VMware VeloCloud Edge Manuel utilisateur
Revision History
Revision Number
Date
Notes
1.3
7/3/18
Add revision history.
Change to new
corporate template
Introduction
This document provides instructions on how to factory reset
and test a VeloCloud Edge unit.
Tools Required
● 1x computer dedicated to testing Edge units. (Make
sure the computer or laptop only has a network
connection to the Edge).
● 2x Ethernet cable, 2x SFP transceivers, 1x fiber
cable.
Performing a Hard Reset on the VeloCloud Edge
Follow the procedures below to perform a hard factory reset
to the VeloCloud Edge. This restores the original
manufactured image to the Edge.
1. Make sure the Edge is powered down.
2. Locate the RESET button located on the back of the
Edge as shown in the image below.
0. Insert a paperclip or something similar into the
RESET button (see image below).
0. While holding the paperclip on the RESET button,
plug the power into the Edge as shown in the image below.
0. Hold the paperclip on the RESET button for 30
seconds to a minute until the cloud LED on the front panel of
the Edge pulses dark blue. (See image below).
0. Once the cloud LED pulses dark blue, release the
RESET button and wait for the Edge to reboot. (During the
reboot process, the cloud LED light turns white, flashes
white, and then turns red or green after the Edge boots up).
0. Connect one Ethernet/cat5 cable (with Internet
access) into the “GE1” port and connect one Ethernet/cat5
cable from a computer into the “LAN1” port. (See image
below).
Removing System Logs from the Edge
VeloCloud is in the process of creating a tool that you can
run immediately after the hard reset (the hard reset is
described in the above section) that will enable you to
remove all the persistent system logs and unused data
partitions to ensure that the Edge is in a factory-shipped
state. These instructions will be updated once the tool is
available.
Testing the VeloCloud Edge
Follow the steps below to test the Edge.
1. Open an Internet browser and go to http://192.168.2.1
The VeloCloud Edge Activation screen displays as
shown in the image below.
2. Click the Review the Configuration link in the
VeloCloud Edge Activation screen.
3. In the Edge Overview screen, click the Details button.
Make sure the GE1 and the LAN1 status indicators display
green indicating that they are active, and make sure the
cloud LED (the only LED) on the front of the Edge is yellow.
4. Open a separate Internet browser and verify that you can
connect to any website (e.g. www.google.com).
5. Return to the VeloCloud Edge Activation screen (IP
address http://192.168.2.1) and test all of the LAN ports
1-8 and GE ports 1-2.
a. Move the computer cable into each of the LAN
ports in turn, from LAN1 through LAN8. At each step, verify
that the status indicator in the local UI for that port displays
green.
b. Move the Internet cable from GE1 into GE2,
and verify that the status indicator for GE2 in the local UI
becomes green. Leave the Internet cable in GE2 at the end
of this test.
c. Test the two SFP ports (SFP1 and SFP2) by
using a fiber cable with two fiber SFP modules, or a ‘direct
attach’ SFP cable to loop them together. Check that the Link
lights turn on, and the local UI displays them as red. (See
image below).
6. Test the four USB ports one by one, by inserting a blank
USB flash key into them, and make sure the
corresponding status indicator on the local UI for that
USB port turns red. (If it remains grey, the USB port is
broken.)
7. Safely shut the unit down by clicking the Details button,
the Reset Settings button, and then click the Reboot
button. When prompted, enter the username as “admin”
and password as “admin.” (See the next three images
below).
