Vivitek D732MX Manuel utilisateur

D732MX

XGA DLP PROJECTOR

www.vivitekcorp.com

Turbo-Charge Light Engine Auto-Image Optimization

Auto-Input Search

Vivitek cutting edge Turbo-Charge Light

Engine delivers up to 3 types of lamp

brightness modes (boost, normal, eco),

enabling you to conquer various light/dark environments with

suitable brightness and corresponding picture performance.

The raw extra power of this turbo-charge light engine can

further boost brightness up to 130%

Smart auto image optimization function

auto sizes and adjusts images for optimum

picture performances, allowing you to fully

concentrate on your presentations rather than

time consuming manual adjustments.

D732MX has a built-in password

authentication system, which can

increase the security and further

assist you to prevent unauthorized

usage of the projector.

Filter-Free Design

Latest DLP® Technology with 3200 Lumens of Superior Brightness

Convenient Lamp Replacement Design Off and Go Feature

D732MX projector has a built-in

aluminum alloy thermal case that

enables the projectorto efficiently

cool itself in order to conserve the

energy and prevent damage to the projector.

Auto-Power Saving

Mobile Projector. Superior Performance.Mobile Projector. Superior Performance.

The D732MX projector features Texas Instruments DLP® technology, 3200 lumens of brightness for effective

presenting even in lighted environment, and 2100:1 contrast ratio for crisp image details, all in a 7.3 lbs

package. This projector is a brand new design with a hand grip that allows you to carry the projector

comfortably. Also, this XGA (1024 x 768) projector carries the industry’s very first 5-Year DLP® chip warranty.

The projector comes with Vivitek’s 3-Year parts and labor warranty, and amazing 1-Year lamp warranty.

The D732MX can be automatically

shut-off when the projector idles

for 10 minutes without any signal

source inputs.

With normally placed or ceiling mounted,

the D732MX comes with a special top

loading lamp replacement design that

allows you to change the lamp instantly.

This unique design delivers the most

convenient and easiest method for lamp

replacement.

No filter require, resistant to dust and dirt,

no clogged filters. Reduced maintenance

fees, low total cost of ownership.

Input and Output Terminals

MODEL D732MX

DISPLAY TECHNOLOGY

RESOLUTION

BRIGHTNESS

CONTRAST RATIO

ZOOM & FOCUS

LENS THROW RATIO

PROJECTION SCREEN SIZE

PC COMPATIBILITY

VIDEO COMPATIBILITY

PC INPUT TERMINALS

KEYSTONE CORRECTION

OUTPUT TERMINALS

COMMUNICATION

TERMINALS

AUDIO SPEAKER

DIMENSIONS (W x H x D)

WEIGHT

POWER SUPPLY

FAN NOISE LEVEL

ACCESSORIES

WARRANTY

REPLACEMENT LAMP

POWER CONSUMPTION

COLOR WHEEL

LAMP LIFE

ASPECT RATIO

SPECIFICATIONS

0.7” 1-Chip DMD

XGA 1024 x 768 (Total 786,432 pixels)

3200 ANSI Lumens

2100:1 (on/off)

USB (Service), RS-232C x 1

30dB (Eco-Mode), 32 dB (Standard Mode)

Eco (200W), Standard (230W)

3W Mono

AC 110-240V

7.3 lbs

AC Power cord, VGA cable, Remote Control

3-Year Parts and Labor, 1-Year lamp warranty, and *5-Year DLP Chip

5 Segments (R, G, B, W, Y)

180W (Shut Off Time: 4,000 hrs) with Eco-Mode

Native (4:3) & Compatibility (16:9)

NTSC/NTSC 4.43, PAL B/G/H/I/M/N 60, SECAM, 480i/480p/720p/1080i

DVI-D X 1, RGB X 1, S-Video x 1, Video x 1,

Audio (RCA L & R) x 1, Audio (Mini Jack) x 1

RGB x 1, Audio x 1

Vertical (+/- 15 degree)

1.8 - 2.1

VGA, SVGA, XGA, SXGA, Macintosh

D732MX Mobile XGA DLP Projector

VIVITEK CORPORATION

Tel: 626-369-8420

Email: [email protected]

www.vivitekcorp.com

*5 Year DLP chip warranty is supported with the same process

and terms/conditions as the 3-year warranty

2008 Vivitek Corporation. Standard features, options and

specications subject to change without notice. Vivitek is a

trademark of Vivitek Corporation. DLP logo and DLP

medallion are trademarks of Texas Instruments. All other

trademarks are the property of their respective holders.

8/08 - LIT-D732MX-US

Manual Zoom & Manual Focus

23.4” - 273.4”

11.8 x 9.6 x 3.5 inches

The above numbers are approximate, and may be slightly different from the actual measurements.

Screen Size and Projection Distance

1000048-A

D732MX

Projection

Distance

Diagonal

Width

Height Diagonal Width

Height

Max.Screen (Wide) 1.8 Max.Screen Size (Tele) 2.1

3.28 ' 27.34 '' 21.87 '' 16.40 '' 23.43 '' 18.75 '' 14.06 ''

4.92 ' 41.01 '' 32.81 '' 24.61 '' 35.15 '' 28.12 '' 21.09 ''

7.87 ' 65.62 '' 52.49 '' 39.37 '' 56.24 '' 44.99 '' 33.75 ''

9.18 ' 76.55 '' 61.24 '' 45.93 '' 65.62 '' 52.49 '' 39.37 ''

10.50 ' 87.49 '' 69.99 '' 52.49 '' 74.99 '' 59.99 '' 44.99 ''

11.81 ' 98.43 '' 78.74 '' 59.06 '' 84.36 '' 67.49 '' 50.62 ''

13.12 ' 109.36 '' 87.49 '' 65.62 '' 93.74 '' 74.99 '' 56.24 ''

14.43 ' 120.30 '' 96.24 '' 72.18 '' 103.11 '' 82.49 '' 61.87 ''

15.74 ' 131.23 '' 104.99 '' 78.74 '' 112.49 '' 89.99 '' 67.49 ''

17.06 ' 142.17 '' 113.74 '' 85.30 '' 121.86 '' 97.49 '' 73.12 ''

18.37 ' 153.11 '' 122.48 '' 91.86 '' 131.23 '' 104.99 '' 78.74 ''

22.96 ' 191.38 '' 153.11 '' 114.83 '' 164.04 '' 131.23 '' 98.43 ''

32.80 ' 273.40 '' 218.72 '' 164.04 '' 234.35 '' 187.48 '' 140.61 ''

VGA-Input

USB (Service)

VGA Output

PC (Audio In/Out)

S-Video

Video

Video (L/R)

81 2 3 4 5 7

DVI-Input

RS-232C
