WAGNER W 140 P Guide de configuration

Wagner Product Training

Safety Considerations and

Recommendations

As with any power tool, you need to exercise a level of care to ensure user

safety.

Wagner products used correctly are very safe, and meet all of the necessary

safety requirements.

There has not been a reported case of skin injection injury in over 10 years,

but safety should always be high priority

Safety Considerations and

Recommendations – cont.

1. Before using the equipment, read and observe the safety instructions detailed

in the Users Manual.

2. Make sure the electrical lead is in good working condition.

3. Spray materials emerge from the nozzle tip under high pressure. Never point

the spray stream towards human beings or animals. In the event of injury to

the skin by paint or solvents, quick expert treatment by a physician is

essential. The physician should be informed of the type of paint or solvent

involved.

4. To avoid the hazard of explosion when spraying, provide for effective natural

or artificial ventilation.

Safety Considerations and

Recommendations – cont.

5. No sources of ignition are to be in the immediate area when spraying eg.

open flame, cigarettes, sparks, glowing wires and hot surfaces.

6. The spray gun is not a toy. Keep out of reach of children.

7. Before carrying out any type of work on the spray gun, unplug the lead from

the power socket.

8. Do not use spray guns to spray flammable liquids.

9. Do not spray any liquid of unknown hazard potential.

10. Wear a breathing mask or ear protection as required.

Power Painter Airless Sprayers

W 140 P W 180 P

W 400 SE

Power Painter Airless Sprayers

Paints & Materials

Water diluted primers, water diluted paints, wood preservatives, polishes,

stains, aluminium paints and cavity sealers. W400 SE also undercoats,

interior wall emulsion paints and interior wall latex paints.

Ideal for small to

medium

redecoration

and renovation

jobs around the

house and yard

Air Spray

Process

Paint is drawn into the gun by venturi

and is a atomized by injected air. The

fan can be manipulated by air

introduced around the fan. Because

the paint is both picked up and

atomized by air the paint leaves the

nozzle in form of a fine mist. The paint

droplets are suspended in the air and

tend to float, causing overspray. The

transfer efficiency is very low, only 25-

45% of the coating reaches the job

Advantages

• Adjustable air control

• Adjustable fluid control

• Fan width adjustment

Disadvantages

• Poor transfer efficiency

• Overspray

Airless Spray

Process

Paint is drawn into the gun by

vacuum and is pressurised. It is

forced trough a small orifice causing

it to atomise. The paint is delivered

to the job by pressure only, therefore

there is little overspray although you

do get fallout. Due to fixed tips a

percentage of the paint can be

sprayed past the job. The transfer

efficiency of an airless gun is 65-

80%

Advantages

• Fast coating time

• Good transfer efficiency

• Low overspray

Disadvantages

• Fixed tips

• Not adjustable

Functional Principle of Electric Hand

Spray Guns

The heart of the airless unit is the

piston which causes atomisation

by high pressure.

The oscillator pushes the piston

forwards. As soon as the piston

spring moves the piston backwards,

a vacuum is set up in the pump

cylinder and this sucks in the

spraying material. In the next

forward movement of the piston, the

suction aperture is closed and the

spray material is pressed outwards

under high pressure through the

valve system – with no air.

The spray flow rate and the

spraying pressure can be

smoothly adjusted with the

regulating screw

Power Painter Introduction

Power Painters let you paint quickly and smoothly. The drawing below shows

the set of typical components. Refer to the selection chart for model specific

components.

Optional accessories may include a backpack container, additional spray tips, or

a packet of Cleaner/Lubrication depending on model.
