VIVA E586 Router VIVA E586 Router
ﻞﻴﻐﺸﺘﻟا ﻞﻴﻟد Quick Start Guide
Thank you for choosing VIVA E586 Router (hereinafter referred
to as the E5).
•The supported functions and actual appearance are subject to the
productpurchased.Thefollowing picturesaredisplayedfor illustration
purposes only. For details of your product selection, consult your
serviceprovider.
•This guide briey describes the functions of the E5. For details about
how to set the management parameters, see the Help on the Web
managementpage.
•If the E5 is placed in an environment with poor ventilation, it will get
heatedafteruseforalongtime.WhentheE5getsheatedtoacertain
degree,itwillswitchoffordisconnectfromthenetworkautomaticallyto
protectitself.Inthiscase,pleaseplacetheE5inawell-ventilatedplace
forheatdissipationandthenrestarttheE5.
Getting to Know Your E5
Packing List
Thepackageboxcontainsthefollowingitems.Ifanyoftheitemsarelost
ordamaged,contactyourlocaldealer.
QuickStart
Safety
Information
Mainunit Battery Datacable
Someoftheoptionalaccessoriesarenotprovidedinthepackage.Youcan
contactyourlocaldealertobuythem.
Application Scenarios
TheWiFideviceorcomputercanbeconnectedtotheInternetthroughthe
E5.Theactualconnectingproceduredependsontheoperatingsystemof
theWiFideviceorcomputer.Youcanperformtheconnectionoperations
asprompted.
Scenario1:
Multi-deviceaccessviaWiFi
Scenario2:
One-deviceaccessviaUSB
Scenario3:Multi-deviceaccessviaWiFiandUSBatthesametime Appearance
No. Item
1. Screen
2. WPSbutton
3. Powerbutton
4. USBport
5. microSDcardslot
6. Batterybutton
7. Straphole
1
4
3
2
6
7
5
Screen
No. Item
1. Signalstrength
2. Network
3. •WiFienabled
•Numberofdevicesconnected
4. Internetconnectionstatus
5. •Newmessages
•Numberofnewmessages
6. Powerlevel
7. Roamingstatestatus
8. •Trafcdata
•Connectionduration
Before You Start Installing the SIM Card and the Battery
Tips:PleaseremovethePIN1numberofyourSIMcardusinganymobile
phonepriortoinstallingtheSIMcardinyourVIVAE5router.
InstalltheSIMcardatthecardslotentrance.EnsurethattheSIMcardfaces
thedirectionasshowninthefollowinggure.ThenslideintheSIMcard.
InstallingthemicroSDcard
1.Remove the rubber cap from the microSD card slot. Then insert the
microSDcardintotheslot.
2.AfterinsertingthemicroSDcardcompletely,attachtherubbercap.
7
1
2
4
3
5
6
8
0B 00:00
•WiFi:WirelessFidelity
•WPS:WiFiProtectedSetup
•Trafcstatisticsarefor yourreferenceonly.Toobtain theactual trafc
data,contactyourserviceprovider.
Note:
•ThemicroSDcardisan optionalaccessory.If themicroSDcardis not
providedinthepackage,youcanbuyone.
•ToremovethemicroSDcard,opentherubbercapandpressthemicroSD
cardgently.WhenthemicroSDcardpopsupautomatically,takeitout.
•Do not remove the card when it is being used. Otherwise, the card
andtheE5maybedamaged,andthedatastoredonthecardmaybe
corrupted.
Charging the Battery
Note:
If you have not used the battery for a long time, please charge it first.
Method 1: Chargingbyusingthecharger
Caution:
OnlyusethechargercompatiblewiththeE5modelandprovidedbythe
designatedmanufacturers.Ifachargerincompatiblewiththedevicemodel
orprovidedbyothermanufacturersorvendorsisused,theE5mayfailto
workanddamagesmayoccur.Atthesametime,anynationalregulations
onterminalproductsorwarrantyapplicabletotheE5willbecanceled.
Thechargerisanoptionalaccessory.Ifthechargerisnotprovidedinthe
package,youcancontactyourlocaldealertobuyone.
Method 2: Charging by
connecting to a PC
1.PowerofftheE5.
2.ConnecttheE5tothePCwitha
compatibledatacable.
Accessing the Internet through a WiFi connection
Note:
Bydefault,the managementparametersarepresetonthe E5according
to the requirements of the service provider. You can follow the steps
belowtoquicklyaccesstheInternet.Forthedetailsabouthowtosetthe
managementparameters,seetheHelpontheWebmanagementpage.
Step1:PowerontheE5.
Step2:EstablishaWiFiconnection.
Step3:AccesstheInternet.
1. Power on the E5
Pressandhold untilthescreen
lightsup.Whenthescreenlightsup,it
indicatesthattheE5ispoweredon.
Note:
Pressandhold untilthescreenisoff.Whenthescreenisoff,it
indicatesthattheE5ispoweredoff.
2. Establish a WiFi connection (Taking a PC for example)
1.MakesurethattheWiFifunctionisenabled.
2.SelectStart>ControlPanel>NetworkConnections>Wireless
NetworkConnection.
Note:
To set up a WiFi connection, the PC must be congured with a wireless
networkadapter.IfWireless Network Connectionisdisplayed,thewireless
network adapter is available. Otherwise, you need to install a wireless
networkadapter.
3.ClickviewavailableWirelessNetworkstodisplaythelistwirelessnetwork
available.
4.SelectthenetworkwhoseSSIDisthesameasthatoftheE5,andthen
clickconnect.
Note:
• IftheencryptionparameterisalreadysetfortheE5,theWirelessNetwork
Connection dialog box is displayed and requires the network key and
conrmation.
• TheSSIDandkeylabelisattachedontheE5.
5.Waituntilthewirelessconnectioniconisdisplayedinthestatusareain
thelowerrightcornerofthePCscreen.Then,youcanconnectyourPC
totheE5.
3. Access the Internet
After you establish a WiFi connection successfully, you can access the
Internetineitherofthefollowingtwomodes.Bydefault,themodeisAuto.
Note:
• Youcanlaunchthewebmanagementpagetoselectthemodeofaccessing
theInternet.
• IftheE5accessestheroamingnetwork,theE5automaticallydisconnects
fromtheestablishednetworkconnection.IfyouneedtoaccesstheInternet
fromthenewnetwork,youmustre-establishanetworkconnection.
• ThedialingbuttondoesnotworkinAutomode.
Mode Operations
Auto
AftertheE5ispoweredon,itcanautomaticallyconnecttotheInternet
whendatatransmissionisrequired.Ifdatatransmissionisnotperformed
overaperiodoftime,theE5automaticallydisconnectsfromtheInternet
Manual Launchthewebmanagementpageandfollowthepromptstoconnector
disconnectfromthenetwork
Accessing the Web Management Page
1.MakesurethattheconnectionbetweentheE5andtheclientisaproper
one.
2.StarttheInternetbrowserandenterhttp://192.168.1.1intheaddressbar.
3.Enterthepassword,andthenclickLogin.
Note: The default password is admin.
Create a secure connection:
1-Launchthewebbrowserandenterhttp://192.168.1.1intheaddressbar.
2-Enterthepasswordandclicklogin.Thedefaultpasswordisadmin.
3-Clickon“settings.”
4-Clickon“quick setup.”Amessage“welcometothequicksetupwizard”
willbeshown.
5-Clickon“Next.”Amessage“CongureProleSettings”willbeshown.
6-Clickon“Next.”Amessage“congureDial-upSettings”willbeshown.
7-Click on“Next.”Amessage“congureWLANSettings”willbeshown.
Insertthedesiredrouternameinthe“Name (SSID)”led.
8-Clickon“Next.”Forthe“Authentication”select“Auto”,forthe“encryption
mode”select“WEP”.Enterthedesirednetworkkeyinthe“Network key 1”
led. This key will be requested every time a user tries to access this
connection.
9-Clickon“Next.”
10-Clickon“Finish.”Amessage“Theactionwilldisconnectyourconnection,
areyousuretoproceed?”willbeshown.
11-Clickon“Ok.”
Note: Network key should be between 5 to 10 numerical digits (E.g. 123456).
Verifying the PIN code
When PIN code protection is enabled, you need to launch the Web
managementpageandthenenterthecorrectPINcodeasprompted.Both
thePINandPUKaredeliveredwiththeSIMcard.Fordetails,consultyour
serviceprovider.
Sharing data stored on the microSD card
AfterthemicroSDcardisinserted,youcanstoredataonthecardorshare
thedatastoredonthecardonthewebmanagementpage.
1.InsertthemicroSDcard.
2.Accessthewebmanagementpage.
3.ClickSDCardtomanagethedatastoredonthemicroSDcard.
