4. Pressing the plunger head on the handle to change the view direction of the VA-100
camera from front to side to backside.
5. As the angular lock as desired to fix the camera head position.
Software and App compatible with VA-100 USB camera
Note: The camera built in the grabber is a UVC camera and can be used with any other
software for UVC cameras.
1. Windows System:
Windows 11/10/8/7/XP: “camera” built-in; “amcap.exe”; “digital viewer”, “oasis.exe”, “Vividia
Ablescope viewer” etc.
2. MacBook System:
“Photo Booth”; “Quick Camera”; or “Digital Viewer for Mac”.
3. Android Phones and Tablets: (Connect with OTG cable)
Download from Google Play Store. “USB Camera”; “Endoscope Camera”; CameraFi” etc.
Note: Not all Android devices are compatible with our USB cameras.
4. Chromebook
“Camera”, the built-in app on Chromebook system.
5. iPad & iPhone
The grabber USB camera cannot directly connect to iPhone or iPad. A WiFi box (separate product) is
needed. Refer to your WiFi box user manual on how to connect and use.
Specification of VA-100
Camera head Diameter: 8.5 mm / 0.3”
Probe total length: 760 mm / 2.5ft
Steering Angle: 0 degrees to 180+ degrees, continuous
Resolution: 1MP,1280X720
Image sensor: CMOS
Focus range: 20 mm – 200 mm
Viewing Angle: 90-degree wide field of vision
Waterproof: IP65
Lighting: 6 white LED lights
Material: stainless steel, aluminum alloy and silicone
USB output: USB2.0
The packing list: VA-100 borescope, USB-C OTG cable, user manual.
Safety Precaution
1. The borescope should be used under 60oC (140oF). High temperature can increase video
noise, even damage the camera sensors and electronics.
