IP Surveillance

User’s Manual

AE2101

Camera Enclosure

Specications

Model Number AE2101

Power Input 90~240VAC (+/-10%)

Rating Current 3.5 A

Heater Control 18 +/-3°C (ON) / 28 +/-3°C (OFF)

Blower Control 35 +/-3°C (ON) / 25 +/-3°C (OFF)

Environmental Operation Temp. -20°C ~ +50°C

Protection Level IP68

Temper Glass thickness 4mm

Mounting Bracket Fully-cable Management

Construction Die-cast Aluminum Alloy

Coating Ivory Powder & Stove Finish

Dimensions 425 (L) x 160 (W) x 165 (H) mm

Camera Space 275 (L) x 90 (W) x 100 (H) mm

Net Weight 5230 g

CAUTION:

TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE COVER.

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

UNPACKING:

Unpack carefully. Electronic components can be damaged if improperly handled or

dropped. If an item appears damaged in shipment, place it properly in its carton and

notify the shipper.

IMPORTANT!

1. Read and follow Instructions: All operating and user instructions should be read and

followed before the unit is to be operated.

2. Electrical Connections: Only a qualied electrician is allowed to make electrical

connections.

English

Mounting Conguration & Dimensions

82.80mm

69.00mm

94.95mm

Swivel Positions and

Directions

Bracket Base Dimensions

BR-13 Full-cable Management

Bracket

160mm

68.5mm

83.2mm

425mm

165mm

Component Description

III

Camera Mounting

Platform Cable Conduits

Bushing Power Supply

Unit

Ground Wire

Blower

Terminal Block

Assembly

Thermal Control

Board

Heater

Shield

Heater

Wiring Diagram

Shown below is the wiring diagram for the window demister. A spare 6-way terminal block

is provided at the rear of the chassis for additional camera and lens connections.

H1, Heater

STAT.1 TURN OFF at 28 C

TURN ON at 18 C

B2, Blower

STAT.2 TURN OFF at 25 C

TURN ON at 35 C

12VDC X4

3.5A or 5A

24VAC or

80~260VAC Input

H.1

B.2

PCB.1 CHASSIS EARTH

COVER EARTH

FTB. 1 FS. 1

TB. 1

TB.2

STAT.2

STAT.1

SPARE

PSU

TB.1 6 way terminal block

TB.2 3 way terminal block

FTB.1 Fused terminal block

STAT.1 18°C Thermostat

STAT.2 35°C Thermostat

H.1 Heater

PSU Power Supply Unit

P.C.B.1 Thermal control

circuit board

FS.1 3 Amp. Fuse

1. Pins 1, 2, 3, and 4 are DC 12V output for motor lens, siren, or speaker connecitons. If

they are not connected, remove cables from the connectors.

2. Pins 5 and 6 are DC 12V output for camera.

DC Output of PSU Connectors

H1. Heater

STAT.1 TURN OFF at 28°C

TURN ON at 18°C

B2. Blower

STAT.2 TURN OFF at 25°C

TURN ON at 35°C

Lines for

heater & blower

Pins 5 & 6

DC for camera

Pins 1 & 2

12V Output

Pins 3 & 4

12V Output

CHASSIS EARTH

COVER EARTH

English

Installation Suggestions

If you plan to install this camera enclosure into a tropical, sea coastal, or an environment

where salt water or corrosive industrial waste water/moist are present, please seal each

stainless steel screws and ttings with a silicon grease compounds. This will help prevent

electrolysis to occur and extend the life span of the camera and housing.

IMPORTANT!

1. Disconnect devices: A readily accessible disconnect device in the building installation

wiring should be incorporated.

2. Electrical Connection: Only a qualied electrician is allowed to make electrical

connections.

Features

Model Name

Heater:

On at 18OC

Off at 28OC

Blower

On at 35OC

Off at 25OC

PSU

(Power Supply Unit)

12VDC/24VAC 12VDC 080 324

080/F -• • -

080/HF • • • -

324/HF • • -•

1. 080: [90~240VAC input (+/-10%), 4x12VDC output, 3.5A]

2. 324 (24VAC input, 4x12VDC output, 3.5A)

Below are AC power connections to the FTB. 1 connector.

AC Power Connection

AC 24V Input AC 24V Input

Ground

Green Line

2. Remove the camera bracket by

loosening 4 screws using a mid-size

Phillips screwdriver. Loosen the socket

screw on top of the bracket to remove

the rectangular support.

3. Place the rubber insulation pad

on top of the camera with its opening

aligned with the screw hole.

Rectangular Support

Camera Installation

1. Loosen the socket screws

using the included L-type hex key

wrench, and open the cover.

English

4. Mount the bracket on top of camera

in a reversed orientation to gain more

space for the lens module to zoom in/

out. You may change the camera's

vertical position by adjusting the screws

on the sides of bracket.

5. When done, place the camera into

the housing, secure the bracket to the

bottom of housing, and tighten the

socket screw.

6. Route your AC input, DI/DO, and

Ethernet cables through the BR-13

bracket, and then the rubber bushing at

the bottom of the housing.

In order to pass cables through, you

may need to disassemble the BR-13

bracket. Use the included L-type wrench

to loosen the screws and pass cables

through the bracket.

When done, re-assemble the bracket

and its swivel parts.

8. Connect 24V AC lines to the FTB.

1 connectors.

AC Input

7. Connect the Ethernet cable and the

12V DC connector to your camera. You

may use the BNC connector for initial

image adjustment.

BNC Connector

RJ-45 Ethernet

12V AC Input

9. Secure the housing to the bracket

using the supplied socket screws. Pan and

tilt the housing to aim at the monitored

area.

10. Mount the bracket to a desired

position using the included mounting

screws.

BNC

Connector

12V DC

Input

RJ-45 Ethernet

AC Input

English

11. After you adjust the camera's zoom

and focus, close and secure the cover by

tightening the socket screws using the

L-type wrench.

規格

型號 AE2101

電源輸入 90~240VAC (+/-10%)

額定電流 3.5 A

加熱器控制 18 +/-3°C (開) / 28 +/-3°C (關)

吹風機控制 35 +/-3°C (開) / 25 +/-3°C (關)

環境操作溫度 -20°C ~ +50°C

保護層級 IP68

強化玻璃厚度 4mm

安裝支架完整纜線管理

構造鑄模鋁合金

塗料象牙粉及烤漆

尺寸 425 (L) x 160 (W) x 165 (H) mm

攝影機尺寸 275 (L) x 90 (W) x 100 (H) mm

淨重 5230 g

重要事項！

1. 請閱讀並遵照指示：在操作機體之前，請先閱讀並遵照所有操作及使用指示說明。

2. 連接電線：僅可由合格電力技師執行電線連接工作。

注意：

為降低火災或觸電的風險，請勿移除護蓋。用戶不得進行內部零件的維修工作。

請洽詢合格的技術服務人員以進行維護。

拆封：

請小心拆封。若不當處理或掉落，電子元件可能會受損。若出貨包裝內的物品可能受

損，請妥善放置在其紙箱內，並通知出貨商。
