELLY

EWELLY EW-181 Manuel utilisateur

Prolon

Prolon T1100 Instructions d'installation

Computherm

Computherm Q20 Manuel utilisateur

Heatmiser

Heatmiser neoStat Manuel utilisateur

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA Manuel utilisateur

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat Manuel utilisateur

Saswell

Saswell SAS920XWHB-7-S-RF Mode d’emploi

Aircalo

Aircalo TFP1-ET85P2 Manuel utilisateur

Honeywell

Honeywell CM721 Manuel utilisateur

Carrier

Carrier DEBONAIR 33CS Manuel utilisateur

Lennox

Lennox iHarmony Zone Thermostat Instructions de montage

Gemtech

Gemtech GT7000 Mode d’emploi

Rollei

Rollei Smartes 45000 Manuel utilisateur

Sinope

Sinope TH1300RF Manuel utilisateur

Honeywell

Honeywell RLV4305 Manuel utilisateur

Honeywell

Honeywell Prestige 2.0 THX9421 Manuel utilisateur

NuTone

NuTone NTBZ48 Instructions d'utilisation d'origine

Stelpro

Stelpro MAESTRO ASMT402AD Manuel utilisateur
