2.0 List of Figures
Figure Description Page
1 Laser Safety Label Location 2
2 Serial Number Label 2
3 Laser Head Power Indicator 4
4 Control Box Power Indicator 4
5 Control Box Interlock Indicator 5
6 Remote Interlock Plug 6
7 Interlock Diagram 7
8 Laser Emission Indicator 8
9 Laser Shutter Positions 8
10 Control Box Key Switch 9
11 System Block Diagram 12
12 Laser Head Dimensions 15
13 Control Box Dimensions 15
14 Laser Head Torque Pattern 16
15 Mini-DIN Plug 18
16 I/O Pin Diagram 18
17 Remote Interlock Plug 20
18 Laser Head Dimensions 21
19 Laser Mounting Dimensions 21
20 Laser Mounting Torque Pattern 22
21 Laser Solder Connections 23
22 Laser Head Pin Numbers 24
23 I/O Pin Diagram 30
24 Laser Head Pin Numbers 31
25 Laser Head Shutter Positions 32
26 Near-field Beam Image 32
27 Far-field Beam Image 33
28 SMB Connector Location 34
29 Pulse Mode Example 35
30 USB Connector Location 37
31 USB Connector Diagram 37
32 Initial USB Connection Message 59
33 Computer Restart Message 59
34 Windows Device Manager 60
35 Computer Properties 60
36 System Properties 61
