DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

Table of Contents

The Serial Interface RS-232 Command ........................................................................................2

Communication parameter.........................................................................................................................................2

Operation commands.................................................................................................................................................2

Operation command syntax................................................................................................................................2

List of operation commands ...............................................................................................................................3

Simulated IR remote controller commands..............................................................................................................14

Control the Projector Through a Network..................................................................................15

Cable connection .....................................................................................................................................................15

Set up the projector for networking..........................................................................................................................16

Control the projector through a network ..................................................................................................................17

Control the projector through a web browser ...................................................................................................17

Control projector with TCP/IP communication protocol ....................................................................................23

About Vivitek Support .................................................................................................................24

DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

The Serial Interface RS-232 Command

This projector supports to control by RS-232 command, there exist two types of RS-232 serial commands:

Operation command: Available menu options are INPUT, PICTURE, ALIGNMENT, CONTROL and SERVICE.

Simulated IR remote controller commands: Controls projector via RS-232 command, the commands simulate IR

remote controller and its control keys.

Communication parameter

You can use the serial control command to input commands for projector control or retrieve its operational data

through Windows client terminal software, e.g. Hyper Terminal, with ASCII characters. You need to set up the following

communication parameters in advance:

Item Parameter:

Bit per Second 9600 bps

Data Bit 8-bit

Parity None

Stop Bit 1

Flow Control None

Port 7000

Note:

The terminal software does not return every command input character

The transmission performance varies with the length of RS-232 cable

Operation commands

Operation command syntax

An operation command is prefixed by character "op", followed by control commands and settings separated by

space blank [SP], and ended by carriage return pair "CR" and "ASCII hex 0D".Syntax of serial control

commands:

op[SP]<operation command>[SP]<Setting Value>[CR]

op :

A constant indicating this is an operation command.

[SP] :

Indicate one blank space.

[CR] :

Indicate the command ending carriage return pair "CR" and "ASCII hex 0D".

Setting value : Settings of operation command

Types of setup strings Characters of settings Description

Query current setup ? Question mark "?" indicates querying current setup

Setup = <settings> Syntax: Symbol "=" suffixed with setup values

Increase setup order of

adjustment items

+ Some settings are changed in steps. Symbol "+"

indicates changing one step up

Decrease setup order of

adjustment items

- Some settings are changed in steps. Symbol "-"

indicates changing one step down

Execute operation command None Certain operation commands execute after input

without further setting or regulators.

Examples:

Control items Input command Projector return message

Query current brightness op bright ? [CR] OP BRIGHT = 101

Set up brightness op bright = 127 [CR] OP BRIGHT = 127

Set up input signal source to

HDMI

op input.sel = 0 [CR] OP INPUT.SEL = 0

Reset projection lens to

center position

lens.center

Note:

When sending the multiple commands, make sure the return message of the last command is received

before sending out the next one.

DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

List of operation commands

INPUT

OSD Function Operation

command

Settings/Return Values Note

Input Select input.sel ?

0 = HDMI 1

1 = HDMI 2

3 = HDBaseT

4 = 3G-SDI

Not applicable when the project is at

standby mode

PIP/PIP Option pip ?

0 = Off

1 = On

Not applicable when the project is at

standby mode and 3D mode

PIP/PIP Input pip.sel ?

0 = HDMI 1

1 = HDMI 2

3 = HDBaseT

4 = 3G-SDI

Not applicable when the project is at

standby mode or PIP option is set to

Off.

PIP/ Position pip.pos ?

0 = Top Left

1 = Top Right

2 = Bottom Left

3 = Bottom Right

4 = PBP

Not applicable when the project is at

standby mode or PIP is set to Off.

Auto Source auto.src ?

0 = Off

1 = On

Not applicable when the projector is

at standby mode.

Auto Sync Auto.mg (execute) Available when source is locked.

Color Space color.space ?

0 = Auto

1 = YPbPr (Rec. 709)

2 = YcbCr (Rec. 601)

3 = RGB-PC (0-255)

4 = RGB-Video (16-235)

Available when source is locked.

Aspect Ratio aspect ?

0 = 5:4

1 = 4:3

2 = 16:10

3 = 16:9

4 = 1.88

5 = 2.35

6 = LetterBox

7 = Source

8 = Native

Available when the source is locked.

VGA Setup/H Total h.total ?

0-200

Available when the source is locked

Or Input source is VGA or

Component(RGBHV)

VGA Setup/H Start h.pos ?

0-200

Available when the source is locked

Or Input source is VGA or

Component(RGBHV)

VGA Setup/H Phase h.phase ?

0-200 Available when the source is locked.

Input source is VGA or

Component(RGBHV)

VGA Setup/V Start v.pos ?

0-200 Available when the source is locked.

Input source is VGA or

Component(RGBHV)

DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

OSD Function Operation

command

Settings/Return Values Note

Test Pattern pattern ?

0 = Off

1 = CrossHatch

2 = Color Bar

3 = Checkboard

4 = H Burst

5 = V Burst

6 = White

7 = Red

8 = Green

9 = Blue

10 = Black

Not applicable when the project is at

standby mode.

3D/3D Format 3d.format = ? 0 = Off

1 = Auto

2 = Side-By-Side (Half)

3 = Top-And-Bottom

4 = Frame Sequential

Not applicable when the project is at

standby model.

3D/Eye Swap 3d.swap = ? 0 = Normal

1 = Reverse

Applicable when the projector is at

3D mode.

3D/DLP Link 3d.dlplink = ? 0 = Off

1 = On

Applicable when 3D.Darktime is set

to 2 (1.95ms)

3D/Dark Time 3d.darktime = ? 0 = 0.65 ms

1 = 1.3 ms

2 = 1.95 ms

Applicable when the projector is at

3D mode.

3D/sync delay 3d.syncdelay = ? 1 – 60 Applicable when the projector is at

3D mode.

3D/Sync Reference 3d.syncref = ? 0 = External

1 = Internal

2 = Auto

Not applicable when the project is at

standby mode.


OSD Function Operation

command

Settings/Return Values Note

Picture Mode pic.mode ?

0 = High Bright

1 = Presentation

2 = Video

Not applicable when the project is at

standby mode.

Brightness bright ?

0-200 Not applicable when the project is at

standby mode or the input signal is

not locked yet.

Contrast contrast ?

0-200 Not applicable when the project is at

standby mode or the input signal is

not locked yet.

Saturation saturat ?

0-200 Apply for YUV signal input

Not applicable if the input signal is

not locked yet.

Hue tint ?

0-200 Apply for YUV signal input

Not applicable if the input signal is

not locked yet.

Sharpness sharp ?

0-10 Not applicable when the project is in

standby mode or the input signal is

not locked yet.

DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

OSD Function Operation

command

Settings/Return Values Note

Noise Reduction nr ?

0 = Off

1 = Low

2 = Middle

3 = High

Not applicable when the project is at

standby mode.

Color Temperature color.temp ?

0 = 5400K

1 = 6500K

2 = 7500K

3 = 9300K

4 = Native

Not applicable at 3D mode

Gamma gamma ?

0 = 1.0

1 = 1.8

2 = 2.0

3 = 2.2

4 = 2.35

5 = 2.5

6 = S-Curve

7 = DICOM

8 = HDR-PQ400

9 = HDR-PQ500

10 = HDR-PQ1000

11 = HDR-HLG

Not applicable when the project is at

standby mode or the input signal is

not locked yet.

Overscan zoom ?

0 = Off

1 = Crop

2 = Zoom

Not applicable when the project is at

standby mode or the input signal is

not locked yet.

Input Balance /Red

Offset

red.offset ?

0-200 Available when the input source is

locked.

Input Balance /Green

Offset

green.offset ?

0-200 Available when the input source is

locked.

Input Balance /Blue

Offset

blue.gain ?

0-200 Available when the input source is

locked.

Input Balance /Red

Gain

red.gain ?

0-200 Available when the input source is

locked.

Input Balance /Green

Gain

green.gain ?

0-200 Available when the input source is

locked.

Input Balance /Blue

Gain

blue.gain ?

0-200 Available when the input source is

locked.

HSG/Red Gain hsg.r.gain ?

0-200 Available when the input source is

locked.

DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

OSD Function Operation

command

Settings/Return Values Note

HSG/Green Gain hsg.g.gain ?

0-200 Available when the input source is

locked.

HSG/Blue Gain hsg.b.gain ?

0-200 Available when the input source is

locked.

HSG/Cyan Gain hsg.c.gain ?

0-200 Available when the input source is

locked.

HSG/Magenta Gain hsg.m.gain ?

0-200 Available when the input source is

locked.

HSG/Yellow Gain hsg.y.gain ?

0-200 Available when the input source is

locked.

HSG/Red/Saturation hsg.r.sat ?

0-200 Available when the input source is

locked.

HSG/Green/Saturation hsg.g.sat ?

0-200 Available when the input source is

locked.

HSG/Blue/Saturation hsg.b.sat ?

0-200 Available when the input source is

locked.

HSG/Cyan/Saturation hsg.c.sat ?

0-200 Available when the input source is

locked.

HSG/Magenta/

Saturation

hsg.m.sat ?

0-200 Available when the input source is

locked.

HSG/Yellow/Saturation Hsg.y.sat ?

0-200 Available when the input source is

locked.

HSG/Red/Hue hsg.r.hue ?

0-200 Available when the input source is

locked.

HSG/Green/Hue hsg.g.hue ?

0-200 Available when the input source is

locked.

HSG/Blue/Hue Hsg.b. hue ?

0-200 Available when the input source is

locked.

DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

OSD Function Operation

command

Settings/Return Values Note

HSG/Cyan/Hue hsg.c. hue ?

0-200 Available when the input source is

locked.

HSG/Magenta/Hue hsg.m. hue ?

0-200 Available when the input source is

locked.

HSG/Yellow/Hue Hsg.y. hue ?

0-200 Available when the input source is

locked.

HSG/White/Red Gain hsg.wr.gain ?

0-200 Available when the input source is

locked.

HSG/White/Green Gain hsg.wg.gain ?

0-200 Available when the input source is

locked.

HSG/White/Blue Gain Hsg.wb.gain ?

0-200 Available when the input source is

locked.

HSG Reset hsg.reset (execute) Available when the input source is

locked.

Dynamic Black dblack ?

0 = Off

1 = On

Not applicable when the projector is

at below condition:

- Standby mode.

- Edge Blend is On

- 3D mode

- Dynamic Black is off

Freeze freeze ?

0 = Off

1 = On

Not applicable when the projector is

at standby mode

Alignment

OSD Function Operation

command

Settings/Return Value Note

Lens control

Zoom

zoom.in (execute) Not applicable when the projector is

at standby mode

Lens control

Zoom

zoom.in.2 (execute) Not applicable when the projector is

at standby mode.

Lens control

Zoom In

zoom.in.3 (execute) Not applicable when the projector is

at standby mode.

Lens control

Zoom Out

zoom.out (execute) Not applicable when the projector is

at standby mode.

Lens control

Zoom Out

zoom.out.2 (execute) Not applicable when the projector is

at standby mode.

Lens control

Zoom Out

zoom.out.3 (execute) Not applicable when the projector is

at standby mode.

Lens control

Focus near

focus.near (execute) Not applicable when the projector is

at standby mode

DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

OSD Function Operation

command

Settings/Return Value Note

Lens control

Focus near

focus.near.2 (execute) Not applicable when the projector is

at standby mode.

Lens control

Focus near

focus.near.3 (execute) Not applicable when the projector is

at standby mode.

Lens control

Focus far

focus.far (execute) Not applicable when the projector is

at standby mode.

Lens control

Focus far

focus.far.2 (execute) Not applicable when the projector is

at standby mode.

Lens control

Focus far

focus.far.3 (execute) Not applicable when the projector is

at standby mode

Lens control

Lens up

lens.up (execute) Not applicable when the projector is

at standby mode.

Lens control

Lens up

lens.up.2 (execute) Not applicable when the projector is

at standby mode.

Lens control

Lens up

lens.up.3 (execute) Not applicable when the projector is

at standby mode.

Lens control

Lens down

lens.down (execute) Not applicable when the projector is

at standby mode.

Lens control

Lens down

lens.down.2 (execute) Not applicable when the projector is

at standby mode.

Lens control

Lens down

lens.down.3 (execute) Not applicable when the projector is

in standby mode.

Lens control

Len left

lens.left (execute) Not applicable when the projector is

at standby mode

Lens control

Len left

lens.left.2 (execute) Not applicable when the projector is

at standby mode.

Lens control

Len left

lens.left.3 (execute) Not applicable when the projector is

at standby mode.

Lens control

Lens right

lens.right (execute) Not applicable when the projector is

at standby mode.

Lens control

Lens right

lens.right.2 (execute) Not applicable when the projector is

at standby mode.

Lens control

Lens right

lens.right.3 (execute) Not applicable when the projector is

at standby mode.

Lens Memory /

Load Memory

lens.load ?

1-10 set of lens memory

(Load)

Not applicable when the projector is

at standby mode

Lens Memory /

Save Memory

lens.save ?

1-10 set of lens memory

(Save)

Not applicable when the projector is

at standby mode.

Lens Memory /

Clear Memory

lens.clear ?

1-10 set of lens memory

(Save)

Not applicable when the projector is

at standby mode.

Center Lens lens.center (execute) Not applicable when the projector is

at standby mode or Lens Lock is

enabled.

Lens Type Lens.type 0 = non-UST

1 = UST lens

Not applicable when the projector is

at standby mode.

Lens Lock Lens.lock ?

0 = Off

1 = On

Not applicable when the projector is

at standby mode.

Digital Zoom /

Digital Zoom

digi.zoom =

0 - 100 Not applicable when the projector is

at standby mode.

DK8500Z DLP Projecto

Remote Communication Manual

RM85001117EN00

OSD Function Operation

command

Settings/Return Value Note

Digital Zoom /

Digital Pan

digi.pan =

-1280 - 1280

(depend on input timing;

use "op digi.pan ?" to

query current setting)

Not applicable when the projector is

at standby mode.

Digital Zoom /

Digital Scan

digi.scan =

-720 - 720

(depend on input timing;

use "op digi.scan.?" to

query current setting

Not applicable when the projector is

at standby mode.

Digital Zoom /

Reset

digi.zoom.rst

(execute) Not applicable when the projector is

at standby mode.

Active Warp

(Not on OSD)

active.warp =

1 = Keystone

2 = Four Conner

3 = Rotation

4 = Pin/Barrel

5 = Arc

Not available when projector is at

standby mode.

Reset Warp setting

(Not on OSD)

Warp.reset (execute) Not available when projector is at

standby mode.

Warp / Keystone H h.keystone =

Horizontal -470 ~ +470 Available when active.warp is set to

1 (keystone) or 4 (Pincushion)

Warp / Keystone V v.keystone =

Vertical -400 ~ + 400 Available when active.warp is set to

1 (keystone) or 4 (Pincushion)

Warp / Keystone reset Keystone.reset (execute) Not available when projector is at

standby mode

Warp / Rotation rotation =

-100 ~ +100 Available when active.warp is set to

1 (keystone), 3 (Rotation) or 4

(

Pincushion

)

Warp / Rotation reset rotation.reset (execute) Not available when projector is at

standby mode

Warp / H Pin/Barrel h.pin.barrel =

-150 ~ + 300 Available when active.warp is set to

(Pincushion).

Warp/ V Pin/Barrel v.pin.barrel =

-150 ~ + 300 Available when active.warp is set to

4 (Pincushion).

Warp/ V Pin/Barrel

Reset

Pin.barrel.reset (execute) Not available when projector is at

standby mode

Warp/ Top Left

Corner/Horizontal

4corner.ulx =

-192 ~+192 Available when active.warp is set to

2 (Four Corner).

Warp/ Top Left

Corner/Vertical

4corner.uly =

-120 ~+120 Available when active.warp is set to

2 (Four Corner).

Warp/ Top Right

Corner/ Horizontal

4corner.urx =

-192 ~+192 Available when active.warp is set to

2 (Four Corner).

Warp/ Top Right

Corner/ Vertical

4corner.ury =

-120 ~+120 Available when active.warp is set to

2 (Four Corner).

Warp/Bottom left

Corner/ Horizontal

4corner.llx =

-192 ~+192 Available when active.warp is set to

2 (Four Corner).

Warp/Bottom left

Corner/ Vertical

4corner.lly =

-120 ~+120 Available when active.warp is set to

2 (Four Corner).

Warp/Bottom Right

Corner/ Horizontal

4corner.lrx =

-192 ~+192 Available when active.warp is set to

2 (Four Corner).

Warp/Bottom Right

Corner/ Vertical

4corner.lry =

-120 ~+120 Available when active.warp is set to

(

Four Corner

)

Table des matières

Autres manuels Vivitek Projecteur

Vivitek

Vivitek D75XXWTIR Series Manuel utilisateur

Vivitek

Vivitek DX977 Series Manuel utilisateur

Vivitek

Vivitek D-220MX Manuel utilisateur

Vivitek

Vivitek D8800 Manuel utilisateur

Vivitek

Vivitek DH286-ST Series Manuel utilisateur

Vivitek

Vivitek D5010-WNL Manuel utilisateur

Vivitek

Vivitek D835 Manuel utilisateur

Vivitek

Vivitek D525ST Manuel utilisateur

Vivitek

Vivitek H5098 Manuel utilisateur

Vivitek

Vivitek D5500 series Manuel utilisateur

Vivitek

Vivitek D8 Series Manuel utilisateur

Vivitek

Vivitek D-635MX Manuel utilisateur

Vivitek

Vivitek DX4630Z Manuel utilisateur

Vivitek

Vivitek D5280U Manuel utilisateur

Vivitek

Vivitek D5380U Series Manuel utilisateur

Vivitek

Vivitek Qumi Q5 Series Manuel utilisateur

Vivitek

Vivitek D755WT SERIES Manuel utilisateur

Vivitek

Vivitek HK2299 Manuel utilisateur

Vivitek

Vivitek DU8090Z Manuel d'utilisation et d'entretien

Vivitek

Vivitek D3 Series Manuel utilisateur

Vivitek

Vivitek Q3PLUS Manuel utilisateur

Vivitek

Vivitek DX977 Series Manuel utilisateur

Vivitek

Vivitek DX883ST Series Manuel utilisateur

Vivitek

Vivitek DW3321 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
