Model VS7895A

I-TRIM PRECISE+ STUBBLE TRIMMER

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, especially when children are

present, basic safety instructions should always be followed,

including the following:

Polythene bags over product or package may be dangerous. To

avoid danger of suffocation, keep this wrapper away from babies

and children. This bag is not a toy.

DANGER: When the unit is used in a bathroom, unplug after use

since the proximity of water presents a hazard even when the unit

is switched off.

WARNING:Do not use or leave the appliance or AC

power adaptor in a position where it can become wet or

there is danger of it falling into a basin or other vessels

containing water.

•Takecaretoavoidcontactbetweenthemovingbladesoftheunit

and the skin, paying particular attention to the face, neck and

hands.

•This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety.

• Children should be supervised to ensure that they do not play

with the appliance.

IMPORTANT: Always unplug the appliance when not in use or before

cleaning. Do not leave unattended when plugged in or switched on.

Do not place on any heat sensitive surface.

•DonotuseanyattachmentsotherthanthosesuppliedbyConair

Australia Pty Ltd.

•Usethisapplianceonlyforitsintendeduseasdescribedwithin

this instruction booklet.

•Alwaysunplugtheappliancewhenfullycharged.

•Thisapplianceisnotintendedforcommercialuse.

•Neverdroporinsertanyobjectintoanyopening.

•Donotusetheappliancewith damaged orbrokenattachment

combsorwithanyteethmissingfromtheblades,asinjurymay

occur.

•Donotplaceapplianceonanysurfacewhileitisoperating.

•Donotuseoutdoorsoroperatewhereaerosol(spray)products

are being used or where oxygen is being administered.

•Keepthecordawayfromheatedsurfaces.

•Do not use this appliance if it is damaged. In the event of

damage, discontinue use immediately and contact your dealer for

instructionsonreturningitforexaminationorexchange.Ifthe

supply cord is damaged, it must be replaced by the manufacturer,

its service agent or similarly qualified person in order to avoid a

hazard.

•Nevertwistorpullonthetrimmeradaptorcord.

•Afterusedonotwrapthecordaroundtheapplianceasintime

this may cause the cord to fracture. Coil cord loosely by the side

of the appliance in storage.

•Always ensure that the voltage to be used corresponds to the

voltage marked on the unit.

• For additional protection, the installation of a residual current

device(RCD)witharatedoperatingcurrentnotexceeding30mAis

advisable in the electrical current circuit supplying the bathroom.

Ask your installer for advice.

I-TRIM PRECISE+

AUTOMATIC ALL-IN-ONE DC MOTOR STUBBLE TRIMMER

ThankyouforpurchasingtheVSForMeni-trimprecise+Stubble

Trimmer, an automatic all-in-one DC motor stubble trimmer that

provides the ultimate in stubble control.

This next generation design stubble trimmer features a unique

contouring ex head with exclusive blade design that adjusts

awlesslytothecontoursoftheface.Its’advanceddesignprovides

more precise and even results, minimizes pressure for less skin

irritation and provides exceptional accuracy for perfect stubble

results, every time.

Thei-trimprecise+deliversVSForMen’sbestcuttingperformance

by combining ‘Hard Like Diamond’ (HLD) carbon coated stainless

steel blades with titanium and a high performance professional DC

motor to provide precision control for exact stubble.

FEATURES

1. Innovativemotorisedcomb

guide system with up

and down selections with

memory function

2. 1 integrated motorised

stubble comb guide that

delivers the ultimate in

length consistency for

effortless ease

3. Uniquecontouringex

head with exclusive blade

design minimizes pressure,

for less irritation, and exact

precision control

4. Trimmer blades – ‘Hard Like

Diamond’(HLD)carbon

coated stainless steel blades

with Titanium

5. On/Off button

6. LCD display shows:

7. Selected cutting

length in mm

8. Battery life remaining /

charging indicator

9. Dual foil shaver attachment

10.Cord/cordlessdesign.

Advanced power

performancewithlong-

lasting dual battery system

11.

AC power adaptor

12.

Cleaning brush

13.

Lubricating oil

INSTRUCTIONS FOR USE

•Aplasticcoverhasbeenplacedovertheadaptorplugtoprotect

itfromdamageduringtransportation. Remove theplasticcover

before inserting into a suitable power outlet.

•Alwaysinspecttheappliancebeforeusetoensurethecuttinghead

is free from hair and debris, and is running smoothly.

•Ensuretheapplianceisswitchedoffbeforepluggingintoasuitable

power outlet.

CHARGING THE TRIMMER

(FOR CORDLESS OPERATION)

To charge the appliance, place the adaptor charging cord directly

into the base of the trimmer.

1.PlugtheACpoweradaptorintoa100v–240vpowersupply.

2. When the appliance is switched off, plug the charging cord

directly into the base of the trimmer.

3.Switchtheadaptoron.TheLCDdisplaywillthenilluminateand

the charging indicator will appear in the LCD display. Always

check the charging indicator illuminates, so you know you have

correctly inserted the adaptor charging cord into the base of the

trimmer.

IMPORTANT: Before using the appliance for the ﬁrst time, charge

for a full 16 hour continuous charge.

After the ﬁrst charge, the trimmer has a 90 minute charge and

60 minute run time, plus the 5 minute quick charge and 3 minute

run time. Maximum battery capacity will only be reached after

3 charging and discharging cycles.

In order to maintain optimum capacity of the rechargeable

batteries, every 3 months the trimmer should be charged for a

full 16 hour continuous charge.

4. The LCD will always stay illuminated and the charging indicator

in the LCD display will always be ﬂashing when the product

is charging. When the product is fully charged, the charging

indicator will be solid and no longer ﬂashing – this indicates that

a full charge has been reached.

5.Afullchargewillsupplyenoughpowerforminimum60minutes

use. The remaining battery life is shown in the LCD display. The 5

minutesquickchargefunctionwillprovide3minutesuse.

CORDED USE – OPERATION WITH POWER CORD

1.PlugtheACpoweradaptorintoa100v–240vpowersupply.

2. When the appliance is switched off, plug the charging cord

directly into the base of the trimmer.

3. Switch the adaptor on, and the trimmer can now be used in

corded operation.

NOTE – If battery power is weak, wait about 2 minutes before

pressing the on/off button.

24 Ultra Precise Cutting Length Settings (0.4mm to 5mm)

Theinnovativei-trimprecise+StubbleTrimmerusesanintegrated

stubble comb guide with 24 ultra precise control settings eliminating

the need for charging and storing different attachment combs.

Thecuttingguideismotorisedforeasyonetouchadjustmentand

features an LCD display for conﬁrmation of the length setting

selected. When you select your required length, the length setting

will then remain displayed in the LCD screen.

1.Usethecuttinglengthsettingbuttonsonthetrimmertoadjust

the motorised stubble comb guide.

2. Press the power on button to activate the trimmer motor.

3.Presstheupordownarrowbuttonstoselecttherequiredlength

settingin0.2mmincrementsfrom0.4mmthroughto5mm(NB–

thetrimmerwillstopwhilethecombguideisbeingadjusted).

STARTING AND USING YOUR I-TRIM PRECISE+

1. Press the on/off button to activate the trimmer.

2. When the trimmer is switched on, the battery indicator in the LCD

displaywillcyclethroughafewtimes(approx5times)beforethe

remaining battery life is displayed.

3.Presstheupordownarrowbuttonstoadjustandsetthecutting

length. Pressing one of these buttons will stop the trimmer motor.

Itisalwayssuggestedtostartcuttingwithalongerlengthrst,

then trim again if the length is longer than desired.

4. Hold the trimmer against the hair, the teeth of the comb guide

should be pointing upwards and should be ﬂat against the face.

The unique contouring ﬂex head with excusive blade design

allows for trimming at any angle – it perfectly adjusts to the

contours of your face for precision stubble results, every time,

whilst the integrated stubble comb guide helps to avoid uneven

cuts, by providing direction and helping you to hold the trimmer

comfortably on the face.

5.Movethetrimmerupwardsthroughthehair,alittleatatime,

with and against the direction of hair growth, whichever is most

comfortable, as most men have hair growing in many different

directions.

6. The i-trim precise+ will work most effectively when cutting

through the hair at its own speed – never force the trimmer. You

may experience a little resistance around the moustache area,

where hair is thicker and grows in many different directions. This

is completely normal.

7.Neverswitchthetrimmeroffwhilstinthehair.

8. To turn the trimmer off:

To switch off the i-trim precise+ hold down the ‘Power on/off’

button for 2 seconds then release.

MEMORY FUNCTION

This stubble trimmer has a memory function that stores the last

chosen length setting. When the unit is switched off the comb

guide returns to 0.4mm position. When the trimmer is switched

back on the comb guide automatically moves up to the last chosen

length setting.

USING THE STUBBLE COMB GUIDE

Youri-trimprecise+comesassembledwiththeintegratedmotorised

all-in-one stubble comb guide already installed. The integrated

stubble comb guide allows you to change the cutting length of your

trimmerwithease.You’llneedtoexperimenttondyourpreferred

length, but as a guide, 0.4mm will give you an ultra close, short

shadow stubble effect, whilst 2mm will give you a longer designer

stubblelookand3.4mm+willgiveyoualonger,moreruggedlook

(shortbeard).

IMPORTANT: Always detach and attach the integrated stubble comb

guideBEFOREturningthetrimmeron.

Always ensure when using the trimmer that the integrated stubble

comb guide is correctly positioned in place. Check this by pushing

the comb guide gently downwards to ensure it is secured in place.

Using The Trimmer Without The Comb Guide

Usingthe trimmer withoutthe combguide isideal for detailing/

shaping and general tidying of edges around

your stubble, sideburns and moustache.

1. To detach the comb guide, gently hold the

trimmer in one hand and with your thumb and

index ﬁnger, push the comb guide up on each

side(Fig.1).

2.Flipthecombguidetothebackoftheunitand

lock it into position by clicking it securely onto

thefasteneronthebackofthehandle(Fig.2).

IMPORTANT: When using the trimmer without

the stubble comb guide, the cutting length will

bebelow0.4mm.Thelengthsettingshowonthe

LCD screen will no longer be relevant when the

comb guide is detached.

Fig. 1

Fig. 2

Fig. 1

Fig. 2

Using the Shaving Head

The shaver attachment adapts perfectly to the contours of

the face and is ideal for smooth skin and creating a clean, sharp

edge to your stubble or any facial hair styles and for trimming hard

to reach areas, particularly around the ears and nape of the neck.

The foil shaver will leave the skin feeling smooth and refreshed,

with reduced irritation.

NB–Alwaysinspectthefoilwhilstshavingforsignsofdamage.

Nevershavewithadamagedfoilasthismayresultininjury.

1.Ensurethetrimmerisswitchedoff.

2. Attach the facial shaver attachment.

3.Useyourfreehandtostretchtheskinandmakethefacialhairs

stand out.

4.Movetheshaverslowlyovertheskin,applyingminimalpressure

and allow the shaver to fully shave tough areas of hair. Do not

press.

5.Fortheclosestshave,shaveagainstthedirectionofhairgrowth,

or with the hair growth, whichever is preferred, but remember

that hair grows in different directions.

Attaching and removing the heads

Make sure the appliance is

switched off. First, detach the

comb guide and click it onto

the back of the trimmer (Fig. 2).

Hold the trimmer and remove the

trimmer head by pushing the tip

ofthebladeupward(Fig.3).Slide

the shaving head into place, then

carefully push the head down

until you hear a click (Fig. 4). To

remove the shaving head, hold

the trimmer and push the base

of the head upward using your

thumb (Fig. 5). To reattach the

trimmer head, slide the back of

1 2

Table des matières

Autres manuels VS Sassoon Rasoir électrique

VS Sassoon

VS Sassoon VSM2330A Instructions de montage

VS Sassoon

VS Sassoon SUPER BEARD XTP VSM7876A Instructions de montage

VS Sassoon

VS Sassoon Metro Groom Manuel utilisateur

VS Sassoon

VS Sassoon VSM350A Manuel utilisateur

VS Sassoon

VS Sassoon THE ESSENTIAL CUT Instructions de montage

VS Sassoon

VS Sassoon THETRIMBUDDY VSM702A Instructions de montage

VS Sassoon

VS Sassoon VSM7898A Manuel utilisateur

VS Sassoon

VS Sassoon i-Twin Trim VSM155A Manuel utilisateur

VS Sassoon

VS Sassoon VS7863A Manuel utilisateur

VS Sassoon

VS Sassoon PRO METAL Series Manuel utilisateur

VS Sassoon

VS Sassoon The Crafted Trim VSM7847A Instructions de montage

VS Sassoon

VS Sassoon The Beard Designer Manuel utilisateur

VS Sassoon

VS Sassoon VSM7052A Manuel utilisateur

VS Sassoon

VS Sassoon Trim & Groom VSM856A Instructions de montage

VS Sassoon

VS Sassoon ELITE CLIP VSM6000A Instructions de montage

VS Sassoon

VS Sassoon The Rugged Commander Lithium All-In-One Manuel utilisateur

VS Sassoon

VS Sassoon VSM7472A Manuel utilisateur

VS Sassoon

VS Sassoon VSM189RA Instructions de montage

VS Sassoon

VS Sassoon Metro Cordless HairCut VS704A Manuel utilisateur

VS Sassoon

VS Sassoon THE BEARD BUDDY VSM703A Instructions de montage

VS Sassoon

VS Sassoon Xpert Precision VSM50MA Manuel utilisateur

VS Sassoon

VS Sassoon VS7053A Manuel utilisateur

VS Sassoon

VS Sassoon Xpert Beard VSM7865A Instructions de montage

VS Sassoon

VS Sassoon I-TRIM STUBBLE+ VS7855A Manuel utilisateur

Manuels Rasoir électrique populaires d'autres marques

Philips

Philips MicroAction 4402LC Manuel utilisateur

Philips

Philips HQ7740 Manuel utilisateur

Philips

Philips Norelco BG2022 Bodygroom Manuel utilisateur

Norelco

Norelco Quadra 7610X Manuel utilisateur

Philips

Philips 7616X Manuel utilisateur

Philips

Philips HQ802 Manuel utilisateur

Philips

Philips HQ7363/17 Manuel utilisateur

Braun

Braun WaterFlex WF2s Manuel utilisateur

Philips

Philips NORELCO S7371 Manuel utilisateur

Daga

Daga MT-400 Manuel

Philips

Philips RQ119x Manuel utilisateur

Remington

Remington BHT100 Manuel utilisateur

Philips

Philips Bodygroom BG2000 Manuel utilisateur

Kompernass

Kompernass KH 5537 Manuel utilisateur

Remington

Remington BHT6100 Manuel utilisateur

Philips

Philips qc5365 Manuel utilisateur

MIA

MIA Aqua Body Manuel utilisateur

Philips

Philips NORELCO AT880 Manuel utilisateur
