VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201-0696, TEL. (502) 778-2791

FORM 35607 (06-03)

INSTALLATION &

OPERATION MANUAL

MODEL MG24C

CARRABBA'S

MG SERIES GAS RESTAURANT

MODULAR RANGE

MODEL

MG24C ML-135500

MG36C ML-135501

MG48C ML-135502

– 2 –

IMPORTANT FOR YOUR SAFETY

THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL GAS

EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND

ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.

POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN THE

EVENT THE SMELL OF GAS IS DETECTED. THIS INFORMATION CAN BE OBTAINED

FROM THE LOCAL GAS SUPPLIER.

IMPORTANT

IN THE EVENT A GAS ODOR IS DETECTED,

SHUT DOWN UNITS AT MAIN SHUT-OFF VALVE

AND CONTACT THE LOCAL GAS COMPANY

OR GAS SUPPLIER FOR SERVICE.

FOR YOUR SAFETY

DO NOT STORE OR USE GASOLINE OR OTHER

FLAMMABLE VAPORS OR LIQUIDS IN THE

VICINITY OF THIS OR ANY OTHER APPLIANCE.

WARNING

IMPROPER INSTALLATION, ADJUSTMENT,

ALTERATION, SERVICE OR MAINTENANCE

CAN CAUSE PROPERTY DAMAGE, INJURY OR

DEATH. READ THE INSTALLATION,

OPERATING AND MAINTENANCE

INSTRUCTIONS THOROUGHLY BEFORE

INSTALLING OR SERVICING THIS EQUIPMENT.

IN THE EVENT OF A POWER FAILURE, DO NOT ATTEMPT TO OPERATE THIS DEVICE.

– 3 –

TABLE OF CONTENTS

CARRABBA'S MG SERIES GAS RESTAURANT MODULAR RANGE ............................................ 3

INSTALLATION .................................................................................................................................... 4

Uncrating .................................................................................................................................. 4

Location .................................................................................................................................... 4

Installation Codes and Standards ........................................................................................... 5

Assembly .................................................................................................................................. 5

Leveling .................................................................................................................................... 7

Gas Connections...................................................................................................................... 7

Testing the Gas Supply System .............................................................................................. 8

Flue Connections ..................................................................................................................... 8

Lighting and Shutting Down Pilots .......................................................................................... 8

OPERATION ........................................................................................................................................ 9

Controls .................................................................................................................................... 9

Preheating ................................................................................................................................9

Cleaning.................................................................................................................................... 9

MAINTENANCE ................................................................................................................................. 10

OPTIONAL FIELD INSTALLABLE ACCESSORIES ........................................................................ 10

CARRABBA'S MG SERIES

GAS RESTAURANT MODULAR RANGE

– 4 –

INSTALLATION

UNCRATING

This range was inspected before leaving the factory. The transportation company assumes full

responsibility for safe delivery upon acceptance of the shipment. Immediately after unpacking, check

for possible shipping damage. If the range is found to be damaged, save the packaging material and

contact the carrier within 15 days of delivery.

Carefully uncrate range and place in a work-accessible area as near to its final installed position as

possible. Remove all shipping wire and wood blocking.

Before installing, verify that the type of gas supply (natural or propane) agrees with the specifications

on the rating plate located under the left-hand cooking top, mounted to the side wall of the range.

If the supply and equipment requirements do not agree, do not proceed with the installation. Contact

your dealer or Vulcan-Hart Company immediately.

LOCATION

CAUTION: The equipment area must be kept free and clear of combustible substances.

The 28,000 BTU burner input range must have a minimum clearance from combustible construction

of 10" (25 cm) at the sides and 6" (15 cm) at the rear.

The installation location must allow adequate clearances for servicing and proper operation.

The range must be installed so that the flow of combustion and ventilation air will not be obstructed.

Adequate clearance for air openings into the combustion chamber must be provided. Make sure there

is an adequate supply of air in the room to allow for combustion of the gas at the burners.

Installation, Operation and Care of

MG SERIES GAS RESTAURANT MODULAR RANGE

KEEP THIS MANUAL FOR FUTURE REFERENCE

Vulcan ranges are produced with quality workmanship and material. Proper installation, usage and

maintenance of your range will result in many years of satisfactory performance.

The manufacturer suggests that you thoroughly read this entire manual and carefully follow all of the

instructions provided.

– 5 –

INSTALLATION CODES AND STANDARDS

For proper installation procedures in the United States of America, refer to:

1. State and local codes.

2. National Fuel Gas Code, ANSI-Z223.1 (latest edition). Copies may be obtained from The

American Gas Assn., Inc., 1515 Wilson Blvd., Arlington, VA 22209.

3. National Electrical Code ANSI/NFPA-70 (latest edition). Copies may be obtained from The

National Fire Protection Assn., Batterymarch Park, Quincy, MA 02269.

In Canada, refer to:

1. Local codes.

2. CAN/CGA-B149.1 Installation for Natural Gas Burning Appliances and Equipment

(latest edition).

3. CAN/CGA-B149.2 Propane Installation Code (latest edition), available from The Canadian

Standards Association, 178 Rexdale Blvd., Etobicoke, Ontario, Canada M9W 1R3.

ASSEMBLY

Backsplash

1. Remove the backsplash components from the crating materials.

2. Check the backsplash component parts against the list below to ensure that all the required

parts for the backsplash installation have been obtained.

• If any parts are missing, contact your dealer or closest parts depot immediately.

Backsplash Component Parts

3. Assemble the required components as shown in Fig. 2.

4. Lift the assembly up and slide the channels into the space provided at the rear of the range –

this may require two people.

MODELS

MG24C MG36C MG48C

Std. 4" (10 cm) Std. 11" (27 cm) Std. 11" (27 cm)

High High High

Backsplash (1) Backsplash (1) Backsplash (1)

Backsplash Backsplash Backsplash

Channel (2) Channel (2) Channel (2)

Heat Shield (1) Heat Shield (1) Heat Shield (1) Fig. 2

– 6 –

5. It may be necessary to pull the heat shield bottom out slightly in order to clear the flue box.

Be sure the backsplash is resting evenly and the channel holes are lining up with the holes

provided in the right- and left-hand body side (see Fig’s. 3 & 4).

Fig. 3 Fig. 4

Fig. 5

6. Install six #10 sheet metal screws (3 to each channel leg) (Fig. 5).

PL-40045

– 7 –

LEVELING

Check the leveling of the range. Place a carpenter’s level across the range top plates. Level front to

back and side to side.

To adjust the leveling, tilt the range to one side and, using channel locks, unscrew the adjustable leg

insert as required. Repeat this procedure as necessary for each leg.

GAS CONNECTIONS

CAUTION: All gas supply connections and any pipe joint compound used must be resistant to

the action of propane gases.

Connect gas supply. Make sure the pipes are clean and free of obstructions.

Codes require that a gas shutoff valve be installed in the gas line ahead of the range.

Standard ranges are equipped with fixed burner orifices which coincide with installation elevation.

Install the gas pressure regulator.

Before installing, ensure that regulator supplied agrees with rating plate gas supply.

The gas pressure regulator is NOT factory installed. The

regulator for this gas type is sealed within a plastic bag

and packaged with the range. This regulator must be field

installed by a qualified installer.

Natural gas regulators are preset for 5.0" W.C. (Water

Column); propane gas regulators for 10.0" W.C.

1. Locate 3/4" (1.9 cm) gas connection pipe extending

from rear of range.

2. Cover pipe threads with leak sealant.

3. Screw regulator hand-tight onto pipe with

regulator arrow pointing towards range body

back (Fig. 6).

4. Using pipe wrench, tighten regulator securely in

an upright position (Fig. 6).

The arrow on the regulator shows the direction of the gas flow (Fig. 6). The pressure regulator must

be mounted horizontally to ensure proper preset outlet pressure. If the regulator is installed in any other

position, the outlet pressure must be reset for proper operation.

A leak limiter is supplied with every regulator to allow excess gas pressure to escape. Do not obstruct

leak limiter on gas pressure regulator, because obstruction may cause regulator to malfunction.

WARNING: PRIOR TO LIGHTING, CHECK ALL JOINTS IN THE GAS SUPPLY LINE FOR LEAKS.

USE SOAP AND WATER SOLUTION. DO NOT USE AN OPEN FLAME.

After piping has been checked for leaks, all piping receiving gas should be fully purged to remove air.

Fig. 6

– 8 –

TESTING THE GAS SUPPLY SYSTEM

When gas supply pressure exceeds 1/2psig (3.45 kPa), the range and its individual shutoff valve must

be disconnected from the gas supply piping system.

When gas supply pressure exceeds 1/2psig (3.45 kPa) or less, the range should be isolated from the

gas supply system by closing its individual manual shutoff valve until the range is ready for start-up.

FLUE CONNECTIONS

DO NOT obstruct the flow of flue gases from the flue located on the rear of the range. It is recommended

that the flue gases be ventilated to the outside of the building through a ventilation system installed by

qualified personnel.

From the termination of the flue to the filters of the hood venting system, a minimum clearance of 18"

(45 cm) must be maintained.

Information on the construction and installation of ventilating hoods may be obtained from the

standard, “Vapor Removal from Cooking Equipment,” NFPA No. 96 (latest edition), available from The

National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.

LIGHTING AND SHUTTING DOWN PILOTS

All adjustment procedures associated with initial start-up should be performed by an authorized

Vulcan-Hart installation or service person.

Open Top Burners

1. Turn main gas supply ON.

2. Turn all top burner valve knobs ON to purge gas

line of air.

3. Turn top burner valve knobs OFF.

4. Wait 30 seconds.

5. Using a taper, light the open top pilot (Fig. 7).

6. If pilot fails to light, wait 5 minutes and repeat Steps

1 thru 5.

7. Turn one open top burner valve ON to ensure that

all gas lines are completely purged of air. Turn

burner OFF when gas begins to flow. Fig. 7

Nightly Shutdown: Turn burner valve OFF; pilot will remain lit.

Complete Shutdown

1. Turn burner valve OFF; pilot will remain lit.

2. Turn main gas supply OFF.

– 9 –

OPERATION

WARNING: THE RANGE AND ITS PARTS ARE HOT. BE VERY CAREFUL WHEN OPERATING,

CLEANING OR SERVICING THE RANGE.

CONTROLS

OPEN TOP BURNER KNOB — Regulates gas flow to top burners. To increase heat, turn knob

counterclockwise; to decrease, turn knob clockwise.

PREHEATING

Open Top Burners

Open top burners ignite quickly and do not require any preheating time. When food comes to a rolling

boil, cut back to slower boil to conserve energy, yet continue boiling. Turn burners ON only when in use.

CLEANING

Do not use Dawn®dish detergent to clean the exterior or interior components of the range.

Do not use scouring powder; it is extremely difficult to remove completely and can build up

accumulations that will damage the range.

Vulcan painted surfaces may be cleaned using a soft cloth and mild detergent solution.

Daily:

While still warm, wipe top with a soft cloth or other grease absorbing material to remove spillovers,

grease, etc., before they burn in. A crust on top of the hot top range looks unsightly and slows down

cooking speed because it reduces the flow of heat to the utensil.

Empty the grease pan daily or as often as necessary. CAUTION: Remove the grease pan slowly and

be careful of liquid wave action. It is recommended that the grease pan be emptied whenever it

is 3/4filled. The drip shield, grids and grease pan should be washed with a mild grease-dissolving

solution.

Clean cast iron open top grates with a mild soap and water solution. Rinse thoroughly and dry with a

clean, water-absorbent towel. Immediately after drying (with grates still removed from the range top),

season grates lightly with liquid vegetable or Pam®spray-type cooking oil.

After seasoning, replace grates onto the range. Turn all open top sections ON LOW and allow them

to burn for at least 15 minutes before using pots or pans on the range top.

Season the open top grates after each cleaning. Failure to season grates will cause grates to

rust.

Thoroughly clean backsplash, sides and front. Remove grease drip tray and pan, empty and wash out

in the same manner as any ordinary cooking utensil.

– 10 –

FORM 35607 (06-03) PRINTED IN U.S.A.

Weekly:

Boil burners in a solution of washing soda. Rinse and dry parts thoroughly. Flash rusting may occur.

This is a normal condition and will not affect performance or the product.

When reinstalling the burner back onto the range, be sure the burner heads are properly connected.

Do not light the pilot or turn burner valve ON with the burner head removed.

MAINTENANCE

WARNING: THE RANGE AND ITS PARTS ARE HOT. BE VERY CAREFUL WHEN OPERATING,

CLEANING OR SERVICING THE RANGE.

VENT

When cool, check the flue vent every six months for obstructions.

SERVICE AND PARTS INFORMATION

To obtain service and parts information concerning this modular range, contact the Vulcan-Hart

Service Agency in your area (refer to listing supplied with the modular range), or Vulcan-Hart Service

Department at the address or phone number shown on the front cover of this manual.

OPTIONAL FIELD INSTALLABLE ACCESSORIES

OPTIONS

DESCRIPTION

Flue Devices

Flex Hose

and Quick

Disconnects

1. Stainless steel backsplash.

2. Stainless steel 11" (28 cm) low riser.

3. Stainless steel 4" (10 cm) low riser (use with open tops only).

1. 3/4" (1.9 cm) flex hose/disconnect – 3 ft. (0.9 m) long.

2. 3/4" (1.9 cm) flex hose/disconnect – 4 ft. (1.2 m) long.

3. 3/4" (1.9 cm) flex hose/disconnect – 5 ft. (1.5 m) long.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Vulcan-Hart Gamme

Vulcan-Hart

Vulcan-Hart Endurance Series G36B-6T Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 77 SERIES Manuel utilisateur

Vulcan-Hart

Vulcan-Hart G260 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart SX Series Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GH30 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart V24-1T Manuel utilisateur

Vulcan-Hart

Vulcan-Hart MG12 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 148L Manuel utilisateur

Vulcan-Hart

Vulcan-Hart RE-3 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GH60 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GHX45 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GH60 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart VG260 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GH60T/45 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart Restaurant Range Manuel du propriétaire

Vulcan-Hart

Vulcan-Hart MG48 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GH60 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart V6B36S Manuel utilisateur

Vulcan-Hart

Vulcan-Hart GHX45 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart COMMANDER SERIES Manuel utilisateur

Vulcan-Hart

Vulcan-Hart Value Series V36-1 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart V2BG24 Manuel utilisateur

Vulcan-Hart

Vulcan-Hart 36-S-36G-N Manuel utilisateur

Vulcan-Hart

Vulcan-Hart VG36 Manuel utilisateur

Manuels Gamme populaires d'autres marques

Samsung

Samsung FCQ321HTUW Manuel utilisateur

Kenmore

Kenmore 790.45712 Manuel utilisateur

Wolf

Wolf CHR CHSSR Manuel utilisateur

Smeg

Smeg Built-in Microwave Oven Mode d’emploi

Zanussi

Zanussi ZCG054G Manuel utilisateur

Whirlpool

Whirlpool 8575985-W Manuel de la liste des pièces

Frigidaire

Frigidaire 316000635 Manuel utilisateur

GE JCSS630 Manuel utilisateur

Samsung

Samsung NX58M9960P series Manuel utilisateur

Hotpoint

Hotpoint RB524R Guide d'installation

Whirlpool

Whirlpool Roper FGP305KW3 Manuel utilisateur

Amana

Amana ART6610 SERIES Manuel utilisateur

Maytag

Maytag MERH770WB Manuel utilisateur

Fulgor Milano

Fulgor Milano SOFIA Manuel utilisateur

Premier

Premier EF-4358GH Manuel utilisateur

Kenmore

Kenmore 790.9010 Series Manuel utilisateur

KitchenAid

KitchenAid KESC300 Manuel utilisateur

Frigidaire

Frigidaire FFEF3012LS Guide de l'utilisateur
