Vitek VTC-IRLED30A Manuel utilisateur

BLACK

VITEK

VTC-IRLED30A

Long Range Infrared

Day/Night Bullet Camera

•1/3" Color CCD with 480 TV Lines Resolution

•30 Infrared LEDs enable Viewing in Total Darkness up

to 80 Feet

•True Day/Night Operation with Automatic Removable

IR Cut Filter

•Heavy Duty Weather/Vandal Resistant Aluminum

Construction

• Sunshield and Mounting Bracket Included

• 24 VAC Power Input

• Standard 6mm Lens Included. Accepts optional 4, 8,

12, and 16mm Lenses.

1. Unit contains uninsulated dangerous

voltage within the enclosure that may

be of sufficient magnitude to

constitute a risk of electric shock to

persons

2. Only use AC Power Supply

3. Read & Keep these instructions.

4. Heed to all warnings and follow all

instructions carefully.

5. Do not use near water.

6. Clean only with dry cloth.

7. Do not block any ventilation

openings. install in accordance with

the instructions.

8. Do not install near any heat source

such as radiators, heat resisters,

stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of

the polarized or grounding-type plug.

A polarized plug has to blades with

one wider the other. A grounding type

plug has to blades and a third

grounding plug. The wide blade or

the third prong are provided for

safety. if the provided plug dose not

fit into your into your outlet, consult

an electrician for replacement of the

obsolete outlet.

10. Protect the power cord from being

walked on a pinched particularly at

plugs, convenience receptacle, and

the point where they exit from the

apparatus.

11. Only use attachment/accessories

specified by VITEK.

12. Use only with cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the Unit,

13. Unplug this unit during lightning

storms or when unused for long

periods of time.

14. Refer all servicing to qualified service

personnel, Servicing is required

when the unit has been damaged in

any way, such as power-supply cord

or plug is damaged, liquid has been

spilled or objects have fallen into the

unit, the unit has been exposed to

rain or moisture, does not operate

normally or has been dropped.

15. Do not attempt to service this

product yourself as opening or

removing covers may expose you to

dangerous voltage or other hazards.

Refer all servicing to qualified service

personal.

CAUTION - To reduce the risk of electric

shock, do not perform any servicing

other than contained in these operating

instructions unless you are qualified to

do so.

CAUTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

BLACK

Pick up Element

Effective Pixels

Resolution

Minimum lllumination

S/N Ratio

Electronic Shutter

Gamma

Iris Mode

White Balance

Video Output

Lens

BLC

IR LED

Storage Temperature

Operation Temperature

Power Source

Power Consumption

Weight

1/3” Color CCD Image Sensor

771 x 492

480 TV Lines

0 Lux (IR On) / 0.5 Lux @ f2.0 (IR Off)

More than 48dB(AGC off)

1/60 to 1/100,000 sec.

0.45

AES

AWB

1.0 Vp-p composite, 75 Ω

Standard 6mm (4mm, 8mm, 12mm, 16mm Optional)

Auto

30 850nm IR LED’s

-22˚~140˚ F (-30˚~60˚ C)

14˚~122˚ F (-10˚~50˚ C)

24VAC

90 mA (IR Off) / 270 mA (IR On)

17.64 oz. / 500g

VTC-IRLED30A

SPECIFICATIONS

28492 CONSTELLATION ROAD VALENCIA, CA 91355

WWW.VITEKCCTV.COM | 888-VITEK-70

LIMITED LIABILITY WARRANTY

Your new Camera is guaranteed to be free from defects in materials

and workmanship for a period of two years from the date of

purchase.

The product must have been used only for its intended purpose, and

not been subjected to damage by misuse, willful or accidental

damage, caused by excessive voltage or lightning.

The product must not have been tampered with in any way then the

guarantee will be considered null and void.

This guarantee does not affect your statutory rights.

Contact VITEK directly for all servicing.
