Wacom Cintiq 13HD Manuel utilisateur

EN

Welcome

Thank you for purchasing Cintiq 3HD Creative Pen & Touch Display. They are

designed to help you work faster, more productive and more naturally in studio

or on the go.

Please read this Quick start guide ﬁrst. It is very important that you follow the

setup instructions so that your Cintiq will function properly.

After installation, take a look at the Wacom Desktop Center. It’s a great place to

change your settings and access information on how to achieve the most from

using your new Cintiq. There is also an extensive Help system.

At the conclusion of the setup you will be asked to register your Cintiq with

Wacom. We strongly encourage you to do so in order to take advantage of all

the available Wacom resources. There are tips and tricks, webinars, and support

available for you.

Sincerely,

The Wacom Team

EN

Supplied accessories

3-in- cable AC adapter plug

Installation CDStand Quick start guide Cloth

Pro Pen Pen case Pen stand Color rings Pen nibs Nib removal

tool

2

EN

Getting to know the Cintiq

See the Help for details.

1

2

3

5

6

7

8

4

. Home button

2. Rocker Ring

3. ExpressKeys

4. Stand slots

5. Power button

6. USB 2.0 port

7. 3-in- Connector

8. Status LED

3

EN

Using the stand

To learn more go to www.wacom.com

Flat

Reclined Midway Upright

3

2

Reclined

Midway

Upright

4

EN

Software Installation

. Make sure you have an Internet connection.

2. Close all open applications.

3. Install the Cintiq driver from the CD. If you don't

have a CD/DVD drive, download the driver from

http://us.wacom.com/en/support/.

4. Click "Install Tablet" and follow the prompts.

You must install the driver for correct Pen/Touch functionality.

5

EN

Connecting the Cintiq to your computer

. Turn off your computer.

2. Plug the 3-in- cable into your computer and Cintiq 3HD.

3. Attach the plug to the AC adapter. Connect the adapter to the 3-in- cable,

and plug it in.

4. Turn on the Cintiq. The Status LED will light.

5 . Turn on your computer.

3-in- cable

AC adapter

plug

6

EN

Calibrating the Cintiq

Calibrate your Cintiq to align the cursor with the position of the pen on the

display. Position the Cintiq as you will use it, and then follow the calibration

procedure below.

Open the Wacom tablet control panel.

Windows 7 - Click Start > (All) Programs > Wacom Tablet > Wacom Tablet

Properties.

Windows 8 - Start screen > Wacom Tablet Properties (Tile).

Mac - Open System Preferences > Wacom Tablet.

2 Click the Calibrate tab.

3 Click Calibrate....

4 Use the pen to click the center of each cross mark that appears on the display with

the pen.

• The position adjustment is completed when the cross marks disappear.

• Click OK and close the control panel after saving the adjustment settings.

You may want to re-calibrate whenever you signiﬁcantly change your working

position or viewing angle.

7

EN

Using the pen with Cintiq

Move the pen slightly above the display, without touching

the surface, to position the display cursor.

Tap the display once with the pen tip to select.

Choose a color ring to distinguish

your pen.

For best performance wipe off the

display often with the cleaning cloth.
