Vitek VTC-BHOCR4F Manuel utilisateur

VITEK

FEATURES:

• 1/2.9” Sony CMOS

• 2.0 MegaPixel With full 1080p HD-SDI Output (SMPTE 292M)

• 25 850nm Dynamic Intensity IR LEDs with 100’ Range

• 4.3mm Fixed Iris lens Included

• Mechanical IR Cut Filter (True Day/Night)

• 3D-DNR Noise Reduction

• 16:9 Video format

• 100% Pure Digital Transmission of video data

• Up to 700’ HD Transmission Range (Depending on cable characteristics

and integrity)

• 12VDC Operation

VTC-BHOCR4F

2.0MP HD-SDI Vandal Resistant WDR

Bullet Camera with 25 IR LEDs

SPECIFICATIONS

Sensor

Resolution

S/N

Video Output

IR Illuminators

IR Color Temp.

IR Range

Dynamic Intensity IR LEDs

Lens

Minimum Illumination

Day/Night

Electronic shutter speed

White Balance

Brightness

DNR

WDR

HD Transmission Range

Weather Resistance Rating

Operating Conditions

Input Voltage

Dimensions

1/2.9” Sony CMOS

2.0 MegaPixel (1080p)

More than 52 dB (AGC Off)

1x HD-SDI (BNC)

25 IR LEDs

850nm

100’

YES

4.3mm Fixed

1 Lux at F1.2 / 0.1 Lux (B/W) / 0 Lux at IR On

Mechanical IR Cut Filter (True Day/Night)

Auto (1/ 30sec ~ 1/ 60,000sec)

Auto

3D-DNR

YES

Up to 700’ (Depending on cable characteristics and integrity)

IP-68

14°-122°F (-10°-50°C) < 80% RH

12VDC

2.95” x 5.12” x 8.39” (W x H x D)

DIMENSIONS

INSTALLATION

ADJUST MOUNT

8.39”

2.95” 2.87”

2.83”

5.16”

4.29”

5.12”

HDMI

HD-SDI DVR

LIMITED LIABILITY WARRANTY

VITEK products carry a three (3) year limited warranty. VITEK warrants to the purchaser that

products manufactured by VITEK are free of any rightful claim of infringement or the like, and

when used in the manner intended, will be free of defects in materials and workmanship for

a period of three (3) years, or as otherwise stated above, from the date of purchase by the

end user. This warranty is nontransferable and extends only to the original buyer or end user

customer of a VITEK Authorized Reseller.

The product must have been used only for its intended purpose, and not been subjected to

damage by misuse, willful or accidental damage, caused by excessive voltage or lightning.

The product must not have been tampered with in any way or the guarantee will be

considered null and void.

This guarantee does not affect your statutory rights.

Contact your local VITEK Reseller should servicing become necessary.

VITEK makes no warranty or guarantee whatsoever with respect to products sold or

purchased through unauthorized sales channels. Warranty support is available only if product

is purchased through a VITEK Authorized Reseller.

28492 CONSTELLATION ROAD VALENCIA, CA 91355

WWW.VITEKCCTV.COM Version 1.2 (3700-8537C)

July 2013
