Volthium WALLMOUNT Series Manuel utilisateur
USER MANUAL –WALLMOUNT
25.6V 200AH
1
DESCRIPTION
The WALLMOUNT SÉRIES is composed of 100AH certified prismatic square cells with
certifications: UL9540A, UL1973, UL1642, IEC62619, IEC62660.
For more details refer to the technical sheet.
No.
Fonction
1
Positive terminal
2
Negative terminal
3
LCD –Valid for Voltage only *SOC shown is not manage by
the BMS and cannot be take in consideration
4
Communication port –used to access BMS
5
ON / OFF switch for the battery
1
2
3
4
5
USER MANUAL –WALLMOUNT
25.6V 200A
USER MANUAL –WALLMOUNT
25.6V 200AH
2
CURRENT AND LOAD VOLTAGE
DESCRIPTION
BATTERIE 25.6V
Bulk
28.8V
Absorption (optionnel)
28.8V
Float
27.2V
Charge current per unit
40A
Low disconnect voltage (BMS)
21.5 –22.4
PARALLELING
When the DC current of the battery bank exceeds 150A, we suggest the use of BUSBAR.
Each battery will connect to the BusBar using an AWG-2 cable, and then from the BUSBAR
to your equipment with the cable of your choice.
ON/OFF SoftSwitch
The ON/OFF switch of the battery (SoftSwitch) has the effect of disabling or enabling the
BMS. Once the BMS is deactivated, no current can enter or leave the battery. Note that it
is not possible to deactivate the battery via the ON/OFF switch if the battery is in use
(charging or discharging current in operation).
Even though the battery is closed by the SoftSwitch, if you apply voltage to the battery
terminals, the display will still light up.
USER MANUAL –WALLMOUNT
25.6V 200AH
3
USAGE ENVIRONMENT
Type
Points required
Usage Temperature
Range of function：-20℃~+60℃
Storage Temperature
-20℃~+60℃
Humidity Level
＜95%
Atmospheric pressure
86kPa~106kPa
Essentials
No conductive dust and corrosive gas, no vibration.
Keep away from heat and flame.
CAUTIONS
Please read and respect the following battery installation conditions and use, improper
installation using the battery may cause personal injury or damage the product.
1. DO NOT throw the battery in water. Store batteries in a cool, dry environment when it
is not in use.
2. DO NOT ignite the battery or heat the battery to avoid explosion or other dangerous
events.
3. When charging the battery, please choose specialized charging equipment and follow
the correct procedures, do not use improper chargers.
4. DO NOT reverse positive and negative terminals, do not connect battery directly to AC
power, avoid battery short circuit.
5. DO NOT use batteries from different manufacturers or different types and types
together, and do not use old batteries with new batteries.
6. DO NOT use the battery when it becomes hot, swells, deforms, or leaks.
USER MANUAL –WALLMOUNT
25.6V 200AH
4
7. DO NOT pierce the battery with a screwdriver or other sharp object; do not throw, dab,
knock or hit the battery.
8. DO NOT open or attempt to repair the battery when it is defective. Warranty invalid if
the battery is repaired or disassembled.
9. The batteries are half charged before shipping, do not use the battery if it is hot, bulging
or has an abnormal smell and so on, and notify the after-sales service. At once.
10. If you need to store the battery for a long time, please charge and discharge the
battery every three months to ensure the best performance, and the best charge state for
storage is between 50% ~ 60%.
11. Please use the battery within the temperature range set in the manual.
12. The state of charge of the batteries is 50% before shipment, please charge the battery
before use.
Note: If you have specific technical issues not listed above, please contact technical
staff.
USER MANUAL –WALLMOUNT
25.6V 200AH
5
STATE OF CHARGE (SOC) AND VOLTAGE WHEN DISCHARGING AT 50AH
25.6V 200A -50A discharge
SOC
Voltage
100%
27.01
90%
26.02
80%
25.98
70%
25.87
60%
25.72
50%
25.66
40%
25.57
30%
25.40
20%
25.14
10%
24.71
0%
21.64
